VisionNet 560780 Manuel utilisateur

-1 -

p.n.560780

p.n.560781

Keypad Fingerprint Access Control

User Manual

Please read and understand this instruction completely before installation or operation

-2 -

1. Introduction

This series’ product is a new generation of multi-function standalone access control.

It adopts new ARM core 32-bit microprocessor design, which is powerful, stable and reliable.

It contains reader mode and standalone access control mode etc..

It’s widely applied to different occasions, such as office, residential communities, villa, bank and prison etc..

2. Features

Read 125KHz EM Card and HID Card (Optional)

Read 13.56MHz Mifare card and CPU card (Optional)

Metal backlight keypad

Contain reader mode, the transmission format could be adjusted by user.

Support seven access ways

Support admin add card and admin delete card

10,000 card users and 600 fingerprint userss.

3. Technical Specifications

Operating Voltage: DC 12-24V

Standby Current: ≤35mA

Operating Current: ≤100mA

Operating Temperature: -40°C~60°C

Operating Humidity: 0%~95%

Access ways: Fingerprint, card, code, or multiple combination methods

4. Installation

Remove the back cover from the keypad using the supplied special screw driver

Drill 2 holes on the wall for the self-tapping screws and I hole for the cable

Put the supplied rubber bungs to into the two holes

Fix the back cover firmly on the wall with 2 self tapping screws

Thread the cable through the cable hole

Attach the keypad to the back cover. (See the figure below)

-3 -

5. Wiring

No. Color Marks Description

1 Green D0 Wiegand input (Wiegand output as reader mode)

2 White D1 Wiegand input (Wiegand output as reader mode)

3 Grey ALARM Alarm signal MOS tube drain output end (optional)

4 Yellow OPEN/ BEEP Exit button input end (Beeper input as reader mode)

5 Brown D_IN/ LED Door contact switch input (LED input as reader mode) (optional)

6 Red +12V Positive power supply or AC power supply end

7 Black GND Negative power supply

8 Blue NO Relay NO end

9 Purple COM Relay COM end

10 Orange NC Relay NC end

6. Diagram

6.1 Common Power Supply

Note: The door contact and alarm function are optional

-4 -

6.2 Special Power Supply

Note: The door contact and alarm function are optional

6.3 Reader Mode

-5 -

7. Sound and Light Indication

Operation Status

Light indicator

Buzzer

Stand by Red

Operation successful Green Beep—

Operation failed Beep-Beep-Beep

Admin card enter programming Beep-Beep

Admin card exit programming Beep—

Press digital key Beep

Press * key Beep—

Press access code Red indicator flash slowly

Read card under card plus code mode Red indicator flash slowly

Read multi user cards Red indicator flash slowly

Enter programming mode Red indicator flash slowly

Enter setting status Orange

Unlocking Green

Buzzer alarm Red indicator flash quickly Alarm

8. Admin Menu

8.1 Standalone Mode Settings

Device Management

Enter programming Men

u Operation steps Description Default

value

Press * Admin code #

(Default admin code is

"999999")

00 New admin code # new admin code # Change admin code 999999

01 Read card

/ Input a fingerprint twice *

Set admin add card or admin add

fingerprint

02 Read card

/ Input a fingerprint twice *

Set admin delete card or admin

delete fingerprint

0# Reader mode

1# Standalone access control mode

2# Relay toggle mode

08 WIFI matching Optional

09 Unlocking code # (4-6 digits) Public code

-6 -

Add and Delete Users

Enter

programming Menu Operation steps Description Default value

Press * Admin

code #

(Default admin

code is "999999")

Read card

/ Input a fingerprint twice... *

Add card users or fingerprint users

continuously

“…” means

repeating the

operation,

Press * key to exit.

Press 8 or 10 digits card

number # … *

Add card users by card number

Press ID number # read

card

/ Input a fingerprint twice … *

Add card users or fingerprint users by

specific ID number

Press ID number # press 8

or 10 digits card number # … *

Add card users by specific ID number

and card number

Press ID number # press code

# … *

Add an independent user code by

specific ID number

Read user card, input the

first fingerprint twice, input the

second fing

erprint

twice...*

Match fingerprints to a card

(Maximum 2 fingerprints)

Press ID number # press 8

or 10 digits card number #

input card quantity #

Add conductive number card

Delete users

Read card

/ Input a fingerprint once … *

Delete card users by reading card /

Delete fingerprint users by

inputting fingerprint

“…” means

repeating the

operation,

Press * key to exit.

Press 8 or 10 digits card

number #… * Delete card users by card number

Press ID number # … * Delete users by ID number

20 0000# Delete ALL users

Access Ways

Enter programming Menu Operation

steps Description Default

value

Press * Admin code #

(Default admin code is

"999999")

0# Forbidden opening door

1# Entry by code only

2# Entry by card only

3# Entry by card+ code/fingerprint + code

4# Entry by card, fingerprint or code

5# Entry by fingerprint only

Entry by fingerprint + card

7# Entry by multi-fingerprint / multi-card

1# Set door open by 1 user card/user fingerprint

2-10 # Set door open by 2-

10 user cards/user

fingerprints

-7 -

Advanced Settings

Enter programming Menu

Operation

steps Description

Default

value

Press * Admin code #

(Default admin code is

"999999")

41 (0-300) # Door opening time range: 0-300S

0 equals to 50mS

42 0 # Alarming time sets 0S, means no alarm 0

(1-99) # Alarming time range: 1-99 min

0# Normal working mode

1# The external alarm and built-in buzzer will work

if wrong operations are over 5 times.

2# T

he device will be locked out for 10 min if

wrong operations are over 5 times.

62 0# Disable light indicator 1

1# Enable light indicator

0# Disable the keypad backlight

11# Enable the keypad backlight

(2-99) # Time of keypad backlight: 2-99 sec

64 0# Disable buzzer 1

1# Enable buzzer

8.2 Reader Mode Settings

Enter programming Menu Operation steps Description

Default

value

Press * Admin code #

(Default admin code is

"999999")

00 New admin code #

new admin code # Change admin code 999999

Read card / Input a

fingerprint twice *

Set admin add card or admin add

fingerprint

Read card / Input a

fingerprint twice *

Set admin delete card or admin delete

fingerprint

0# Reader mode

1# Standalone access control mode

2# Relay toggle mode

Input a fingerprint

twice, ... * Add fingerprint users continuously

“…” means

repeating the

operation,

Press * key to

exit.

Press ID number #

Input a fingerprint

twice … *

Add fingerprint users

by specific ID

number

Press * Admin code #

(Default admin code is

"999999")

Input a fingerprint

once … *

Input the 2nd

fingerprint ... *

Delete fingerprint users continuously

Press ID number # … * Delete users by the specific ID

number

20 0000# Delete ALL users

42 0# Alarming time sets 0S, means no

alarm

-8 -

Enter programming Menu Operation steps Description Default

value

(1-99)# Alarming time range: 1-99 min

51 (0-255)# Set device number 0

52 (26-58)# Wiegand output：26-58 bits 26

0# Keypad transmission format 4 bits

1# Keypad transmission format 8 bits

2# Virtual card number output

62 0# Disable light indicator 1

1# Enable light indicator

0# Disable the keypad backlight

1# Enable the keypad backlight

(2-99)# Time of keypad backlight: 2-99 sec

64 0# Disable buzzer 1

1# Enable buzzer

9. Admin Card Operation

9.1 Add Card

Read admin add card , Read the 1st user card Read the 2nd user card …,Read admin add card

Note: The add card is used to add card users continuously and quickly. When you read the admin add card at the first time,

you will hear short "BEEP" sounds twice and the indicator light turns orange, it means you have entered into add user

programming, when you read the admin add card at the second time, you will hear long "BEEP" sound once and the

indicator light turns red, it means you have exited the add user programming.

9.2 Delete Card

Read admin delete card , Read the 1st user card Read the 2nd user card … , Read admin delete card

Note: The delete card is used to delete card users continuously and quickly. When you read the admin delete card at the

first time, you will hear short "BEEP" sounds twice and the indicator light turns orange, it means you have entered into

delete user programming, when you read the admin delete card at the second time, you will hear long "BEEP" sound once,

the indicator light turns red, it means you have exited the delete user programming.

-9 -

10.User Operation

10.1 Change the User Code

Change the user code by card

Press * Read card Old code # New code # New code #

Note: The default code “1234” of matching card can’t open the door unless revising other codes.

Change the user code by fingerprint

Press * Input fingerprint Old code # New code # New code #

Note: The default code “1234” of matching fingerprint can’t open the door unless revising other codes.

Change the user code by ID number

Press * ID number # Old code # New code # New code #

Note: ID number has to be known from admin before changing the code, user code can’t be default code “1234”.

11 Other Operation

11.1 Remove Alarm

Read admin card or Read valid user card or Input valid fingerprint or Press admin code #

Note:When the alarm is activated, user can remove the alarm by reading a valid card or Input valid fingerprint or pressing

valid admin code .

11.2 Reset to Factory Default

Users can reset to the factory default when the admin code is forgotten, or the default settings have been modified,

operation as below:

Power off, press and hold the # key or the exit button continuously, power on, release the # key or the exit button until

hearing beep sound twice, the admin code has been reset to 999999, factory default settings are successful.

Note: Registered user data won’t be deleted when reset to factory default.

Technical support * 2023
