VISIONARY DESIGNS MOD-1521 Manuel

Order #XXXXX

Monitor

Mount

Kiosk

Cabinet

Kiosk Top

Monitor

Mount

Completed Assembly

Item

Qty.

Description

Base

15” RR125 Vertical Extrusion

24” RR91 Vertical Extrusion

Steps:

1) Attach vertical extrusion [2] to base [1], using screw.

2) Attach Kiosk Cabinet to vertical extrusion [2], using screw.

See Kiosk Base Attachment detail.

3) Attach horizontal extrusion [3] to Kiosk Top, from inside

Kiosk Cabinet door, using screw.

4) Connect Monitor Mounts to vertical extrusion [3].

See Monitor Mount detail.

Monitor Mount

Slide Connectors into groove

of Vertical extrusion. Tighten

set screws to secure in place.

Attach Monitor Mount back

plate to Connectors, using Bolts.

Bolts

Monitor

Mount

Connectors

with Set

Screws

Kiosk Cabinet Attachment

Kiosk Cabinet

Screw

Insert screw, from

inside Kiosk Cabinet,

into Extrusion [2].

MOD-1521 Monitor Kiosk

SETUP INSTRUCTIONS

If you would like to tell us about your experience with your setup instructions please email us at [email protected]

Order #XXXXX

DO NOT USE POWER TOOLS

ALL CONNECTIONS MUST

BE TIGHTLY SECURED

Part Identification - Numbering

Spline Connection Base Plate & Extrusion Connection

General Setup Instructions

- Read entire setup instruction manual prior to

unpacking parts and pieces.

- The setup instructions are created specifically

for this configuration.

- Setup instructions are laid out sequentially in

steps, including exploded views with detailed

explanation for assembly.

WARNING

Cleaning & Packing

- For Cleaning Metal, Plex, & Laminate Parts:

Use a MILD NON-ABRASIVE cleanser and

soft cloth/paper towel to clean all surfaces.

- Keep exhibit components away from heat

and prolonged sun exposure.

Heat and UV exposure will warp and

fade components.

- Retain all provided Packing Materials.

All provided packing materials are for

ease of repacking & component protection.

Disassembly

- For loss prevention, tighten all setscrews

and locks during disassembly

Hex Tool - Essential for Assembly

Extrusion & Lock Connection Engaged Lock

LADDERS OR LIFTS

MAY BE REQUIRED

General Information

Crate 1 of 1

Order #XXXXX Crate Packing
