Vision Engineering Ergo 80 Manuel utilisateur
Ergo8
0
User Guide
Ergo 80 stereo microscope
INTRODUCTION
Stereo microscope
Vision Engineering manufacture a wide range of patented optical systems, offering fatigue-free viewing with superb
hand-eye co-ordination, for improved quality and productivity.
To achieve the most from this precision instrument, please read the enclosed assembly instructions, usage and
maintenance guidelines.
Health & Safety
Vision Engineering and its products conforms to the requirements of the EC Directives on Waste Electrical and
Electronic Equipment (WEEE) and Restriction of Hazardous Substances (RoHS).
EN61326-1:2006
FCC Part 15
IEC 61010-1:2001
WARNING: ALL EQUIPMENT PLUGGED INTO THIS UNIT MUST BE APPROVED TO EN60950-1:2001 AND
CHECK CURRENT RATING OF OUTPUT SOCKET IF USED.
The equipment is connected to protective earth via the mains cable provided.
If the equipment is used in a manner not specied by Vision Engineering Ltd in this user guide, the protection
provided by the equipment may be impaired.
Warning symbols
This symbol, when used alone or in conjunction with the following symbol, indicates the need
to consult the operating instructions provided with the product.
WARNING: A potential risk of danger exists if the operating instructions are not followed.
This symbol indicates the presence of electric shock hazards. Consult the operating instructions
provided with the product wherever this symbol is found.
UNPACKING
System by box content
Box 1 Stand (Boom or Bench as ordered)
Box 2 Zoom assembly
Box 3 Objective
Box 4 ISIS ergonomic eyepieces or standard eyepieces
Box 5 Dovetail adapter, power supply, control box, screws, cable clips and user guide
Box 6 Boom stand adapter and screws (if Boom stand ordered)
Box 7 Accessories
CONTENTS
SYSTEM EQUIPMENT
Head 1
Stand 1
Illuminator 1
Optional equipment 2
Stage 2
Ergowedge 2
25° wedge 2
Unicam digital camera 2
Iris control 2
ASSEMBLY
Bench stand 3
Attaching the zoom assembly & objective 3
Attaching the head & control box 3
Boom stand 4
Attaching the boom stand interface bracket 4
Attaching the zoom assembly, objective, head & control box 4
Attaching the ringlight & antiglare screen 5
Attaching the head & optional iris control 5
Attaching the ergowedge 5
Attaching the 25° wedge 5
Attaching the unicam 6
Attaching the oating stage 6
Fitting the stage glass 6
Cabling 7
Isis adjustment 7
Using the iris control 7
Getting the most from your system 8
Routine maintenance 8
Tensioning 8
Environmental considerations 8
WARRANTY
Page
SYSTEM EQUIPMENT
www.visioneng.com/support Ergo 80 stereo microscope
1
SYSTEM EQUIPMENT
Head
ISIS ergonomic eyepieces
Standard eyepieces
Head adapter
Zoom assembly
Objective
Stand
Illuminator
Ringlight
Antiglare screen
SYSTEM EQUIPMENT
Ergo 80 stereo microscope www.visioneng.com/support
2
Optional equipment
Stage
Floating stage
Stage adapter
Ergowedge
25° wedge
Unicam digital camera
Iris control
ASSEMBLY
www.visioneng.com/support Ergo 80 stereo microscope
3
ASSEMBLY
Bench stand
Attaching the zoom assembly & objective
Ensuring all components are clean and dust-free, proceed as follows:
XLoosen the securing screw u.
XLower the zoom assembly vinto the stand’s head location ring w.
XTighten the securing screw.
XScrew the objective lens xup into the zoom assembly.
Attaching the head & control box
XPlace the adapter ring uon to the zoom assembly v
and using a 2mm Allen key, secure it with the securing
grub screw w.
XPlace the head xon to the adapter ring and secure it by
tightening the securing screw y.
Note: The ISIS ergonomic eyepieces are illustrated
but the procedure for the Standard eyepieces
is the same.
XRemove the 2 securing screws zfrom the top cap {
and lift the cap off.
XPlace the control box |on top of the stand, replace the
top cap and secure it in place with the replacement screws.
v
u
x
w
z
|
{
w
u
v
x
y
ASSEMBLY
Ergo 80 stereo microscope www.visioneng.com/support
4
Boom stand
Attaching the boom stand interface bracket
XThe boom stand interface bracket u is tted between the boom stand focus
assembly vand the head location ring win a 2 stage process, using the
focus control x.
XRemove the head location ring.
XTurn the focus control clockwise until there is enough room
to secure the interface bracket via the top 2 location holes - see
inset A.
XTurn the focus control anticlockwise until there is enough
room to secure the interface bracket via the top 2
location holes - see inset B.
Attaching the zoom assembly, objective, head & control box
XUsing the same procedures as detailed on page 3, attach
the zoom assembly u, objective v, head adapter
plate wand head x.
XSecure the control box yand its cap zto the
interface bracket {and secure it with the
screws provided |.
A
B
v
w
x
u
u
w
x
v
y
|
{
z
