VIRTUS Fleet Zeus Guide d'application
» Please read this user manual before using the device to ensure safe and proper use.
Vehicle Video Recorder |Device Manual
Zeus
Introduction
This user manual shows how to install the device and use its main functions. Please read this user manual
thoroughly before use of the device.
This user manual also includes the warranty certificate.
Copyright
The content of this document is protected by copyright law. Copyright © 2016 by Virtus Fleet LTD All rights
reserved. Virtus Fleet LTD. has intellectual property rights for VIRTUS FLEET and this user manual.
No part of this user manual is to be used, photocopied, or distributed, or shown to third parties without the prior
consent of Virtus Fleet LTD.
Disclaimer
This manual is subject to change without notice. Virtus Fleet LTD does not warrant this document is error-
free. Virtus Fleet LTD assumes no liability for damage incurred directly or indirectly from errors, omissions, or
discrepancies between the device and this manual.
Zeus
Introduction
Safety information 3
Instructional icons 3
WARNING 4
CAUTION 6
Package components 8
Product specification 11
Getting started 12
Device layout 12
Mounting the microSD cards 14
Insert the microSD card 15
Remove the microSD card 16
Mounting the USIM card 17
Insert the USIM card 17
Remove the USIM card 18
Installation 19
Device installation layout (recommend)20
Installing the main device 21
Installing the cameras 25
Installing the GPS 28
Installing the E-call kit 29
Mount the SD cards and USIM card 30
Connect constant power cable 31
Device status 32
Operation modes 32
LED Status display 33
Video recording 34
SD card memory proportion per settings 34
Recording type 35
Event types 36
Table of contents
Data transmission 37
Event data transmission 37
Status report 38
NAND memory 39
E-call 40
Calling scenario 40
Upon no reception 41
Reception scenario 41
Installing the PC viewer 42
Using the PC viewer 49
Screen description 50
Control panel description 52
Device setting 53
Updating the firmware 57
CE WARNING 58
Warranty Card 59
Safety information
Device Manual
3
Safety information
Please read this safety information carefully before use of the device.
Keep the following warnings and cautions to prevent unexpected accidents or property damage.
Instructional icons
WARNING
Situations that may cause injury or death in case of failure to follow the instruction.
CAUTION
Situations that may cause injury or property damage in case of failure to follow the instruction.
Useful information for operation of the device.
To indicate on the rating plate that the equipment is suitable for direct current only; to identify
relevant terminals.
Safety information
Zeus
4
WARNING
Failure to comply with safety warnings and regulations may cause serious injury or death.
• Do not disassemble, repair, or modify the device
yourself.
It may cause fire, electric shock, or malfunction. For
internal inspection or repair, contact the Virtus Fleet Service
Representative or the sales headquarters.
• If any foreign matter enters the device, stop operation
immediately.
Contact the Virtus Fleet Service Representative or the sales
headquarters for repair.
• Do not store it in a high humid environment.
In case of failure by non-compliance with the instruction,
contact the Virtus Fleet Service Representative or the sales
headquarters.
• Make sure the power is turned off when attaching or
detaching a camera.
It may cause malfunction.
• Make sure the power is turned off when installing the
device.
It may cause an accident or electric shock when installing
the device.
• Do not install the device where it can interfere with the
driver’s vision.
It may cause an accident.
• Do not operate the device when any malfunction is
found in the device.
• If the device is used out of the optimal temperature
range (-20 to 60 °C), the device performance may
decrease or it may cause malfunction.
• Avoid exposing the device to high temperature such as
microwave ovens, stoves, or hair driers.
It can cause explosion or malfunction when overheated.
Safety information
Device Manual
5
• Avoid exposing the device to direct sunlight in summer.
It can cause fire or malfunction.
• Use only accessories provided by the manufacturer.
Using generic accessories may cause the device to
malfunction or an accident.
• Do not install the device where it can interfere with the
vehicle system such as an air bag restraint system.
The vehicle system can be interfered, and may cause
physical injury.
• Use the correct input voltage.
Otherwise it can cause explosion, fire, or malfunction.
• Make sure that the device is installed properly.
The device can fall as a result of vibration, and may cause
physical injury.
Safety information
Zeus
6
CAUTION
Failure to comply with safety cautions and regulations can cause injury or property damage.
• Do not drop or cause an impact to the device.
It can cause damage or malfunction.
• Do not use your device for a while if the device is
overheated.
Prolonged exposure of your skin to an overheated device
may cause low temperature burn symptoms.
• In the circumstance with excessive light change, the
recorded video can be distorted.
While entering or exiting a tunnel, in the excessive change
of brightness, or in the excessive backlight, the quality of
recorded video can deteriorate.
• Do not operate the device with wet or oil-stained hands.
It can cause damage or malfunction.
• Clean the lens regularly.
Foreign material attached to the lens can affect the
recording quality.
• Excessively tinted glass can distort the recorded video
or cause it to be indistinct.
• The event recording may not be generated when an
impact is not enough intensity.
You may change the sensitivity of the impact detection from
the settings.
• Do not operate the device with pointed objects such as
awls or nails.
It can cause damage or malfunction.
• Do not store your device near magnetic fields.
It can cause damage or malfunction.
• Check the device, microSD card, and recording
capability periodically and replace it as necessary.
When the malfunction is found, stop operating and contact
the Virtus Fleet Service Representative or the sales
headquarter.
Safety information
Device Manual
7
• Back up important data to other storage media.
It is required to back up important data regularly to other
separate storage media to store safe for long time.
• If you want to connect the device with the constant
power cable, the installation must be serviced by a
professional car mechanic.
• The battery of the vehicle may discharge while in long
term parking.
• Risk of explosion if battery is replaced by an incorrect
type.
Safety information
Zeus
8
Package components
The product package has the following package components:
• Pictures of the components may differ from the actual ones.
• To enhance the performance of the device, components may be changed without prior notice.
• To download the dedicated PC viewer, APPs, firmware and manuals, login to the user webpage.
http://213.39.58.186:6081/html/LoginVirtus.html
2
6
1
5
3
4
BAT(+)
ACC(+)
GND
