Viper AS710R Manuel utilisateur

Ride-on Scrubbers

USER MANUAL

READ USER MANUAL CAREFULLY BEFORE USE

Please fill out return your warranty card

Model #

Serial No.#

VIPER INDUSTRIAL ESTATE

LIANG BIAN, LIAO BU

DONGGUAN, GUANGDONG

CHINA

TEL: (0769)83293988

FAX: (0769)83280104

VIPER…exceptional value

VR10029 REV.01

2014-12-30

https://harrissupplyind.com-ToOrderPartsCall608-268-8080

USER MANUAL

SAFETY PRECAUTIONS

This machine is intended for commercial use. It is constructed for use in an indoor en ironment

and is not intended for any other use. Use only with recommended accessories.

All operators shall read, understand and exercise the following safety precautions:

1) DO NOT OPERATE MACHINE:

• Unless trained and authorized.

• Unless you ha e read and understand the user manual.

• In flammable or explosi e areas.

• If not in proper operating condition.

• In outdoor areas.

2) BEFORE OPERATING MACHINE:

• Make sure all safety de ices are in place and operate properly.

3) WHEN USING MACHINE:

• Go slow on inclines and slippery surfaces.

• Follow all safety guidelines.

• Be ery careful when using the machine in re erse.

• Report and repair any damage to machine prior to operating it.

4) BEFORE LEAVING OR SERVICING MACHINE:

• Ne er park the machine on a slope.

• Turn machine off.

5) WHEN SERVICING MACHINE:

• Read user manual thoroughly prior to operating or ser icing this machine.

• Use manufacturer supplied or appro ed replacement parts.

• Use appro ed jack or hoist to safely ele ate the machine.

• Disconnect batteries prior to working on machine.

• Wear glo es when handling batteries or battery cables.

• A oid mo ing parts. Do not wear loose fitting clothing while ser icing machine.

）

SAFETY DEVICES

• Emergency-stop button(A15)

The machine comes to a sudden halt including all functions and no display can be

seen on the control panel

（

A13

）

when you press the emergency-stop button.

• Safety button (A1).

Switch off the dri e motor after a 0.5 second delay, if the operator lea es the

operator seat during operation or while mo ing. The LED screen displays STOP.

https://harrissupplyind.com-ToOrderPartsCall608-268-8080

USER MANUAL

Batteries emit hydrogen. Explosion or fire can result from hydrogen. Keep sparks

and open flames away! It is recommended to push the button (C2) to turn reco ery

tank open before charging.

Flammable materials can cause an explosion or fire. Do not use flammable

materials in tanks.

Flammable materials or reacti e metals can cause an explosion or fire. Do not pick

up by hand.

WARNING It in icates a potential risk of injury or angerous situation with risk of

eath for the operator.

NOTED It in icates a remark relate to important remin ing or useful

functions.

MACHINE SET UP & INSTALLATION

UNPACKING MACHINE

Be sure and check packing carton for any damage. Report immediately any damage to carrier.

Check contents of package to ensure that the following items are included:

1, Machine

2, Squeegee assembly

3, Brush assembly(x2)

4, User manual

5, Battery charger (If equipped)

6, Batteries (x4) (If equipped)

7, Connecting wire for battery and charger (If equipped)

8, Warning lamp (If equipped)

9,Bumper bracket(If equipped)

BATTERY CONNECTIONS

1. Turn off the key switch (E5).

2. Turn the seat (A1) open, push board (C2) and turn reco ery tank (A3) open. If machine does

not include batteries. Fit batteries suitable to your requirements.

https://harrissupplyind.com-ToOrderPartsCall608-268-8080

USER MANUAL

7. Make sure solution tank water indicator (E10) is not on. If on, fill water in solution tank (A4).

8. Check that the water al e (D2) is not indicated “0”.

INSTALLING PAD DRIVER OR BRUSH

1. Ensure that the machine is turned off (E5).

2. Raise the brush head (A7) off the floor by trampling the front of foot pedal (A10) on the left

of machine.

3. Put brushes (A8) below both dri er motor hub.

4. Lower the brush head (A7) assembly by trampling the rear of foot pedal (A10). And sitting on

the machine to start brush switch (E3). Lightly depress dri er pedal (C6), then brushes

automatic installed. If installation cannot be performed successfully in one shot, turn off

brush switch (E3) and reset the suit position to install brushes.

5. Adjusting the nut (A6) to properly place for work.

Ne er work without the brusher/pad perfectly installed.

When cleaning or replacing the brushes, you should raise the brush head and rotate

the re erse direction to “working” direction quickly. The two brushes are re erse in

direction.

INSTALLING AND ADJUSTING THE SQUEEGEE

1. Ensure that the machine is turned off (E5).

2. Turn the squeegee lift le er (C5) to put down the squeegee bracket (A5) on floor.

3. Loosen the two knobs (B2) on the squeegee and slide the squeegee into the slots in the back

of the squeegee bracket.

4. Tighten the knobs(B2) securely.

5. Secure the acuum hose (B3) on the pick-up tube of the squeegee.

6. Adjusting the nut (B1) to properly place for suction.

FILLING THE SOLUTION TANK

1. It can be filled in water use a hose under the seat (C4).

2. Do not o erfill the solution tank. Lea e at least two inch from the opening of tank.

3. Water temperature should not exceed 40

Depress the front,

Brushes up

Depress the rear,

Brushes down

https://harrissupplyind.com-ToOrderPartsCall608-268-8080

USER MANUAL

Use only low-foam and non-flammable detergents suitable for ride-on scrubber

applications.

Each time when you need to fill the solution tank, always empty and clean the reco ery

tank by remo ing the drain hose plug(C1). After each use, unscrew the drain cap (D1) to

drain solution tank.

CHECKING THE SPEED DRIVER

1. Sit on seat (A1) of the machine.

2. Turn on the key switch (E5).

3. Lightly depress the dri er pedal (C6) to mo e and release it checking the machine forward or

stop.

4. For more security, you need to press the Emergency-stop button (A15) to make machine

sudden halt to check the button is work, when you use the machine for the first time.

Release it by turning.

5. If the dri e motor error indicator (E4) is on, you must pay more attention. see ERROR

INFORMATION

The gradient in the direction of tra el should not exceed (10) %.

The brake of dri e motor is acti e when the machine is running normally, that is the

brake bracket is close to motor main body. When machine is on package \un-package or

machine error and some special situations, brake bracket will pull out, and use washer

to choke

，

so the machine can mo e by hand pushing.

MACHINE OPERATION

Do not operate machine unless you ha e professional training. You ha e read and

understand this manual before operate machine.

1. You should sit on the seat of the machine when you operate it.

2. Lower squeegee assembly to the floor.

Make sure to raise the squeegee before the machine is mo ing backward, or machine

stops and LED screen displays ERR-01.

3. Lower the brush head to the floor.

You’d better to turn off the brush motor button before raising the brush to pre ent

water throw out. You’d better to raise the brush head before the machine is re erse.

Don’t make brushes work in a same place for a long time to damage the floor.

4. Turn on the key switch.(E5)

https://harrissupplyind.com-ToOrderPartsCall608-268-8080
