Viotek GNV29CB Manuel utilisateur

In order to continue serving our customers and providing the best products, our product information

including our user manuals may receive updates from time to time. Please check our website for the latest

user manuals and product materials.

GNV29CB

GAMING MONITOR

USER MANUAL

Table of Contents

Section 1: Safety Precautions..................................................... 4

Section 2: Box Contents.............................................................. 5

Section 3: Product Overview....................................................... 6

3.1 – Monitor Buttons ............................................................... 6

3.2 – Monitor Ports................................................................... 6

Section 4: Stand Installation ....................................................... 7

Section 5: Mount Installation ...................................................... 8

Section 6: Basic Operation.......................................................... 9

Section 7: Indicator Light ............................................................ 9

Section 8: OSD.............................................................................. 10

8.1 – OSD Menu Functions ...................................................... 10

Section 9: RGB, LED Effects and GAMEPLUS .......................... 12

Section 10: Troubleshooting ....................................................... 13

Section 11: Speciﬁcations ........................................................... 14

Section 12: Three-Year Limited Hardware Warranty................. 14

Section 1: Safety Precautions

Read and observe the following warnings and information below.

1. Before cleaning, always unplug your monitor. Only use dry cloth or lightly damp

cloth to clean your monitor. Dry cloth is, however, the safest. If using damp cloth,

wait for your monitor to completely dry before plugging it in again.

2. Do not use alcohol or ammonia-based cleaner and/or liquids to clean your

monitor.

3. This monitor features ventilation openings on the back of the unit. Avoid blocking

these openings to prevent the monitor from overheating.

4. Avoid placing this monitor near any heat sources, e.g., portable heaters or

heating vents, as this may cause damage to your monitor.

5. Do not spray cleaner and or any kind of liquid directly onto the monitor’s screen

or any part of the monitor.

6. Do not insert anything into any part of the monitor especially the ventilation

openings.

7. Always make sure your monitor is placed on a secure, level surface to prevent it

from falling and sustaining damage.

8. Unplug your monitor during any extended periods of non-use.

9. Do not place heavy items on the monitor or monitor cables.

10. Do not attempt to disassemble or remove parts from the monitor. Any

disassembly or modication not performed by an authorized technician can

result in damage to the monitor and/or possible exposure to high voltage

electricity which may lead to serious injury or death.

VIOTEK®shall not be held responsible for injury or damage of products or persons

due to failure to adhere to the aforementioned precautions or any others noted

hereafter.

The terms HDMI and HDMI High-Denition Multimedia Interface,

and the HDMI Logo are trademarks or registered trademarks of

HDMI Licensing Administrator, Inc. in the United States and other

countries.

Section 2: Box Contents

Monitor x 1 Stand Stem x 1 Stand Base x 1

Power Cable x 1

Decorative Cover x 1

NO. 1 Screws x 3

(for Stand Installation)

DP Cable x 1

Screwdriver x 1 User Manual x 1

Extra screws may be included as backup.

NO. 2 Screws x 4

(for Wall Mounting)

17mm

27.5mm

Section 3: Product Overview

3.1 – Monitor Buttons

7 Audio Output: Insert the audio cable for output of audio signals.

8 DP Connector: Insert one end of the DP cable into the computer’s DP output

and connect the other end to the monitor’s DP port.

9 HDMI Connectors: Insert one end of the HDMI cable into the computer’s

HDMI output and connect the other end to the monitor’s HDMI port.

10 Power Connector: Insert the power cable to supply power to the monitor.

7 9 10

2 3 4 5 61

1 M Menu Button: Press to display the OSD menu or enter sub-menus.

2 Down Button: Press to move down in the menus.

3 Up Button: Press to move up in the menus.

4 E Exit Button:Press to exit.

5 Power Button: Press to turn the monitor on/off.

6 LED Indicator: Changes colors to indicate status. Refer to Section 7.

3.2 – Monitor Ports

HDMI 2.0 HDMI1.4

Section 4: Stand Installation

Keep the foam underneath the monitor before attaching the stand.

1. Open the package and take out the monitor with foam still attached. Gently place

it on a desktop or table.

2. Take out the stem and base. Insert the stem into the base then use the included

screwdriver and one NO.1 screw to fasten base to the stem.

NO.1 Screw x 1

Stand Stem

Base

3. Remove the foam covering the back of the monitor, then insert the stem with base

into the adapter on the back of monitor. Use one NO. 1 screw to fasten stem onto

the adapter.

4. Take out the decorative cover and cover it in place on the stem.

Decorative Cover

NO.1 Screw x 1

5. With the stand fully assembled, reattach it onto the back of monitor. Then remove

the remaining foam on monitor and stand it up on a at, level desktop or table.

Make sure the monitor is laid on a at surface before removing the stand.

Section 5: Mount Installation

1. Open the package and take out the product with foam still attached. Gently

place it on a desktop or table. Remove the extra parts and the foam covering the

monitor. If the monitor is already attached to the stand, remove the stand.

Adapter

Hole

2. Gently put one nger into the hole of adapter then pull it out to remove it from the

back of monitor, then follow the below picture to tighten the included four NO. 2

screws onto the mounting holes on back of monitor.

27.5 mm NO.2

Screws x 2

17 mm NO.2

Screws x 2

17mm

27.5mm

17mm

27.5mm

3. Install the monitor on the wall, mount, or xture as desired.

Mount

(Not included)

Section 6: Basic Operation

1. Insert one end of the DP cable into your PC’s graphics card. An HDMI cable may

also be used. HDMI cable not included.

2. Connect the other end of the cable to the corresponding connector on your

monitor.

HDMI Connectors

DP Connector

3. Connect the power cable to your monitor then connect the other end to your

power source. It is recommended that you use a surge protector with adequate

voltage if a wall outlet cannot be reached directly.

4. Locate the power button on the monitor and press it to turn the monitor on.

Overclocking (DP Only)

Depending on your graphics card, it may be possible to overclock the monitor’s

refresh rate, up to 120Hz. Doing so may limit max. resolution as determined by your

graphics card. You must use an HDMI 2.0 connection or DisplayPort to reach higher

refresh rates.

Overclocking can result in image distortion based on the conguration of the connected

device. It may be possible to reduce distortion by lowering monitor resolution.

Overclocking has the potential to damage the monitor. Damage caused by overclocking

is not covered by the warranty.

AMD FreeSync

This feature is off by default. To activate, you must have hardware with FreeSync

capability, a DP or HDMI cable, and the latest graphic drivers. After connecting your

computer and monitor with a DP or HDMI cable, you may receive a prompt to enable

the feature on your computer. If you do not, you may need to enable the function in

your graphics card menu. See your graphics card manufacturer’s documentation for

instructions.

Section 7: Indicator Light

Indicator Light

Solid blue light indicates power is on and the monitor is operating normally. Flashing

blue light indicates no video source, no horizontal or vertical signal has been

detected or voltage is low. Please ensure your computer is on and all video cables

are fully inserted and/or connected.

Section 8: OSD

The On-Screen Display (OSD) Menu may be used to adjust your monitor’s settings and

appears on screen after turning on the monitor and pressing the Mbutton.

When using the monitor for the rst time, settings will automatically adjust to optimal

settings according to your computer’s setting congurations.

1. Press any one of the buttons (M, , , E, ) to activate the navigator screen.

eco

2. Press M to enter the OSD screen.

Input Source

Brightness/Contrast

Color Setting

Picture Quality Setting

Display

Audio

Multi-Window

OSD

Other

Resolution：1920x1080@200Hz

Input Source

Brightness/Contrast

Color Setting

Picture Quality Setting

Display

Audio

Multi-Window

OSD

Other

Window2:

InputSource：

Resolution：

Window1：

InputSource：DP

Resolution：1920x1080@200Hz

HDMI1 (2.0)

HDMI2 (1.4)

3. Press eco or to browse functions.

- Highlight the desired function and then press Mto enter the sub-menu.

- Press eco or to browse sub-menus then press Mto highlight the desired function.

- Press eco or to highlight an option and then press M to conrm the settings and

exit the current screen.

4. Press Eto exit the current screen.

8.1 – OSD Menu Functions

Main Menu Sub-Menu Options Description

Input

Source

DP NONE Switch to DP signal input

HDMI 1 2.0

HDMI 2 1.4 NONE Switch to HDMI signal input
