Viking Installation Guide

Professional & Designer Freestanding

Refrigeration Side Trim, Side Panel,

Top Panel & Grille Installation

Apply ad esive tape to grille assembly.

Required Components Remove and discard screw and inge cover, if

applicable.

Remove edge of corner cover.

Left Shim

Trim

Left SideTrim

Right Shim

Trim Right Side

Trim Front Grille

Adhesive

Tape

Screws

Grille Spacer

L-Bracket Right

L-Bracket Left

Installation - Side Trim and Grille

(Built-In Installation) (cont.)

Attac brackets and spacers, included in t e kit, to t e

grille assembly wit four A screws.

Remove ad esive backing. Firmly press t e grille

assembly down so t e ad esive ad eres to t e cabinet.

Align grille assembly to front door and position grille

on top of unit.

Professional & Designer

Freestanding Refrigerators

Description VCSF/DDSF136D with side panels/tops/grilles

Overall widt wit side panels 35-7/8” (91.1 cm)

Overall eig t wit tops/grilles 71-7/8” (182.6 cm)

Cutout widt wit side panels 36” (91.4 cm)

Cutout eig t wit tops/grilles 72” (182.9 cm)

Specifications

Installation - Side Panel, Top Panel and Grille

(Wrapped Installation)

Required Components Remove and discard screw and inge cover, if

applicable. (Repeat if two inges are used.)

Left Panel Right Panel

Top Panel

Front Grille

Caps

Screws

Remove edge of corner cover.

A - Designer Series

B - Pro Series

Wit top panel and grille upside down, position grille

assembly in front of top panel. Secure top panel to grille

assembly via four outer oles and t ree inner oles.

Remove ad esive backing from t e side panel. Fit t e

side panel to t e front of t e unit first.

Attac rear of side panels wit screws.

NOTE: T e oles on t e side panel are clearance oles.

Installation - Side Trim and Grille

(Built-In Installation) (cont.)

Secure t e grille brackets to t e oles in t e inge

plate wit two B screws.

72”

Raise t e unit up until t e measurement from t e floor

to t e top of t e grille assembly is 72 inc es or 6 feet.

complete

S im trim as ad esive backing on bot sides. Remove ad esive

backing on refrigerator side only. Fit t e s im trim to t e front of t e

unit first. Locate t e top of t e s im trim wit t e top of t e

refrigerator cabinet.

Remove ad esive backing for t e side trim. Locate t e

top of t e side trim wit t e top of t e grille assembly.

Press t e side trim into t e refrigerator cabinet at t e

center location.

Installation - Side Panel, Top Panel and Grille

(Wrapped Installation) (cont.)

Remove ad esive backing from ot er side panel. Fit t e

side panel to t e front of t e unit first. Spacer on top of

side panel needs to sit on top of refrigerator cabinet.

Attac rear of side panels wit screws.

NOTE: T e oles on t e side panel are clearance oles.

Align top panel and grille assembly to front door and

position top panel and grille on top of unit.

Insert screws t roug oles of top panel into side

panel.

Insert cap covers into oles.

complete
