Viking VMOS201SS Guide de démarrage rapide
R E V I S E D 5 / 1 1 / 1 1
© 2 0 1 1 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
PLANNING AND DESIGN GUIDE
V I K I N G R A N G E . C O M • 1 - - V I K I N G 1
Both ovens include
• Capacity—2.0 cu. ft.
o 17-3/ ”W. x 10”H. x 1 -5/ ”D.
o 16” diameter turntable
• Commercial-type styling and design
• 13 Sensor settings—adjusts cooking
times and power levels for a variety
of foods and quantities
• Breakfast and Lunch options for
cooking and re-heating popular food
items
• 15 Minute Dinners and Preset
Recipes each offer five recipes with
easy-to-follow steps
• Add-A-Minute allows you to add a
minute of extra cooking time with the
touch of one button
• Warm/Hold feature allows you to keep
food warm for up to 30 minutes
• Child lock safety feature locks the
control panel to prevent unwanted
operation
• Interior light
• Suitable for placement on countertop,
in 30”W. or 36”W. multi-use chamber,
or installed as a built-in using a trim
kit. (Chambers and trim kits sold
separately—see Installation Notes &
Accessories for part numbers.)
FINISH DETAILS FOR DESIGNER MODEL
• Stainless Steel (SS)
FINISH DETAILS FOR PROFESSIONAL MODEL
• Stainless Steel (SS), Black (BK), White
(WH), Metallic Silver (MS), Graphite
Gray (GG), Stone Gray (SG), Taupe (TP),
Biscuit (BT), Cotton White (CW), Oyster
Gray (OG), Golden Mist (GM),
Lemonade (LE), Sage (SA), Mint Julep
(MJ), Sea Glass (SE), Iridescent Blue (IB),
Viking Blue (VB), Pumpkin (PM), Racing
Red (RR), Apple Red (AR), Burgundy
(BU), Plum (PL), Chocolate (CH), and
Cobalt Blue (CB).
Standard Features & Accessories
Model Options
COOKING
Professional Custom & Designer
Microwave Oven
*Shown with trim it. See Installation Notes & Accessories for details.
ORDERING INSTRUCTIONS
First specify model number, and then color code (VMOS201SS).
VMOS201
Professional Custom
Microwave Oven
VMOS201*
w/Trim Kit
DMOS201
Designer
Microwave Oven
DMOS201*
w/Trim Kit
DMOS201
w/Trim Kit
VMOS201
Professional Custom
Microwave Oven
VMOS201
w/Trim Kit
DMOS201
Designer
Microwave Oven
R E V I S E D 5 / 1 1 / 1 1
© 2 0 1 1 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
COOKING
Professional Custom & Designer
Microwave Oven
PLANNING AND DESIGN GUIDE
V I K I N G R A N G E . C O M • 1 - - V I K I N G 1
✪
Please see
Installation Notes
and Accessories for
important information,
including trim kits and
multi-use chambers.
All models
Overall width 2 ” (60.9 cm)
Overall height (from bottom) 13-3/8” (33.9 cm)
Overall de th (from rear) 19-1/ ” ( 8.9 cm)
Interior (each oven)
Width 17-3/8” ( .1 cm)
Height 10-1/2” (26.6 cm)
De th 18-5/8” ( 7.3 cm)
A rox. shi weight 6 lbs. (20.9 kg)
Dimensions & Specifications
19-1/4”
(48.9cm)
24”
(60.9cm)
13-3/8”
(33.9cm)
19-1/4”
(48.9cm)
24”
(60.9cm)
13-3/8”
(33.9cm)
PROFESSIONAL
CUSTOM
DESIGNER
PRODUCT DIMENSIONS
COOKING
Professional Custom & Designer
Microwave Oven
PLANNING AND DESIGN GUIDE
V I K I N G R A N G E . C O M • 1 - - V I K I N G 1
R E V I S E D 5 / 1 1 / 1 1
© 2 0 1 1 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
16-3/4”
(42.5 cm) min.
to
17”
(43.2cm) max.
16-3/4”
(42.5 cm) min.
to
17”
(43.2cm) max.
4”
(10.2cm)
4”
(10.2 cm)
4”
(10.2cm)
6”
(15.2cm)
6”
(15.2cm)
4”
(10.2cm)
4”
(10.2 cm)
4”
(10.2cm)
Outlet
location
area
24-3/8”
(61.9cm)min.
to
24-11/16”
(62.7 cm) max.
20”
(50.8 cm) min.
All Models
Cutout width 2 -3/8” (61.9 cm) min. to 2 -11/16” (62.7 cm) max.
Cutout height 16-3/ ” ( 2.5 cm) min. to 17” ( 3.2) max.
Cutout de th 20” (50.8 cm)
UTILITY
REQUIREMENTS
GAS
•Not applicable
ELECTRICAL
• Three-and-a-half
foot power cord
included
• 120 VAC/60 Hz
•Maximum amp
usage—
o VMOS—
13 (1.5 kW)
oDMOS—
13 (1.5 kW)
PLUMBING
Not applicable
Installation Requirements
ACCESS REQUIREMENTS
DMOS201
w/Trim Kit
VMOS201
Professional Custom
Microwave Oven
VMOS201
w/Trim Kit
DMOS201
Designer
Microwave Oven
COOKING
Professional Custom & Designer
Microwave Oven
PLANNING AND DESIGN GUIDE
V I K I N G R A N G E . C O M • 1 - - V I K I N G 1
R E V I S E D 5 / 1 1 / 1 1
© 2 0 1 1 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
Built-In Trim Kits
• Stainless Steel (SS)
• Designed to match with corresponding ovens and warming drawers
•Trim gives finished look to ovens installed as built-in units
• Kit includes frame assemblies, exhaust duct assembly, and metal fasteners
Compliance Information
WARRANTY INFORMATION*
• Three-year full warranty—complete product (Professional Series)
• One-year full warranty—complete product (Designer Series)
• Five-year limited warranty—magnetron tube (Professional and Designer)
• Ninety-day limited warranty—cosmetic parts such as glass, painted, and decorative items (Professional and Designer)
*For complete warranty see Use & Care Guide. Warranty valid on Viking products shipped within the United States and Canada.
✪Installation Notes & Accessories
Model Description Approx. ship wt. lbs. (kg)
VMTK272 26-1/2”W./18-1/4”H. Professional microwave trim 12.9 (5.8)
VMTK302 29-1/2”W./18-1/4”H. Professional microwave trim 13.9 (6.3)
VMTK362 35-1/4”W./18-1/4”H. Professional microwave trim 14.9 (6.8)
DMTK302 29-1/2”W./17-1/2”H. Designer microwave trim 15 (6.9)
