ViewSonic VLCDS25973-4W Manuel utilisateur

Model No. VLCDS25973-4W/5W

19” Color TFT LCD Display

Service Manual

ViewSonic VP912s/b1

ViewSonic

381 Brea Canyon Road, Walnut, California 91789 USA - (800) 888-8583

(VP912s/b_SM_902 Rev. 1bMar. 2005)

reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or

computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical,

manual or otherwise, without the prior written permission of ViewSonic Corporation.

Disclaimer

ViewSonic makes no representations or warranties, either expressed or implied, with respect to the

contents hereof and specifically disclaims any warranty of merchantability or fitness for any particular

purpose. Further, ViewSonic reserves the right to revise this publication and to make changes from time

to time in the contents hereof without obligation of ViewSonic to notify any person of such revision or

changes.

Trademarks

ViewSonic is a registered trademark of ViewSonic Corporation.

All other trademarks used within this document are the property of their respective owners.

Optiquest is a registered trademark of ViewSonic Corporation.

Revision History

ViewSonic CorporationConfidential

Do Not Copy VP912s/b

DCN Number ECR Number

Documents Number Description of Changes EditorRevision SM Editing Date

1a 08/26/04 4644 Initial Release A. Lu

1b 03/04/05

5005 Panel Change from AUO M190EN04 V1(12ms) A. Lu

4819 Scaler GM5120

to AUO M190EN04 V4 (12ms),

TABLE OF CONTENTS

2. Specification

3. Front Panel Function Control Description

4. Circuit Description

6. Troubleshooting Flow Chart

9. Block Diagram

10. Schematic Diagrams

7. Recommended Spare Parts List

1. Precautions and Safety Notices

5. Adjustment Procedure

8. Exploded Diagram and Spare Parts List

11. PCB Layout Diagrams

ViewSonic CorporationConfidential

Do Not Copy VP912s/b

1. Appropriate Operation

(1) Turn off the product before cleaning.

(2) Use only a dry soft cloth when cleaning the LCD panel surface.

(3) Use a soft cloth soaked with mild detergent to clean the display housing.

(4)Use only a high quality, safety approved AC/DC power cord.

(5)Disconnect the power plug from the AC outlet if the product will not be used for a long period of time.

(6) If smoke, abnormal noise, or strange odor is present, immediately switch the LCD display off.

(7) Do not touch the LCD panel surface with sharp or hard objects.

(8) Do not place heavy objects on the LCD display, video cable, or power cord.

(9) Do not use abrasive cleaners, waxes or solvents for your cleaning.

(10) Do not operate the product under the following conditions:

- Extremely hot, cold or humid environment.

-Areas containing excessive dust and dirt.

- Near any appliance generating a strong magnetic field.

- In direct sunlight.

2. Caution

No modification of any circuit should be attempted. Service work should only be performed after you are thoroughly familiar

with all of the following safety checks and servicing guidelines.

3. Safety Check

Care should be taken while servicing this LCD display. Because of the high voltage used in the inverter circuit, the voltage is

exposed in such areas as the associated transformer circuits.

4. LCDModule Handling Precautions

4.1 Handling Precautions

(1) Since front polarizer is easily damaged, pay attention not to scratch it.

(2)Be sure to turn off power supply when connecting or disconnecting input connector.

(3)Wipe off water drops immediately. Long contact with water may cause discoloration or spots.

(4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.

(5) Since the panel is made of glass, it may break or crack if dropped or bumped on hard surface.

(6)Since CMOSLSI isusedinthis module, take care of static electricity and ensure human earth when handling.

(7)Do not open or modify the Module Assembly.

(8)Do not press the reflector sheet at the back of the module in any direction.

(9)In the event that a Module must be put back into the packing container slot after it was taken out of the

container, do not press the center of the CCFL Reflector edge. Instead, press at the far ends of the

CFL Reflector edge softly. Otherwise the TFT Module may be damaged.

(10) At the insertion or removal of the Signal Interface Connector, be sure not to rotate or tilt the Interface

Connector of the TFT Module.

1. Precautions and Safety Notices

ViewSonic CorporationConfidential

Do Not Copy VP912s/b

(11) After installation of theTFT Module intoan enclosure(LCDmonitor housing, for example), do not twist or

bend the TFT Module even momentarily. When designing the enclosure, it should be taken into consideration

that no bending/twisting forces may be applied to the TFT Module from outside. Otherwise theTFT Module

may be damaged.

(12) The cold cathode fluorescent lamp in the LCD contains a small amount of mercury. Please follow local

ordinances or regulations fordisposal.

(13) The LCD module contains a small amount of materials having no flammability grade. The LCD module

should be supplied with power that complies with the requirements of Limited Power Source

(IEC60950 or UL1950), or an exemption should be applied for.

(14) The LCD module is designed so that the CCFL in it is supplied by a Limited Current Circuit (IEC60950

or UL1950). Do not connect theCCFL to a HazardousVoltage Circuit.

ViewSonic CorporationConfidential

Do Not Copy VP912s/b

5. Handling Methods

ViewSonic CorporationConfidential

Do Not Copy VP912s/b

Only touch the metal frame of the LCD

panel or the front cover of the monitor. Do

not touch the surface of the polarizer.

If the surface of the LCD panel is pressed

by fingers, that may cause "MURA."

Take out the monitor by grasping the cushions.

If the monitor is removed by grasping the

LCD panel, that may cause "MURA."

Correct Methods: Incorrect Methods:

ViewSonic CorporationConfidential

Do Not Copy VP912s/b

Place the monitor on a clean and soft

foam pad.

If the monitor is placed on foreign objects,

that could scratch the surface of the panel

or cause "MURA."

If the panel is placed facedown on the

lap, that may cause "MURA."

1. General Requirements

General Specifications

Test Resolution & Frequency 1280x1024 @ 60Hz

Test Image Size Full Size

Contrast and Brightness Controls Factory Default:

Contrast = 50%, Brightness = 100%

2. Signal Interface

Video Interface

Input Connector 1 (Analog 1) DB-15 (Analog)

Input Connector 2 (Analog 2) DB-15 (Analog)

Digital Input Connector DVI-I (Digital)

Default Input Connector Defaults to the first detected input

Video Cable Connector DB-15 Pin out Compliant DDC 2B

Video Signals 1. Video RGB (Analog)

Separate, Composite, and Sync on Green

2. TMDS (Digital)

Video Impedance 75 Ohms (Analog), 100 Ohms (Digital)

Exclusions Not compatible with interlaced video

3. Power

Power Supply

Internal Power Supply Primary : LSE0204A1250

2nd source: Tiger power TOF 5001

Input Voltage Range 90 to 264 VAC

Over Current Protection 7.0 A typical at 12.0 VDC

Power Dissipation 50 Watts (typ.)

2. Specification

ViewSonic CorporationConfidential

Do Not Copy VP912s/b

4. Electrical Requirements

Horizontal / Vertical Frequency

Horizontal Frequency 24 – 82 KHz

Vertical Refresh Rate 50 – 85* HZ.

FOR RESOLUTION 1280 X 1024, THE

VERTICAL RFRESH RATE UP TO 75 HZ; FOR

THE REST RESOLUTIONS, THE VERTICAL

REFRESH RATE UP TO 85HZ

Maximum Pixel Clock 135 MHz

Primary Presets 1280x1024 @ 60Hz

Look up table timing

<<Analog>>

640 x 350 @ 70Hz, 31.5kHz

640 x 400 @ 60Hz, 31.5kHz

640 x 400 @ 70Hz, 31.5kHz

640 x 480 @ 50Hz, 24.7kHz

640 x 480 @ 60Hz, 31.5kHz

640 x 480 @ 67Hz, 35.0kHz

640 x 480 @ 72Hz, 37.9kHz

640 x 480 @ 75Hz, 37.5kHz

640 x 480 @ 85Hz, 43.27kHz

720 x 400 @ 70Hz, 31.5kHz

800 x 600 @ 56Hz, 35.1kHz

800 x 600 @ 60Hz, 37.9kHz

800 x 600 @ 75Hz, 46.9kHz

800 x 600 @ 72Hz, 48.1kHz

800 x 600 @ 85Hz, 53.7kHz

832 x 624 @ 75Hz, 49.7kHz

1024 x 768 @ 60Hz, 48.4kHz

1024 x 768 @ 70Hz, 56.5kHz

1024 x 768 @ 72Hz, 58.1kHz

1024 x 768 @ 75Hz, 60.0kHz

1024 x 768 @ 85Hz, 68.67kHz

1152 x 864 @ 75Hz, 67.5kHz

1152 x 870 @ 75Hz, 68.7kHz

1280 x 1024 @ 60Hz, 63.4kHz

1280 x 1024 @ 75Hz, 79.97kHz

1280x 720 @ 60Hz, 45kHz (HDTV)

<<Digital>>

640 x 350 @ 70Hz, 31.5kHz

640 x 400 @ 60Hz, 31.5kHz

640 x 400 @ 70Hz, 31.5kHz

640 x 480 @ 50Hz, 24.7kHz

640 x 480 @ 60Hz, 31.5kHz

640 x 480 @ 67Hz, 35.0kHz

640 x 480 @ 72Hz, 37.9kHz

640 x 480 @ 75Hz, 37.5kHz

640 x 480 @ 85Hz, 43.27kHz

720 x 400 @ 70Hz, 31.5kHz

800 x 600 @ 56Hz, 35.1kHz

800 x 600 @ 60Hz, 37.9kHz

800 x 600 @ 75Hz, 46.9kHz

800 x 600 @ 72Hz, 48.1kHz

800 x 600 @ 85Hz, 53.7kHz

832 x 624 @ 75Hz, 49.7kHz

1024 x 768 @ 60Hz, 48.4kHz

1024 x 768 @ 70Hz, 56.5kHz

1024 x 768 @ 72Hz, 58.1kHz

1024 x 768 @ 75Hz, 60.0kHz

1024 x 768 @ 85Hz, 68.67kHz

1152 x 864 @ 75Hz, 67.5kHz

1152 x 870 @ 75Hz, 68.7kHz

1280 x 1024 @ 60Hz, 63.4kHz

1280 x 1024 @ 75Hz, 79.97kHz

1280x 720 @ 60Hz, 45kHz (HDTV)

Changing Modes

zMaximum Mode Change Blank Time for

image stability : 3 seconds (Max), excluding

“Auto Adjust” time

zUnder DOS mode (640 x 350, 720 x 400 &

640 x 400), it should recall factory setting

when execute “Auto Adjust” by “0-Touch™”

zThe monitor needs to do “Auto Adjust” the

first time a new mode is detected (see section

“0-Touch™ Function Actions”)

zWhile running Change Mode, Auto Adjust or

Memory Recall, the image shall blank

ViewSonic CorporationConfidential

Do Not Copy VP912s/b

5. LCD Panel

Panel Characteristics

Model number AUO M190EN04

Type TN type with LVDS interface

Active Size 376.32 (H) x 301.06 (V)

Pixel Arrangement RGB Vertical Stripe

Pixel Pitch 0.294 mm

GLASS TREATMENT Anti Glare (Hard coating 2H)

# OF BACKLIGHTS 4 CCFL edge-light (2 top / 2 bottom)

BACKLIGHT LIFE 50,000 (Typ) / 40,000 Hours (Min)

Luminance (Center) – CT = 6500K

Contrast/ Brightness = Max

400 cd/m2 (Typ after 30 minute warm up)

350 cd/m2 (Min after 30 minute warm up)

Brightness Uniformity 75% (Typ) / 70% (Min) Entire Area

Contrast Ratio 450:1 (typ), 250:1 (min)

Color Depth 16 million colors (6+2 bit)

Viewing Angle (Horizontal, CR>10) Minimum: 130º (±65º)

Typical: 135º (+70º/-65º)

Viewing Angle (Vertical, @ CR>10) Minimum: 125º (+65º/-60º)

Response Time

10%-90% @ Ta=25°C

12 ms (Tr= 3.6 ms, Tf = 8.4 ms) (typ)

21 ms (Tr= 6.3 ms, Tf = 14.7 ms) (max)

6. Mechanical

Dimensions

Width 416 mm (16.4 inch)

Height 460 mm (18.1 inch)

Depth 238 mm (9.4 inch)

Monitor Weight 7.5 kg / 16.5 lbs

Ergonomics

Tilt Up From 0º up to ≧20º+/-2º

Tilt Down From 0º down to -3º ~ -5 º

7. Environmental

Environmental Conditions

Operating Temperature 0°C to +40°C

Storage Temperature -20°C to +60°C

Operating Relative Humidity 20% to 90% RH Non-Condensing

Storage Relative Humidity 5% to 90% RH Non-Condensing

Operating Altitude 0 to +3,000 meters

Storage Altitude 0 to +12,000 meters

ViewSonic CorporationConfidential

Do Not Copy VP912s/b

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels ViewSonic Moniteur

ViewSonic

ViewSonic VX2240W - 22" LCD Monitor Manuel utilisateur

ViewSonic

ViewSonic VX3258-PC-mhd Manuel utilisateur

ViewSonic

ViewSonic VS18115 Manuel utilisateur

ViewSonic

ViewSonic VS11425 Manuel utilisateur

ViewSonic

ViewSonic VA903B - 19" LCD Monitor Manuel utilisateur

ViewSonic

ViewSonic E220 - 21" CRT Display Manuel utilisateur

ViewSonic

ViewSonic ViewPanel VA720 Manuel utilisateur

ViewSonic

ViewSonic VG732m Manuel utilisateur

ViewSonic

ViewSonic VP201 Manuel utilisateur

ViewSonic

ViewSonic VA2232wm-LED Manuel utilisateur

ViewSonic

ViewSonic VA930M - 19" LCD Monitor Manuel utilisateur

ViewSonic

ViewSonic VA2223-H Manuel utilisateur

ViewSonic

ViewSonic Optiquest Q191wb Manuel utilisateur

ViewSonic

ViewSonic VS17286 Manuel utilisateur

ViewSonic

ViewSonic VA702-2 Manuel utilisateur

ViewSonic

ViewSonic VX2640W - 26" LCD Monitor Manuel utilisateur

ViewSonic

ViewSonic VA2261-2 Manuel utilisateur

ViewSonic

ViewSonic VG275 Manuel utilisateur

ViewSonic

ViewSonic VS15741 Manuel utilisateur

ViewSonic

ViewSonic VG500 Manuel utilisateur

ViewSonic

ViewSonic E92f+ Manuel utilisateur

ViewSonic

ViewSonic CDP6530 Manuel utilisateur

ViewSonic

ViewSonic EP5542 Manuel utilisateur

ViewSonic

ViewSonic VS17425 Manuel utilisateur

Manuels Moniteur populaires d'autres marques

Linear Acoustic

Linear Acoustic LQ-1000 Manuel utilisateur

AOC

AOC I2579V Manuel utilisateur

Gateway

Gateway FPD1520 Manuel utilisateur

Furuno

Furuno Mu 120c Manuel utilisateur

Asus

Asus VB171D - 17" LCD Monitor Manuel utilisateur

Dell

Dell S2230MX Instructions d'utilisation

Philips

Philips 107C64 Manuel utilisateur

Dell

Dell S2409WFP Manuel utilisateur

EverFocus

EverFocus EN-7517E Manuel utilisateur

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manuel utilisateur

Dell

Dell Precision 7680 Mode d’emploi

LG 50PM1M - - 50" Plasma Panel Manuel utilisateur

Bosch

Bosch DDU 9 Manuel utilisateur

Acer

Acer A231HL Manuel utilisateur

Philips

Philips 86BDL4152T Manuel utilisateur

NEC

NEC AccuSync LCD5V Manuel utilisateur

Emay

Emay SleepO2 Manuel utilisateur

IBM

IBM 6360 Instructions d'installation
