ViewSonic DF88W Manuel utilisateur
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A grounding type plug has two blades and a
third grounding prong. The wide blade or the third prong is provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for long
periods of time.
14) Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has been dropped.
EMC/EMI
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
conditions: (1) This device may not cause harmful interference, and (2) This device must
accept any interference received, including interference that may cause undesired operation.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appreil numérique de la classe B est conforme à la norme NMB-003 du Canada.
Important safety instruction
1
yDigital Photo Frame
yRemote Control
yPower Adapter
yUSB Cable
yQuick Start Guide
yStand
1. LCD
2.
IR Sensor
3. Front frame
4. Transparent decorative frame
5. Power switch
6. Power indicator
7. Navigation button
8. Speaker
9. Enter button
10. Esc button
11. Locker of front frame
12. Stand
13. SD/MMC/MS Pro card slot
14. CF card slot
15. DC-IN jack
16. USB port
Identifying the Parts
Unpacking
EN
2
Remote Control Buttons
Direction Up Down Left/Previous Right/Next
Enter Enters/Opens control bar.
Info Views file properties or accesses the file
management menu.
Rotate Rotates the image clockwise or counter-clockwise by
90º.
Esc Exit
Mute Mute
Zoom Enlarges image.
Volume Adjustment Turns up/down volume.
Unspecified Inactive button, no functionality.
Tip: The remote control range is 5m or less within a +/-45 horizontal and +/-5 vertical angle from the
remote sensor. If the remote's battery is low, the remote may not function properly, so replacing the battery
immediately is recommended.
3
Installing Stand
Insert the stand into the corresponding slot in the back cover and rotate the stand clockwise
until it is locked into place.
Powering It On
Connect the power cable of the attached power adapter to the DC-IN jack of the digital photo
frame and connect the power adapter to the AC power socket.
Turn on the power: When the power switch is OFF, the power is turned off. Move the power
switch to ON to turn on the power or move it to LED to turn on the LED indicators.
Tip: Power input: AC100~240V, 50~60Hz. Power output: DC5V/1.8A. Power consumption: ≤7.5W.
Operating temperature: 0ºC~40ºC. Operating humidity: ≤90%.
Getting Prepared
4
Inserting Cards
yInsert the memory card into the
corresponding slot as shown in the
illustration. If the card is improperly
inserted, it may not function properly.
yIt is recommended to not remove the
memory card when a file is being played.
Tip: This product support several types of memory cards such as SD/MMC, MS Pro, and CF. Since
there are many memory card brands, it is recommended to test whether a card is compatible with this
product. (Note: This product does not support illegal cards) If the card is inserted correctly and the
startup picture is displayed but the card fails to read, it is recommended that you shut down and repower
the unit or reformat the card before writing files onto it.
Turn on the power. After the startup logo is displayed, the startup interface screen is
displayed. The default screen is the calendar.
Calendar
This interface displays calendar, current time,
and current alarm time.
yUse to view the previous/next month,
and use Enter to access the card selection
interface.
Operation
5
Card Select
This interface is used to select the desired
storage device.
yUse to move the cursor.
yUse Enter to access the selected option.
yUse Esc to go back to the calendar interface.
Function Select
This interface is used to select functions.
yUse to move the cursor.
yUse Enter to access the selected option
yUse Esc to go back to the card selection
interface.
Select and press Enter to view the images
in a 9-image thumbnail screen.
yUse to move the cursor to
select image.
yUse Enter to view selected image and start the
automatic slideshow.
yUse Esc to go back to the function selection
interface.
In slideshow mode, all the images in the memory card will be played automatically.
yUse Esc to stop slideshow.
yUse to view the previous image and to view the next image.
EN
6
yUse to access the brightness adjustment
menu. Use to access the volume
adjustment menu.
yUse to adjust parameters.
yUse Enter to confirm the adjustment. Use
Esc to exit.
When browsing the images, use the image control bar to control the playing of images and
use the music control bar to control the playing of music.
yUse Enter to access the image control bar;
use or to switch to the music control
bar. Use Esc to close the control bar.
The figure below shows the image control bar.
Status display
Stop Rotate Zoom
Previous
Next
Image info.
Thumbnails
Play/Pause Image resolution
yUse to select a button on the control bar. Use Enter to confirm the selection.
Status display Displays the play status of the current image (play or
pause).
Play/Pause Play/Pause the image slideshow.
Stop Stops browsing images and returns to the function
selection interface.
7
Rotate Rotates the current image clockwise by 90º.
Zoom Enlarges the current image.
Previous Displays the previous image.
Next Displays the next image.
Image info Displays the properties of the current file.
Thumbnails Previews images in a 9-image screen.
1024×768 Resolution Displays the resolution of the current image.
Tip: This product supports JPEG (baseline) image files within 12 mega pixels.
Music
Select and press Enter to access the
music playing function. After that, the audio file
in the directory will be played automatically.
yUse to activate/deactivate the spectrum
effect.
yUse Esc to go back to the function selection
interface.
yUse to access the volume adjustment
menu.
yUse Enter to confirm the adjustment. Use
Esc to exit.
EN
8
The figure below shows the music control bar.
yUse to select a button on the control bar. Use Enter to confirm the selection.
Status display Displays the play status of the music (play or pause).
00:00:05 Progress Displays the progress of music playing.
Play/Pause Play/Pause the music.
Stop Stops playing music and returns to the function
selection interface.
Previous Plays the previous song.
Fast Rewind Speeds up the music playing backward.
Fast Forward Speeds up the music playing forward.
Next Plays the next song.
File properties Displays the properties of the current file.
ID3 info Displays the ID3 information of the music.
Standard Play mode Press Enter to switch between these play modes:
“standard”, “repeat one” and “Dir repeat”.
Tip: This product supports MP3 audio files (MPEG 1.0 Layer 3, with a sampling rate of 44.1kHz and
a bit rate of 32kbps-320kbps) and WMA audio files (WMA CBR, with a sampling rate of 44.1kHz and a bit
rate of 32kbps-192.kbps).
