Viessmann VITOPLANAR Manuel utilisateur

6136715 GB 7/2018

Installation and

operating instructions

Wireless room temperature controller,

LCD with clock and 7-day program

VITOPLANAR wireless thermostat LCD clock

VIESMANN

6136715

Safety instructions

Please follow these safety instructions closely to prevent hazards,

injury and material losses.

Safety instructions explained

Danger

¨This symbol warns against the risk of injury.

Caution

! This symbol warns against the risk of material losses and

environmental pollution.

Note

Text with the word Note contains additional information.

Installation, commissioning, inspection, maintenance and repairs

must only be carried out by an authorised, competent person

(heating engineer/installation contractor).

Before working on the appliance/heating system, isolate it from the

power supply (e.g. by removing a separate fuse or by means of a

mains isolator) and safeguard against unauthorised reconnection.

Repairing components that full a safety function can compromise

the safe operation of the system.

For replacements, use only original spare parts supplied or

approved by Viessmann.

6136715

Product information

The appliance is a wireless room temperature controller with clock

for capturing the temperature in residential, o󰀩ce and hotel rooms.

Simple to install – no time-consuming chase cutting and plastering

for cable routing. The controller can be installed on a ush mounted

or surface mounted box on the wall. A support arm also enables

freestanding operation. The controller has a freely programmable

7-day program, frost protection function, manual operation and

on/o󰀨 function.

6136715

Installation

6136715

Operating and display elements

AUTO mode

Comfort mode

Setback mode

Frost protection

mode

Set the date and time /

programming

8 96 7

Time

Day

Measured temperature or

set temperature

Current set temperature

Wireless transmission

"Party" mode

Absence mode

Info button

Off mode

Temperature

setting

Standby mode:

After a certain period of inactivity, the thermostat switches to

standby mode. To exit this mode, press a button or turn the

selector switch

6136715

Assigning wireless receivers

6136715

Conguration

The thermostat must be switched off.



Press the second button from the left for 5 seconds.

The thermostat version appears on the display.



Press OK.

Menu CF01 appears on the display.



Select the required setting with + and -.

Press OK to confirm the setting and move to the next setting.

Turn the selector switch to exit the mode.

CF01 – Correction of measured temperature

Adjustable from -5

°C to +5 °C.

xample: If the temperature displayed by the appliance is 19 °C

and the temperature measured (by thermometer) is 20

°C, +1 °C

must be set.

CF02 – Displayed temperature in AUTO mode

0Set temperature

1 Measured temperature

>5s -5 °C -> +5 °C

1 2

Note: The fields with a grey background correspond to the

pre-configured factory settings.

6136715

Conguration (continued)

6136715

Conguration (continued)

CF08 – Open detection function

If the receiver is combined with an open detector (e.g. for a

window), the heating is switched to frost protection mode when

the window is opened.

CF09 – Presence detection function

If the receiver is combined with a motion detector, the temperature

is automatically reduced during long periods of absence:

•

1.5 hours -> current set temperature -1.5 °C

•

3.5 hours -> current set temperature -3.5 °C

•

48 hours -> set frost protection temperature

CF10 – Max. set comfort temperature

justable from 22 °C to 30 °C.

Standard value: 28

°C

CF11 – Programming format

0 Deactivated

1 Activated

0 Deactivated

1 Activated

0 Programming in 1-hourly steps

1 Programming in 1/2-hourly steps
