Viconics VT7600 Series Manuel utilisateur

1 | 028-0228-06 November 2015

CONTENTS

Installation 2

Location 2

Installation 2

Terminal, Identification and Function 4

Wiring 4

Screw terminal arrangement 5

Main outputs wiring 5

Typical applications 6

Remote sensor accessories 7

Configuring and Status Display Instructions 9

Status display 9

User Interface 12

User configuring instructions menu 12

Local keypad interface 12

VT7600 Series

Installation Guide

November 2015

2 | 028-0228-06 November 2015

INSTALLATION

Remove security screw on bottom of Room

Controller cover.

Open unit by pulling on bottom side

of Room Controller (fig. 1).

Remove wiring terminals from

sticker.

Read FCC ID and IC label installed

in the cover.

Location

1. Should not be installed on an outside

wall.

2. Must be installed away from any

direct heat source.

3. Should not be installed near air

discharge grill.

4. Should not be affected by direct

sun radiation.

5. Nothing should restrict vertical

air circulation to Room

Controller.

Installation

1. Swing open Room Controller

PCB to left by pressing PCB

locking tabs (fig. 2).

2. Pull out cables 6” out from wall.

Ensure wall surface is flat and

clean.

3. Insert cable in central hole of

base.

4. Align base and mark location of

two mounting holes on wall

ensuring proper side of base is

up.

5. Install anchors in wall.

6. Insert screws in mounting holes

on each side of base (fig. 2).

7. Gently swing back circuit board

on base and push until tabs

lock.

8. Strip each wire 1/4 inch from

end.

9. Insert each wire according to

wiring diagram.

10. Gently push excess wiring back

into hole (fig. 3).

3 | 028-0228-06 November 2015

11. Re-Install wiring terminals in correct locations (fig. 3).

12. Re-install cover (top side first) and gently push extra wire length back into hole in

wall.

13. Install security screw.

If replacing an existing Room Controller, label the wires before removal

of the Room Controller.

Electronic controls are static sensitive devices. Discharge yourself

properly before manipulating and installing the Room Controller.

A short circuit or wrong wiring may permanently damage the Room

Controller or the equipment.

All VT7000 series Room Controllers are designed for use as operating

controls only and are not safety devices. These instruments have

undergone rigorous tests and verification prior to shipping to ensure

proper and reliable operation in the field. Whenever a control failure

could lead to personal injury and/or loss of property, it becomes the

responsibility of the user / installer / electrical system designer to

incorporate safety devices (such as relays, flow switch, thermal

protections, etc…) and/or an alarm system to protect the entire system

against such catastrophic failures. Tampering with the devices or

unintended application of the devices will result in a void of warranty.

4 | 028-0228-06 November 2015

TERMINAL,IDENTIFICATION AND FUNCTION

Wiring

Multistage

1H / 1C

Heat Pump

Part Number

VT7656B

VT7605B

VT7652B

VT7600B

VT7652A

VT7600A

Part

Number

VT7652H

VT7600H

Schedule

Yes

Schedule

Yes

Top left terminal

block

Top left terminal block

Top right terminal

block

Top right terminal block

O/B

Bottom terminal block

Econo

Aux

DI1

DI2

Scom

5 | 028-0228-06 November 2015

Screw terminal arrangement

Main outputs wiring

Wiring notes:

Note 1: If the same power source is used for the heating stages, install jumper across RC &

RH. Maximum current is 2.0 amps.

Note 2: If auxiliary output is used to toggle occupancy of the electronic control card inside

the equipment, configure the relay parameter (Aux cont) to the N.O. setting. A

second relay can be added for additional functionality of the occupancy output.

Note 3: Economizer output uses a half bridge rectifier. Reference of the control signal is the

common of the power supply of the Room Controller. (Terminal C)

Note 4: Electromechanical contacts are to be used with the digital inputs. Electronic triacs

cannot be used as mean of switching for the input. The switched leg to the input for

the input to activate is terminal C (common)

Note 5: The transformer of the unit provides power to the t Room Controller and the

additional loads that will be wired to the Room Controller.

Scom

O/B

5 pole left top connector

3 pole left top connector

8 pole bottom connector

6 | 028-0228-06 November 2015

TYPICAL APPLICATIONS

VT7656B5X00(X)

2 Heat / 2 Cool / Economizer / With Schedule

VT7652H5X00(X)

Heat pump / Without Schedule

Auxiliary

Heat

System wiring

Jumper J1

Thermostat internal wiring

Compressor

Stage 1

24 VAC

Compressor

Stage 2

Jumper J1

See note 1

(previous

page)

Fan

Remote

Room

Sensor

Field contacts

Reversing

Valve

Digital Input #2

Digital Input #1

Auxiliary

Output

O/B

DI1

DI2

Scom

Remote

Outdoor

Sensor

Remote

Mixed Air

Sensor

Controller Terminals -

VT7652H5x00

DI1

DI2

O/B

Scom

Heat

Stage 2

Cool

Stage 1

System wiring

Thermostat internal wiring

Jumper J1 T1

24 Vac

Cool

Stage 2

Y2 Y1

Jumper J1

See note 1

(previous

page)

Fan

RCG C

Heat

Stage 1

W1RH W2

Auxiliary

Output

Field contacts

Com24V

Remote

Outdoor

Sensor

Digital Input #2

Digital Input #1

Remote

Room

Sensor

0-10 Vdc

EC AU DI1 DI2 RS

Remote

Mixed Air

Sensor

MSScom OS

Controller Terminals -

VT7656B5x00

DI1

DI2

Scom

7 | 028-0228-06 November 2015

Remote sensor accessories

MODEL NO.

DESCRIPTION

S3010W1000

Wall mounted temperature sensor

S3020W1000

Wall mounted temperature sensor+override button and occupancy

status

S2020E1000

Outdoor temperature sensor

S2060A1000

Averaging temperature sensor

S2000D1000

Duct mounted temperature sensor

Remote mount temperature sensors use 10K NTC thermistor.

This sensor can be used for:

Various averaging combinations

Optional occupancy led

Optional override key

Wall mounted sensor

WIRING EXAMPLE OF SINGLE REMOTE ROOM SENSOR:

Scom

Aux

Scom

VT7600 Series

1x S3020W1000

Remote wiring 1 sensor

S2-1 = ON / S2-2 = ON

S3010W1000

Remote wiring 1 sensor

S2-1 = ON / S2-2 = ON

Dip switch

setting for:

1 sensor

S2-1 = ON

S2-2 = ON

8 | 028-0228-06 November 2015

WIRING EXAMPLES OF 2 REMOTE ROOM SENSORS FOR AVERAGING

APPLICATIONS:

WIRING EXAMPLES OF 3 REMOTE ROOM SENSORS FOR AVERAGING

APPLICATIONS:

Notes for averaging applications:

S3010W1000 and S3020W1000

can be mixed matched.

S3010W1000 and S3020W1000

are to be wired in parallel.

Respect the dip switch setting in

each remote sensor.

Scom

Aux

Scom

Aux

Scom

Aux

VT7600 Series

2x S3020W1000

Remote wiring 2 sensors

S2-1 = OFF / S2-2 = ON

Scom

2x S3010W1000

Remote wiring 2 sensors

S2-1 = OFF / S2-2 =

VT7600 Series

1x S3010W1000 and 1x S3020W1000

Remote wiring 2 sensors

S2-1 = OFF / S2-2 = ON

9 | 028-0228-06 November 2015

Temperature vs. resistance chart for 10 Kohm NTC thermistor

ºC

ºF

Kohm

ºC

ºF

Kohm

ºC

ºF

Kohm

ºC

ºF

Kohm

ºC

ºF

Kohm

-40

324.3197

-20

-4

94.5149

32.1910

12.4601

104

5.3467

-39

-38

303.6427

-19

-2

89.2521

30.6120

11.9177

106

5.1373

-38

-36

284.4189

-18

84.3147

29.1197

11.4018

108

4.9373

-37

-35

266.5373

-17

79.6808

27.7088

10.9112

109

4.7460

-36

-33

249.8958

-16

75.3299

26.3744

10.4443

111

4.5631

-35

-31

234.4009

-15

71.2430

25.1119

10.0000

113

4.3881

-34

-29

219.9666

-14

67.4028

23.9172

9.5754

115

4.2208

-33

-27

206.5140

-13

63.7928

22.7861

9.1711

117

4.0607

-32

-26

193.9703

-12

60.3980

21.7151

8.7860

118

3.9074

-31

-24

182.2686

-11

57.2044

20.7004

8.4190

120

3.7607

-30

-22

171.3474

-10

54.1988

19.7390

8.0694

122

3.6202

-29

-20

161.1499

-9

51.3692

18.8277

7.7360

124

3.4857

-28

-18

151.6239

-8

48.7042

17.9636

7.4182

126

3.3568

-27

-17

142.7211

-7

46.1933

17.1440

7.1150

127

3.2333

-26

-15

134.3971

-6

43.8268

16.3665

6.8259

129

3.1150

-25

-13

126.6109

-5

41.5956

15.6286

6.5499

131

3.0016

-24

-11

119.3244

-4

39.4921

14.9280

6.2866

133

2.8928

-23

-9

112.5028

-3

37.5056

14.2629

6.0351

135

2.7886

-22

-8

106.1135

-2

35.6316

13.6310

100

5.7950

136

2.6886

-21

-6

100.1268

-1

33.8622

13.0307

102

5.5657

138

2.5926

CONFIGURING AND STATUS DISPLAY INSTRUCTIONS

Status display

The Room Controller features a two-line, eight-character display. There is a low level

backlight level that is always active and can only be seen at night.

When left unattended, the Room Controller has an auto scrolling display that shows the

actual status of the system.

Each item is scrolled one by one with the back lighting in low level mode. Pressing any key

will cause the back light to come on to high level.

Manual scroll of each menu item is achieved by pressing the Yes (scroll) key repetitively.

The last item viewed will be shown on the display for 30 seconds before returning to

automatic scrolling. Temperature is automatically updated when scrolling is held.

10 | 028-0228-06 November 2015

Sequence of auto-scroll status display:

ROOM

TEMPERATURE

CLOCK

STATUS

SYSTEM

MODE

SCHEDULE

STATUS

OUTDOOR

TEMPERATURE

ALARMS

x.x °C

or °F

XX % RH

Monday

12:00

Sys mode

auto

Occupied

Outdoor

x.x °C or°F

Service

Sys mode

off

Occupied

hold

Frost

Sys mode

heat

Unoccup

SetClock

Sys mode

cool

Filter

Sys mode

emergency

Fan lock

Outdoor air temperature

Outdoor air temperature display is only enabled when outdoor air temperature sensor is

connected.

A maximum range status display of 50 °C ( 122 °F ) indicates a shorted sensor.

Associated functions, such as mode lockouts and economizer function are

automatically disabled.

A minimum range status -40 °C ( -40 °F ) is not displayed and indicates a opened

sensor or a sensor not connected. Associated functions, such as mode lockouts and

economizer function are automatically disabled.

Alarms

If alarms are detected, they will automatically be displayed at the end of the status

display scroll.

During an alarm message display, the back lit screen will light up at the same time as

the message and shut off during the rest of the status display.

Two alarms maximum can appear at any given time.

The priority for the alarms is as follows:

Table des matières

Autres manuels Viconics Contrôleurs

Viconics

Viconics VT8000 Series Manuel utilisateur

Viconics

Viconics VTR8300 Series Manuel utilisateur

Viconics

Viconics VT8000 Series Manuel utilisateur

Viconics

Viconics VT7225 series Manuel utilisateur

Viconics

Viconics VT7600W Series Manuel utilisateur

Viconics

Viconics VT7225 series Manuel utilisateur

Viconics

Viconics VT8000 Series Manuel utilisateur

Viconics

Viconics ZigBee Pro VT8000 Series Manuel utilisateur

Viconics

Viconics VT8000 Series Manuel utilisateur

Viconics

Viconics R851V Series Manuel utilisateur

Viconics

Viconics VTR7300 Series Manuel utilisateur

Viconics

Viconics R851V-4 Manuel utilisateur

Viconics

Viconics VT8000 Series Manuel utilisateur

Viconics

Viconics VT7200 F 5000 B Manuel utilisateur

Viconics

Viconics VTR7300 Series Manuel utilisateur

Viconics

Viconics R850 Series Manuel utilisateur

Viconics

Viconics R820 REV2 Series Manuel utilisateur

Viconics

Viconics R820 REV2 Series Manuel utilisateur

Viconics

Viconics VTR8300 Series Manuel utilisateur

Viconics

Viconics VT7200 Series Manuel utilisateur

Viconics

Viconics VT8600 Series Manuel utilisateur

Viconics

Viconics COV-PIR-FCU-C-5000 Manuel utilisateur

Viconics

Viconics VTR7300 Series Manuel utilisateur

Viconics

Viconics VT76 Series Manuel d'utilisation et d'entretien

Manuels Contrôleurs populaires d'autres marques

Digiplex

Digiplex DGP-848 Mode d'emploi

YASKAWA

YASKAWA SGM series Manuel utilisateur

Sinope

Sinope Calypso RM3500ZB Manuel utilisateur

Isimet

Isimet DLA Series Style 2 Manuel d'installation

LSIS

LSIS sv-ip5a Manuel utilisateur

Rockwell Automation

Rockwell Automation 1769-L31 Manuel utilisateur

Airflow

Airflow Uno hab Manuel utilisateur

ABB

ABB ACS580-01 drives Manuel utilisateur

Panasonic

Panasonic GM1 Series Manuel utilisateur

Emerson

Emerson SW93 Manuel utilisateur

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manuel utilisateur

Panasonic

Panasonic FP? Positioning Unit RTEX Manuel utilisateur

Samson

Samson Type 5824 Manuel de service

Alpha IP

Alpha IP MIOB 21001 Manuel utilisateur

Siemens

Siemens OpenAir GMA 1 Series Manuel utilisateur

Surecom

Surecom SR-629 Manuel utilisateur

Fishman

Fishman TriplePlay Manuel utilisateur

Regulus

Regulus SRS1 T Manuel utilisateur
