Vicon part number 8009-8123-00-03 Section 4 Rev 503
XX123-00-03
AURC-NIU NETWORK INTERFACE UNIT FOR
AURORACORD DIGITAL RECORDER
Copyright © 2003 Vicon Industries Inc. All rights reserved.
Product specifications subject to change without notice.
Vicon and its logo are registered trademarks of Vicon Industries Inc.
Windows is a trademark of Microsoft Corp.
VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788
TEL: 631-952-CCTV (2288) FAX: 631-951-CCTV (2288) TOLL FREE: 800-645-9116
24-Hour Technical Support: 800-34-VICON (800-348-4266)
UK: +44 (0) 1489 566300 WEB: www.vicon-cctv.com
XX123-00-03 Rev 503 Network Interface Quick Installation •
••
•i
Quick Installation
Connections to Install the IPInstaller
ii •
••
•Quick Installation XX123-00-03 Rev 503 Network Interface
Connections for Operation
Standalone
XX123-00-03 Rev 503 Network Interface Quick Installation •
••
•iii
Network
XX123-00-03 Rev 503 Network Interface Introduction •
••
•1
Introduction
The information in this instruction manual covers the installation, programming, operation and maintenance of
the Vicon AURC-NIU Network Interface for the AurorAcorD Digital Recorder. This unit should be installed by a
qualified technician using approved materials in accordance with national, state and local codes. Read these
instructions through completely before attempting installation.
The AURC-NIU is a network interface that allows the AurorAcorD Digital Recorder to be operated from a PC,
using a GUI, over a LAN/WAN (Internet). The AURC-NIU can be accessed by a workstation using Dial Up,
DSL, Cable Modem, ISDN or T1 connections. The Network Interface is normally connected locally to the
AurorAcorD it is controlling via the supplied Remote Control Cable. The Interface is also normally connected
remotely to the PC, or PCs, which will be controlling it via a standard or crossover type Cat5e cable (not
supplied). This results in two basic types of setups, Standalone and Network. The Standalone version is when
the Interface is simply controlled by a single computer via a crossover type Cat5e cable. The Network version
is the installation of the Interface to a LAN or WAN through a network hub or switch. All networked PCs will be
able to control the Interfaces. On a WAN, over the Internet or in any situation where a router is used, the
specific IP address installed into the Interface must be static type followed with an appropriate Gateway
address for communication to take place. Any dynamic IP address installed into the Interface will not provide
access over a WAN. In any case, the specific video of any particular AurorAcorD will be displayed on the PC
that is controlling it.
The provided GUI software allows full control of the AurorAcorD. Therefore, any function or feature performed
at the front panel of the AurorAcorD can be fully replicated on the GUI front panel. (Note: The AURC-NIU does
not transfer audio data.) In addition, any displayed digital video in any particular screen format can be
recorded locally to the PC hard drive or any network drive the PC can access. From there, the video can be
played back as a video segment or still image. Refer to Instruction Manual XX091 for operating instructions for
the AurorAcorD recorder.
Installation
Unpacking and Inspection
All Vicon equipment is tested and inspected before leaving the factory. It is the carrier’s responsibility to deliver
the equipment in the same condition as it left the factory.
Inspection For Visible Damage
Immediately inspect the cartons upon delivery. Make a note of any visible damage on all copies of the carrier’s
freight bill.
Make sure the carrier’s agent (the person making the delivery) signs the note on all copies of the bill. If the
agent does not have claim forms, contact the carrier’s office.
Inspection For Concealed Damage
As soon as possible after delivery, unpack the unit and inspect it for concealed damage. Do not discard the
carton or packing materials. If the unit is damaged, contact the carrier immediately and request forms for filing
a damage claim. Make arrangements for a representative of the carrier to inspect the damaged equipment. If
the equipment must be returned for repair, follow the Shipping Instructions at the end of this manual.
2 •
••
•Installation XX123-00-03 Rev 503 Network Interface
Product Overview
All connections are made on the rear panel. Refer to Figure 1 and Table 1 for connection functions. The side
panel has three LED indicators. Refer to Figure 2 and Table 2 for those functions.
A basic knowledge of Windowsplatform and networking is required to install and operate the unit. Vicon
recommends that the GUI be loaded onto a freshly loaded operating system. Vicon recommends using
Windows 2000, ME or XP operating systems.
Note: Vicon does not recommend using Windows NT or 98SE.
Table 1
Rear Panel Connectors
Connector Name Function
DC12V Power in jack; supplies the power to unit
SERIAL RJ45; connects PC to interface for IP installation and also connects interface to
AurorAcorD for operation
ETHERNET RJ45 (10Base-T/100Base-T) network connector; used for Wide Area Network
(WAN) or Local Area Network (LAN)
PRESET Recessed button; used to restore the factory default settings
IN BNC connector; receives analog video input
OUT BNC connector; transmits analog video output
Figure 1
Rear Panel
Table 2
Side Panel Indicators
Name Function Indication
Ethernet Network
LED Green network status light; indicates network
activity Blinking light indicates data transfer; no
light when no data is transferring
Ethernet Link
LED Yellow link status light; indicates network
connection Solid light indicates physical connection
to Ethernet input on NIU; blinks when
first connected
Power LED Red light; indicates power connection Solid light when power is on; no light
when power is off
Figure 2
Side Panel Indictors
