Network Camera V4.1.0
ES-HNG200I-EI
Installer/User Guide
Vertiv | Network Camera Quick Operation Guide | v01 | UD.6L0201D0146A02
1.0 Physical Description of Camera ....................................................................1
1.1 Camera Description......................................................................................................................1
1.2 Camera Wiring Diagram.........................................................................................................2
2.0 Installation .......................................................................................................... 2
3.0 Setting the Network Camera over the LAN............................................... 7
3.1 Modify device info........................................................................................................................8
4.0 Accessing via Web Browser ........................................................................ 10
CONTENTS
ABOUT THIS DOCUMENT
This manual applies to ES-HND200I-EI series cameras. This manual may contain several technical incorrect places or printing
errors, and the content is subject to change without notice. The updates will be added to the new version of this manual. We
will readily improve or update the products or procedures described in the manual.
DISCLAIMER STATEMENT
“Underwriters Laboratories Inc. (“UL”) has not tested the performance or reliability of the security or signaling aspects of this
product. UL has only tested for fire, shock or casualty hazards as outlined in UL’s Standard(s) for Safety, UL60950-1. UL
Certification does not cover the performance or reliability of the security or signaling aspects of this product. UL MAKES NO
REPRESENTATIONS, WARRANTIES OR CERTIFICATIONS WHATSOEVER REGARDING THE PERFORMANCE OR RELIABILITY
OF ANY SECURITY OR SIGNALING RELATED FUNCTIONS OF THIS PRODUCT.
Save these instructions
This manual contains important instructions that should be followed during installation and maintenance of the Network Bullet
Camera V4.1.0 ES-HNG200I-EI.
Thank you for purchasing our product. If there are any questions, or requests, please do not hesitate to contact the dealer.
0400031020820
1
Vertiv | Network Camera Quick Operation Guide | v01 | UD.6L0201D0146A02
1.1 Camera Description
1.0 PHYSICAL DESCRIPTION OF CAMERA
Figure 1-1 Overview
Figure 1-2 Overview
NOTE: Two types of interfaces of cameras as shown in Figure 1-1 and Figure 1-2. Please choose the right
figure according to the appearance of your camera.
2
Vertiv | Network Camera Quick Operation Guide | v01 | UD.6L0201D0146A02
NO. DESCRIPTION
110M/100M self-adaptive Ethernet interface
2Power supply interface
3IN, G: Alarm input interface
1A, 1B: Alarm output interface
4D+, D-: RS-485 interface
5
AUDIO IN, G: Audio input interface
AUDIO OUT, G: Audio output interface
1.2 Camera Wiring Diagram
Figure 1-3 Wiring Diagram
3
Vertiv | Network Camera Quick Operation Guide | v01 | UD.6L0201D0146A02
2.0 INSTALLATION
NOTES:
Read the following contents carefully before the installation.
Make sure that all the related equipment is power-o during the installation.
Check whether the power supply is matched with your AC outlet to avoid damage.
Do not place the camera in extremely hot or damp environment. To avoid heat accumulation, good
ventilation is required for a proper operating environment. You may refer to the specification of the
product for the detailed information about installation environment.
If the product does not function properly, please contact your dealer or the nearest service center.
Do not disassemble the camera for repair or maintenance by yourself.
The bullet camera can be installed to both wall and ceiling. This quick guide takes wall mounting steps as an
example.
Steps:
1. Use the screws to fix the mounting base to the ceiling; rotate the back box counterclockwise to secure it to
the mounting base; use the lock screw to secure the dome camera.
Lock screw
Figure 2-1 Fix the Mounting Base
4
Vertiv | Network Camera Quick Operation Guide | v01 | UD.6L0201D0146A02
2. Fix the mounting bracket with the camera to the mounting base.
Figure 2-2 Fix the Camera
NOTES:
Please apply water-proof measures between the ceiling surface and mounting base and around the
cables.
For cement wall mounting, you need to use the expansion screw to fix the mounting base. The
mounting hole of the expansion pipe on the wall should align with the mounting hole on the mounting
base.
For wooden wall mounting, you can just use the self-tapping screw to fix the mounting base.
The wall must be strong enough to withstand more than 3 times of the weight of the camera and the
bracket.
NOTE: The “bottom” mark on the mounting base should align with the “bottom” mark on the
mounting bracket.
5
Vertiv | Network Camera Quick Operation Guide | v01 | UD.6L0201D0146A02
3.) View the image of the camera over the network.
4. Loosen the screws on the bracket slightly.
5. Adjust the camera to the desired surveillance angle and then tighten the screws on bracket to fix the camera.
6. Loosen the lock screw on the sun shield and move the sun shield until you can remove it. Remove the sun
shield.
NOTE: The “bottom” mark on the mounting base should align with the “bottom” mark on the
mounting bracket.
Panning screw
Rotation screw
Tilting screw
Figure 2-3 Adjust Monitoring Angle
Figure 2-4 Remove the Sun Shield
6
Vertiv | Network Camera Quick Operation Guide | v01 | UD.6L0201D0146A02
Figure 2-5 Adjust the Lens
7. Rotate to remove the front cover from camera and adjust the lens to get a clear image.
8. Fix the lens; reinstall the front cover and the sun shield to finish the installation.
Figure 2-6 Reinstall the Camera
Adjust the lens
Front
cover
NOTE: Reinstall the front cover until aligning the mark on the front cover with the mark on the
camera.
7
Vertiv | Network Camera Quick Operation Guide | v01 | UD.6L0201D0146A02
3.0 SETTING THE NETWORK CAMERA OVER THE LAN
Steps:
Set the IP address of the camera for accessing via LAN.
Purpose:
To view and configure the camera via LAN (Local Area Network), you need to connect the network camera in the same
subnet with your PC. Then, install the SADP or iVMS-4200 software to search and change the IP of network camera.
The following figure shows the cable connection of network camera and PC:
Figure 3-1 Wiring over LAN
1. To get the IP address, you can choose either of the following methods:
yUse SADP, a software tool which can automatically detect network camera in the LAN and list the device
information like IP address, subnet mask, port number, device serial number, device version, etc., shown in
Figure 3-2.
yUse iVMS-4200 software and to list the online devices. Please refer to the user manual of client software for
detailed information.
2. Change the IP address and subnet mask to the same subnet as of your PC.
Refer to the following introductions to set IP address with SADP software:
ySearch active devices online
Search online devices automatically:
After launch the SADP software, it automatically searches the online devices every 15 seconds from the
subnet where your computer locates. It displays the total number and information of the searched devices in
the Online Devices interface. Device information including the device type, IP address, port number, gateway,
etc. will be displayed.
