Verizon SKU2 Manuel utilisateur
User Guide
Network Adapter SKU2
MAE0340M-D315
1. Inside the box 1
2. Your Network Adapter 3
3. Setting Up Your Network Adapter 6
3.1 Posioning Your Devicer 6
3.2 Setup Requirements 6
3.3 Seng Up 7
4. Login to Your Network Adapter 9
4.1 Connect & Login by Computer 9
5. Web User Interface 11
5.1 Sengs 12
5.1.1 MoCA sengs 12
5.1.2 Device sengs 14
5.1.3 Security sengs 16
5.2 Status 17
5.2.1 Device Status 17
5.2.2 Phy Rates 19
5.3 Advanced 21
5.3.1 Upgrade 21
5.3.2 Reset 22
6. Troubleshooting 24
7. Technical Specification 25
8. Regulatory Compliance Notices 26
https://www.verizonwireless.com/support/ 1
1. Inside the box
Inside the product package you should find the following items. Contact Verizon if any item is missing or damaged.
Network Adapter
Ethernet Cable
Power Adapter
Coaxial Cable * 2
https://www.verizonwireless.com/support/ 2
Wall Mount Screw
Splitter
https://www.verizonwireless.com/support/ 3
2. Your Network Adapter
Your Verizon Network Adapter provides MoCA 2.5 and 2.5G Ethernet port for your devices.
Take a moment to familiarize with your product.
RF port DC port Reset RJ-45 port
https://www.verizonwireless.com/support/
4
Wall Mount
Please follow the steps as below.
Screw Anchor
Wall
Wall
https://www.verizonwireless.com/support/ 5
Reset Button
If you experience difficules with your device or you want to revert all sengs that you have changed, the reset funcon allows you to reset the device
back to its factory default state. Press and hold the reset buon for 10-15 seconds to perform a factory reset (resets all sengs back to factory
defaults).
LEDs
The LEDs indicate the system and connecon status.
Indicator/
Scenario
System
System Off
Power on
MoCA connect
MoCA traffic
10/100M connect
1G/2.5G connect
10/100M connect(traffic)
1G/2.5G connect(traffic)
Off
Yellow
White
White Blinking
Yellow
White
Yellow Blinking
White Blinking
RJ45
Descripon Light type
https://www.verizonwireless.com/support/ 6
3. Setting Up Your Network Adapter
3.1 Positioning Your Devicer
For the best transmission from the device:
-The equipment shall be mounng at heights less than 2 m.
-Keep the device away from direct sunlight.
3.2 Setup Requirements
To configure your network adapter via computer, you need a computer that meets the following system requirements:
-Ethernet RJ-45 (LAN) port (10Base-T/100Base-TX/1000BaseTX/2.5GBASE-T).
-Router(RJ-45 LAN or MoCA LAN).
-An installed TCP/IP service.
-Web browser such as Internet Explorer, Firefox, Safari, or Google Chrome.
https://www.verizonwireless.com/support/ 7
3.3 Setting Up
3.3.1 Use the MoCA Ethernet Adapter as a connector between the coax outlet and your personal devices.
1. Verify the router in your home is connected to a coax outlet.
2. Connect a coaxial cable from the coaxial wall port to the “Data” port of the Network Adapter.
3. Connect the provided splier to your STB and Network Adapter if your service includes a TV subscripon.
4. Connect your laptop, desktop, or game console devices to the “LAN” port of the Network Adapter.
5. Connect the provided power adapter to the Network Adapter.
6. Setup is complete when MoCA connect success and system light turn white.
Coax outlet
Coax outlet Splitter
STB TV
Game console Desktop
Laptop
Home Storage Server
Use splitter to connect STB and Network
Adapter to one coax outlet.
Power Adapter
2.5G Ethernet
1G Ethernet
1G Ethernet
1G Ethernet
1G Ethernet
https://www.verizonwireless.com/support/ 8
3.3.2 Use the MoCA Ethernet Adapter as a connector between your router and your coax outlet.
1. Connect a coaxial cable from the coaxial wall port to the “Data” port of the Network Adapter.
2. Connect the provided splier to your STB and Network Adapter if your service includes a TV subscripon.
3. Connect an Ethernet cable from the “2.5G LAN” port of the Network Adapter to the Ethernet port of the modem/router.
4. Connect your laptop, desktop, or game console devices to the “LAN” port of the Network Adapter.
5. Connect the provided power adapter to the Network Adapter.
6. Setup is complete when MoCA connect success and system light turn white.
Coax outlet
Coax outlet Splitter
STB TV
Game console Desktop
Laptop
Wi-Fi Router
without MoCA
Use splitter to connect STB and Network
Adapter to one coax outlet.
Power Adapter
2.5G Ethernet
1G Ethernet
1G Ethernet
1G Ethernet
1G Ethernet
