USER MANUAL

1. Introduction

To all residents of the European Union

Important environmental information about this product

This symbol on the device or the package indicates that

disposal of the device after its lifecycle could harm the

environment. Do not dispose of the unit (or batteries) as

unsorted municipal waste; it should be taken to a

specialized company for recycling. This device should be

returned to your distributor or to a local recycling

service. Respect the local environmental rules.

If in doubt, contact your local waste disposal authorities.

Thank you for choosing Velleman! Please read the manual thoroughly

before bringing this device into service. If the device was damaged in

transit, do not install or use it and contact your dealer.

2. Safety Instructions

Keep the device away from children and unauthorised users.

Risk of electric shock when opening the cover.

DO NOT disassemble or open the cover. There are no user-

serviceable parts inside the device. Refer to an authorized

dealer for service and/or spare parts.

3. General Guidelines

Refer to the Velleman® Service and Quality Warranty on the last

pages of this manual.

Familiarise yourself with the functions of the device before actually

using it.

All modifications of the device are forbidden for safety reasons.

Damage caused by user modifications to the device is not covered

by the warranty.

Only use the device for its intended purpose. Using the device in

an unauthorised way will void the warranty.

CAMCOLD26/CAMCOLD26W

V. 01 –09/01/2015 4 ©Velleman nv

Damage caused by disregard of certain guidelines in this manual

is not covered by the warranty and the dealer will not accept

responsibility for any ensuing defects or problems.

Keep this device away from extreme heat.

Protect this device from shocks and abuse. Avoid brute force when

operating the device.

Only use this device in compliance with privacy laws and

regulations. Refer to the local authorities for more information.

4. Features

This camera is equipped with a Sony EXMOR CMOS image sensor

and a high performance image DSP. The "EXMOR" high-speed CMOS

sensor has enhanced noise reduction and A/D conversion speed. This

new chipset gives a video signal up to 1000 TV lines. The IR-cut

filter will filter the IR light, so it cannot distort the colour image.

When it gets dark, the camera automatically switches to night mode.

In night mode, the camera enables the IR LEDs and disables the IR-

cut filter.

weatherproof

with B/W night vision (IR LEDs)

super high resolution

vandal-proof housing

special functions via On screen display (OSD) set-up menu:

oshutter/AGC

owhite balance

5. Overview

Refer to the illustrations on page 2of this manual.

mounting plate

varifocal lens

fixation ring

manual focus

positioning ring

light sensor

manual zoom

cable slot

lens enclosure (sphere)

cable

IR night LEDs

CAMCOLD26/CAMCOLD26W

V. 01 –09/01/2015 5 ©Velleman nv

6. Hardware installation

Refer to the illustrations on page 2of this manual.

1. Choose a location for the camera, keeping following guidelines in

mind:

odo not install the camera in locations where extremely high or

low temperatures or excessive vibrations may occur.

oavoid mounting the camera near high electro-magnetic fields.

odo not aim the camera at the sun or other extremely bright

objects or reflections (e.g. metal doors).

2. Hold the mounting plate [1] and unscrew the fixation ring [2] by

turning it counter-clockwise. Note that the lens enclosure [5]and

positioning ring [3] are also released.

3. Use the mounting plate [1] to determine the position of the

mounting holes. Drill the holes.

4. Guide the power and video cable [11] through one of the cable

slots [10] and fix the mounting plate [1] on the ceiling or wall

with the four screws.

5. Position the positioning ring [3] over the lens enclosure [5] onto

the mounting plate [1] and then fix the ensemble by screwing

the fixation ring [2] onto the mounting plate [1]. Make sure the

fixation ring is not screwed too tight to leave the option open to

position the lens into the direction of the desired field of

operation.

6. Connect the video connector [A] to a monitor (not incl.) or a

sequential switcher/quad splitter (not incl.) in case of multiple

domes.

7. Connect the power connector [B] to a 12 VDC power supply (not

incl.).

8. Set up the desired field of observation by adjusting the position of

the lens enclosure [5] in the positioning ring [3].

9. Manually adjust the zoom [4] and focus [8] with their screws.

The location of the screws can be determined by looking at the

position of the light sensor [9].

10.Tighten the fixation ring [2] to secure the camera’s position.

CAMCOLD26/CAMCOLD26W

V. 01 –09/01/2015 6 ©Velleman nv

7. OSD Settings

7.1 Control Buttons

There is a small joystick in the camera cable that allows you to

adjust the settings of the camera using an on-screen display (OSD).

Press and hold the button during

± 2 seconds to access the menu, or press

briefly to select an option.

Press the button upward and downward to

move up and down in the menu.

Press the button to the left and to the right

to modify the menu parameters.

In the OSD menu:

NEXT/BACK: select this option and press the button to go to the

next/previous page of options in the menu.

RETURN: select this option and press the button to return to the

previous level in the menu.

EXIT: select this option and press the button to leave the OSD

menu without saving the settings.

SAVE&EXIT: select this option and press the button to save all

settings.

LOAD DEFAULT: select this option and press the middle button to

reset the camera to the factory defaults.

SOFT VERSION: displays the version number of the camera

software.

The OSD menu settings are described in detail below.

7.2 Noise Reduction

Use this function to switch 3D noise reduction on or off.

Menu: IMAGE > 3D-NR

Select ON to activate 3D noise reduction; select OFF to deactivate.

CAMCOLD26/CAMCOLD26W

V. 01 –09/01/2015 7 ©Velleman nv

7.3 WDR Function

The WDR function (Wide Dynamic Range) optimizes a picture with

extreme backlight. The camera combines two images, one with a fast

shutter speed and one with a slow shutter speed. This function is

useful for a camera oriented towards a strong light source.

Menu: IMAGE > WDR ON

7.4 Automatic Exposure

Use this function to set the exposure method.

Menu: IMAGE > AE MODE

GLOBAL: use the global image to define exposure.

CENTER: use the centre of the image to define exposure.

CENTER WEIGHT: use the global image, but assign more

importance to the centre of the image and less importance to the

edges.

BACK LIGHT: back light compensation. If there is a bright light in

the background, for example from a window, the image around it

may be too dim to see clearly. In that case, use the backlight

function to compensate. The camera automatically brightens the

dim parts of the image.

FRONT LIGHT: front light compensation. Use this setting when

there is a bright light illuminating the front of the image.

DISTINGUISH: for advanced automatic exposure.

7.5 Image Enhancement

These are common adjustments for video images: sharpness,

contrast, and saturation.

Menu: IMAGE > IMAGE ENHANCE

SHARPNESS

Use this option to adjust the sharpness of edges

and details in the image.

DETAIL: use this option to adjust the sharpness of

details in more uniform areas of the image.

AUTO: for automatic adjustment.

MANUAL: for manual adjustment (0–15).

EDGE: use this option to adjust the sharpness of

edges in the image.

AUTO: for automatic adjustment.

MANUAL: for manual adjustment (0–15).

CAMCOLD26/CAMCOLD26W

V. 01 –09/01/2015 8 ©Velleman nv

CONTRAST

Use this option to enhance the image contrast.

AUTO: for automatic adjustment.

MANUAL: for manual adjustment (0–15).

GAIN MAP: advanced contrast adjustment.

SATURATION

Use this function to adjust the colour saturation.

AUTO: for automatic adjustment.

MANUAL: for manual adjustment (0–15).

7.6 Mirror and Flip

Use the MIRROR and FLIP functions to mirror the image or to flip it

upside down.

Menu: IMAGE > TURN > MIRROR

Select ON to mirror the image; select

OFF to keep the image as it is.

Menu: IMAGE > TURN > FLIP

Select ON to flip the image upside

down; select OFF to keep the image as

it is.

7.7 Brightness

Use this option to set the image brightness (0–250).

Menu: IMAGE > BRIGHTNESS

7.8 Day/Night

The camera automatically switches between colour images in day

conditions and black-and-white images in night conditions.

Use this function to control the day/night behaviour of the camera.

CAMCOLD26/CAMCOLD26W

V. 01 –09/01/2015 9 ©Velleman nv

Menu: DAY&NIGHT

AUTO: use this setting for cameras without IR-cut filter, or if you

want to switch the IR-cut filter off during the day. In this case, the

IR light is not filtered during the day, and colours may be

distorted by the IR light.

EXTERNAL: standard setting. The camera uses the IR filter in day

conditions, and switches to a black and white image and switches

off the IR filter in night conditions.

COLOR: the camera always works in colour mode with the IR

filter.

B&W: the camera always works in black and white mode.

7.9 White Balance

Use this menu option to define the white balance adjustment. White

balance makes sure that white objects are always reproduced

correctly.

Menu: WB

The following white balance settings are available: AWB-PRO, AWB-

TEMPORAL, AWB-AI, AWB-SZ, AWB-GW, AWB-CCT.

Defining the optimal setting depends on the illumination conditions of

your particular environment. To find the optimal setting, try each of

the settings and select the one that gives the best results.

7.10 Zone Masking for Privacy

Use this function to block a part of the image where you do not want

to view activity. For example, if part of the image shows a public

area where recording may be illegal. You can define up to 8 areas.

Menu: ZONE MASKING

COLOR

Select black, white or a colour for the mask, or

select MOSAIC for a mosaic effect in the masked

area.

CAMCOLD26/CAMCOLD26W

V. 01 –09/01/2015 10 ©Velleman nv

AREA NO 0–7

To define up to 8 areas. Select the desired area and

use the settings below.

STATUS: select ON to activate the selected

masked area; select OFF to deactivate the

selected masked area.

HORIZON SIZE:

set the width [a]

(in pixels) of the

masked area.

VERTICAL SIZE:

sets the height [b]

(in pixels) of the

masked area.

HORIZON MOVE:

sets the distance

(in pixels) from the

left side of the

screen [c] for the

masked area.

VERTICAL MOVE:

sets the distance

(in pixels) from the

top of the screen

[d] for the masked

area.

7.11 Motion Detection

Use this function to see motion detection during live monitoring. You

can define up to 4 separate areas for motion detection. If the camera

detects motion in an area, the outer edge of that area will ‘flash’.

Menu: DIRECTION

SENSITIVITY

Set the motion detection sensitivity. With a higher

sensitivity, slighter movements will be detected.

Available options for sensitivity: WEAK (weak);

LOW (low); MIDDLE (medium), and HIGH (high).

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Velleman Caméra de sécurité

Velleman

Velleman CAMCOLBBUL16N Manuel utilisateur

Velleman

Velleman CAMZWEXT2N Manuel utilisateur

Velleman

Velleman CAMCOLBUL31 Manuel utilisateur

Velleman

Velleman CAMCOLMHA8 Manuel utilisateur

Velleman

Velleman CAMIP1 Manuel utilisateur

Velleman

Velleman CAMCOLD16H Manuel utilisateur

Velleman

Velleman CAMCOLD5 Manuel utilisateur

Velleman

Velleman EtiamPro ECAMIP601 Manuel utilisateur

Velleman

Velleman CAMCOLD10 Manuel utilisateur

Velleman

Velleman CAMCOLD19 Manuel utilisateur

Velleman

Velleman CAMCOLD16 Manuel utilisateur

Velleman

Velleman CAMCOLBUL28 Manuel utilisateur

Velleman

Velleman CAMSCC3G Manuel utilisateur

Velleman

Velleman CAMTVI7N3 Manuel utilisateur

Velleman

Velleman Etiampro ECAMTVI101 Manuel utilisateur

Velleman

Velleman CAMCOLD7 Manuel utilisateur

Velleman

Velleman CAMCOLBUL2N Manuel utilisateur

Velleman

Velleman CAMCLOPIR Manuel utilisateur

Velleman

Velleman CAMCOLD20 Manuel utilisateur

Velleman

Velleman CAMSCB2 Manuel utilisateur

Velleman

Velleman CAMCOLD Manuel utilisateur

Velleman

Velleman CAMCOLD12 Manuel utilisateur

Velleman

Velleman CAMCOLVC1 Manuel utilisateur

Velleman

Velleman CAMIP15 Manuel utilisateur

Manuels Caméra de sécurité populaires d'autres marques

Okina USA

Okina USA SIR36-870VF650LP Manuel utilisateur

Divio

Divio NDR155PA Manuel utilisateur

Canon

Canon VB-C500D Manuel utilisateur

Easy Access

Easy Access EasyGuard Manuel utilisateur

Vivotek

Vivotek FD9389-EHV-v2 Manuel utilisateur

TUYA

TUYA COSMO W2 Manuel utilisateur

Eusso

Eusso UNC7500-IR Guide de configuration

urmet domus

urmet domus 1096/204 Manuel utilisateur

VC VC20 series Manuel utilisateur

Axis

Axis Q1614 Manuel utilisateur

ieGeek

ieGeek DD201 Manuel utilisateur

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manuel utilisateur

Vicon

Vicon V662-D-1 Mode d'emploi

Grundig

Grundig GCH-K0274P Manuel utilisateur

Lorex

Lorex VANTAGE LBC7032 Manuel utilisateur

4xem

4xem WPT Manuel utilisateur

Samsung

Samsung SCV-3082 Manuel utilisateur

Vitek

Vitek VTC-C544 Manuel utilisateur
