VEKOOTO N92 Mode d'emploi
Let Vekooto be your eyes! ---VEKOOTO
1
Operating Instructions & Installation Guide
N92
Backup Camera with 9”Monitor and DVR
Before Operating This Set
Please Read These Instructions Completely
USER MANUAL
Thank You for Buying VEKOOTO Product.
Read This User Manual Before Installing and Using It.
Pls keep this instruction or write down our email Vekooto@outlook.com
So you can find us once you have any question.
You are Always the First for us.
Let Vekooto be your eyes! ---VEKOOTO
2
Let Vekooto be your eyes! ---VEKOOTO
3
Monitor introduction
The user can perform the manipulation of the guest power segment on
the display parameters through the following nuclear health operations.
①MODE: Confirm / Select button
②V1V2: Switch channel
③- : Increase button
⑤M: Menu / Return button
④+ : Decrease button
⑥POWER: Turn On/Off button
⑦IR: IR Connector
Let Vekooto be your eyes! ---VEKOOTO
4
1. Remote Controller introduction
(1).Standby: Power ON/OFF
(2).Video Select: Channel switch
(3).Menu: Go in setting page
(4).Mode Select: Turn on / off recording
(5).Function Down: Reduce when in setting page
(6).Function Up: Increase when in setting page
Note: Button cell model: CR2025 3V
2. Wiring instructions
Connect with backup lights
To 12-35V Power source -
To 12-35V Power ACC
To 12-35V Power source +
Let Vekooto be your eyes! ---VEKOOTO
5
3. The wiring method when product use, as follows:
(1) Connect Yellow wire to positive power(12-35V).
(2) Connect Red wire to ACC.
The red wire is connected to the car ignition wire ACC switch
(which is the gear switch before starting up the car’s motor),
when the car key is turned on, the device will start automatically,
and if the vehicle key is turned off, it will automatically turn off.
(3) Connect Black wire to negative power / Ground / Sheet Metal
(4) Connect Blue wire (CH2 trigger) to reversing light.
4. The wiring method when product test, as follows:
(1) Connect Yellow wire and red wire together to the positive power
(12-35V).
(2) Connect Black wire to Ground.
(3) Ignore Blue color trigger wires.
* Before installing it by professional person, please test it if works well,
like image display, just in case and save your precious time. Please
contact us if you have any question anytime, our email is
Vek[email protected]om
Note:
1) Before connecting, you need to confirm that the voltage of the battery
is between 12 - 35V.
2) After connecting the wires, pay attention to the insulation between
the power cables to prevent.
the power cables from short-circuiting the battery.
3) The yellow wire must be connected to the ignition wire, otherwise the
device will not support the ignition switch.
4) When you install the 4pin cable,please target every pin to the hole,
avoid breaking the pin.
Let Vekooto be your eyes! ---VEKOOTO
6
5. About Trailer installation
If you need to extend the cable for your trailer, please tell us via our
email: Vekooto@outlook.com
So we can send the extend cable for you, then you can extend it as the
attached picture below shows, and you can disconnect them by Rotating
the button of cable. And please tell us how much cable you need and
how many feet you need. Email us your Amazon Order ID# :
1.The original 33/65ft cable 2.The extend 4 pin cable
we want to send
Let Vekooto be your eyes! ---VEKOOTO
7
6. How to install the monitor and camera:
① Install the monitor (Ceiling bracket)
Ceiling bracket
② Install the monitor brackets
③ Install the camera
Let Vekooto be your eyes! ---VEKOOTO
8
7. Basic Function
7.1 Time Setting Time
(1). Loop Video: 1/3/5/10min
(2). Format: Format the TF card content and system.
7.2 Picture
Let Vekooto be your eyes! ---VEKOOTO
9
7.3 Playback
Press the button Press Press
twice choose AHD1 or AHD2
7.4 Split Setting
Press button to switch between 4 split modes.
7.5 Function
Press the button Press Turn On or Off Mirror
Let Vekooto be your eyes! ---VEKOOTO
10
8. MENU FAQ
(1). How to return interface while viewing the Video List?
A. Press the M/V1V2 button, then it can back to the monitor page.
At other time, press the Menu button to go back the monitor page.
(2). How to rotating the image?
A. Menu-Setting "Rotate" or Function "CH1 Mirror/CH2 Mirror".
(3). How to record video?
A. Press the "MODE" button, then the red point will come that means
the monitor recording.
(4). What is the function of Trigger wire？
A. If you connect the trigger line to the reversing light, the screen will
automatically switch to the camera that connected to the reversing light
when you reverse. You don't need to manually switch to the camera
channel.
(5). How to find the TF card video on the computer？
A: Plug and play. Use a card reader that can read and plug it into your
computer.
(6). How to solve the problem of "no signal/ black screen"?
A. Make sure the camera system can get the power 12-35 V.
Check the camera that if get power?
Please check the wire connection and sure it's tight and right, especially
the power cable. Check the pins of the cable of the monitor and 4 pins
cable of the camera.
If awkward, broken, aligned. Contact us in time, we will help you solve it.
Email:Vekooto@outlook.com
