LVP605 series quick use guide

The quick use guide is for user can learn how to use LVP605 series LED HD video processor

quickly, about further setup,performance and operating method of LVP605, please refer

“LVP605 User’s Manual”.

Frontal\Rear panel introduction

Frontal panel introduction Rear panel introduction

○

1LCD screen (displays parameters ○

7AC power jack and switch

and information) ○

8Extended input port (optional)

○

2Input signal select ○

9DVI loop

○

3Parameter setup ○

10 Sending card slots(cards are optional)

○

4PIP/POP and text overlay ○

11 External audio input and output ports

○

5VGA auto ○

12 RS232 control ports

Add: Room B, 5 th Floor, Bldg. C, Tongfang Information Harbor, Nanshan Hi-tech Park, Nanshan District,

Shenzhen, China

Tel：+86-755-2675 0210 Fax：+86-755-2675 0185 Web：www.videowall.cn

LVP605 series quick use guide

○

6Other functions (switching effect select, ○

13 Signal input ports

Information display, freeze etc.) ○

14 DVI/VGA output ports

LVP605 supports 10 channels of video input, as below:

Note: EXT. extended port, 1 VIDEO for LVP605, 1 SDI/HD-SDI for LVP605S, 1 VGA/DVI/HDMI for

LVP605D.

Step 1: Sending card installation

LED Sending Card can be installed in PCI slot of Desktop Computer, also can be installed in

LVP605.

How to install Sending Card to LVP605:

1 ) Turn off LVP605’s power, and pull out power cable.

2 ) Open LVP605’s surface cover, take down the separation blade of Sending Card of LVP605.

3 ) Unscrewing six angle screw of Sending Card, take down the separation blade of Sending Card.

4 ) Assembling Sending Card in right location of LVP605, screw down all screws.

5 ) Connect +5V power cable, put LVP605’s surface cover back as original.

Step 2: Input and output signal connection

1 ) All devices you need to operate should be power off.

2 ) The output port of all players connect to relevant input port of LVP605, for example:

PC Graphic Card’s DVI output port connects to LVP605’s DVI input port.

Camera’s AV output port connects to LVP605’s V1, V2 or V3 input port.

3 )LVP605’s DVI output port connects LED Sending Card’s DVI input port.

4 ) Sending Card’s net cable connects to Receiving Card.

Port

Description

V1,V2,V3

3 composite videos input (PAL/NTSC )

S-Video

1 Y/C separation video input (PAL/NTSC )

YPbPr

1 HD component video input

VGA1,VGA2

2 computer analog video input

DVI

1 DVI digital video input

HDMI

1 high definition multimedia video input

EXT.

1 extended port input

Add: Room B, 5 th Floor, Bldg. C, Tongfang Information Harbor, Nanshan Hi-tech Park, Nanshan District,

Shenzhen, China

Tel：+86-755-2675 0210 Fax：+86-755-2675 0185 Web：www.videowall.cn

LVP605 series quick use guide

Input = DVI

1080p_60Hz

Cut

5 ) LVP605’s VGA output port connects Displayer as monitor.

Step 3: Power on starting up

1 ) Make sure all of the input and output ports connect correctly.

2 ) Let LVP605 get power and open power switch.

3 ) Then let all devices of signal source power on.

Step 4: Input signal selection

After LVP605 starting up, the LCD on frontal panel will display some

information.

1 )The first line: the input signal you currently choose,

for example : “Input = DVI”.

2 ) The second line :the status of current input signal source, if no input display “No Input”,

meantime the indicator light on relevant input key is flashing, LED screen and displayer is blank

screen;

if the signal is valid displaying the format of current input signal, for example “1080p_60Hz”.

3 )The third line: the effect of signal switch, for example Cut,Fade=(0.5s 1.0s 1.5s) or Blend.

At this time press input signal key, relevant input signal source can be switched.

Step 5: Output resolution setup

After LVP605 starting up normally (PIP and Mosaic is closed)

1 ) Press Setup key, then press Knob (Save key), LVP605 enters setup menu.

The first option: Language

2 ) Rotate Knob can choose “Chinese” or “English”, press Knob (Save key) to save.

3 ) Press ↑ key to the second option of setup menu Output_Format, rotate Knob to modify output

resolution. The output resolution must be bigger than the actual resolution of LED Screen,

press Knob to save,

4 ) The Video processor will remind you to restart, as you are told turn off it then reopen.

LVP605 supports customized resolution, meantime need to meet 4 conditions 1. Maximum

Add: Room B, 5 th Floor, Bldg. C, Tongfang Information Harbor, Nanshan Hi-tech Park, Nanshan District,

Shenzhen, China

Tel：+86-755-2675 0210 Fax：+86-755-2675 0185 Web：www.videowall.cn

LVP605 series quick use guide

width 3840; 2. maximum height 1920; 3. field frequency 23—80HZ; 4. ((width+184) * (height+45) *

field frequency )< 164999000.

Step 6: Setting output width and height of image

After restarting LVP605

1 ) Press Setup key then press Knob (Save key)to enter first option of setup menu, press ↑ key to

setup option of Out_Hori_Width, rotate Knob to modify the width value, which must be as

same as the width (pixel) of LED Screen, press Knob to save;

2 ) Press ↑ key to setup option of Out_Vert_Height, rotate Knob to modify the height value,

which must be as same as the height (pixel)of LED Screen, press Knob to save.

3 ) LVP605’s basic setup is finished, press Setup key again to exit setup.

Step 7: Computer resolution setup

1 ) Entering the control panel of computer Graphic Card, in this option of

Setting multi-displayer, select “Copy mode” ,“Extend mode” or “double display mode” etc.

2 ) In Modify resolution, setting displayer LVP605’s resolution as same as the resolution you have

set in step 5. At this time LVP605’s LCD displays current output resolution of Computer

Graphic Card.

Step 8: full\part display (Bypass)

1 ) Selecting DVI input, make sure the input and output resolution of LVP605 are same.

2 ) Press Bypass key, the indicator light on the key light up, LED Screen’s display status is part,

picture on LED Screen is normal, no compression;

3 ) Press Bypass key, the indicator light on the key doesn’t light up, LED Screen’s display status is

full, the whole picture is compressed to LED Screen for displaying.

Step 9: Open PIP/POP function

Add: Room B, 5 th Floor, Bldg. C, Tongfang Information Harbor, Nanshan Hi-tech Park, Nanshan District,

Shenzhen, China

Tel：+86-755-2675 0210 Fax：+86-755-2675 0185 Web：www.videowall.cn

LVP605 series quick use guide

1 ) In the display status of single picture, press signal key to choose signal as background.

2 ) press PIP/POP ON/OFF key, the LCD on panel will remind you PIP=?

3 ) At the moment press signal key to choose signal for PIP/POP.

4 ) When PIP/POP is open, press PIP ON/OFF key to exit the function.

5 ) LVP605 can save 4 different PIP/POP modes, press mode key M1 M2 M3 M4 to choose.

Step 10: Setting PIP/POP parameter

1 ) When PIP/POP is in open status, press mode key M1 M2 M3 M4 to save setup parameters to

the mode.

2 ) Press Setup key, then press knob(save key), LVP605 enters setup menu of PIP/POP.

3 ) Press ↑ key to set 4 parameters of background separately, rotate Knob to modify the 4

parameter values of background.

Main_Hori_Width Main_Hori_Start

Main_Vert_Height Main_Vert_Start

4 ) Press ↑ key to set 4 parameters of PIP/POP , rotate Knob to modify the 4 parameter values of

PIP/POP

PIP_Hori_Width PIP_Hori_Start

PIP_Vert_Height PIP_Vert_Start
