Vax Quicklite VRS107 Instructions d'installation

vax.co.uk

VRS107/VRS1071/VRS1072/

VRS108/VRS1081/VRS1082

Quicklite

Let’s get started

Let’s talk safety

Basic

safety

precautions

This vacuum cleaner is intended for household use only and

NOT for commercial or industrial use.

• Only use the vacuum cleaner indoors on dry surfaces and

keep the area you’re cleaning well lit.

• Keep ngers, hair and loose clothing away from moving parts

and openings whilst using the vacuum cleaner.

• This vacuum cleaner can be used by children aged from

Don’ts

• Don’t use the vacuum cleaner if it has been dropped,

damaged or left outdoors.

• Don’t run over the power cord or use vacuum cleaner if the

power cord or plug is damaged. Please contact our Customer

Care Line on: 0330 026 8455 (Mon-Fri 8:30am to 6:30pm,

Sat 9:00am to 5:00pm).

• Don’t handle the plug or use the vacuum cleaner with wet hands.

• Don’t pull or carry the vacuum cleaner by the power cord.

• Don’t use the power cord as a handle, pull the power cord around

corners, sharp edges or close a door over the power cord.

• Don’t unplug the vacuum cleaner by pulling on the power cord.

• Don’t vacuum up hard or sharp objects such as glass, nails,

screws or coins etc.

Do’s

• Turn o all controls on the vacuum cleaner before

disconnecting or connecting the plug from the mains socket.

• Always keep the power cord away from the brushes during

use. After use always wrap the power cord around the cord

clips provided.

• Always make sure both the pre-motor/post-motor lters are

in place before use.

• Always ensure the brushbar is switched o when using

the vacuum cleaner on the stairs and take extra care when

positioning the vacuum cleaner on the stairs.

• Always switch o the vacuum cleaner before disconnecting

or connecting the hose and accessories.

8 years and above and persons with reduced physical, sensory or mental

capabilities or lack of experience and knowledge if they have been given

supervision or instruction concerning use of the vacuum cleaner in a safe

way and understand the hazards involved. Children shall not play with the

vacuum cleaner. Cleaning and user maintenance shall not be made by

children without supervision.

• Only Vax recommended tools should be used with the vacuum cleaner,

use of non-branded Vax accessories/tools will invalidate your warranty.

• Don’t vacuum up any ammable or combustible materials (lighter uid, petrol,

kerosene etc) or use the vacuum cleaner in an area with explosive vapours

or liquid.

• Don’t vacuum up hot coals, cigarette butts, matches or smoking hot burning

items or use in an area where there may be harmful uids (chlorine, bleach,

and ammonia drain cleaner).

• Don’t attempt to remove blockages with sharp objects as this may cause

damage to the vacuum cleaner, remove blockages only as instructed in

this guide.

• Don’t use the vacuum cleaner with incorrect voltage as this may result in

damage or injury to the user. The correct voltage is listed on the ratings label.

• Keep all openings clear and free from debris as this may aect the

airow/suction.

• Always replace the fuse in the plug with a British 13amp fuse.

• Always protect the power cable from heated surfaces and open ames.

• Use only CE approved 13amp extension cords, non-approved extension cords

may overheat. Care should be taken to arrange the extension cord as it can be

a trip hazard.

• Store the vacuum cleaner in a cool, dry area. If the lters have been cleaned

as per user the guide instructions ensure they are thoroughly dry before

storing away.

PLEASE KEEP INSTRUCTIONS FOR FURTHER USE AND USE ONLY

AS INSTRUCTED IN THIS GUIDE

Thank you for buying this Quicklite.

Taking care of your carpets and hard oors

The Quicklite is designed to make vacuuming carpets and hard oors regularly, as eective

and ecient as possible and this user guide will help you get the most out of your machine.

Maintaining your carpets and hard oors will ensure they keep their appearance for longer.

You’ve chosen the carpets and hard oors for your home for a reason and Vax will help you

take good care of them.

Taking care of your Quicklite

Also inside this guide are instructions on maintaining your new machine, so that it’s always

ready when you are to tackle your carpets and hard oors.

Let us know what you think @VaxUK

Taking care of you

We’re here if you need us. Instead of taking me back

to the shop, simply visit:

vax.co.uk/support or call:

(UK) 0330 026 8455 (ROI) 1-800 928 308

Monday-Friday 8:30am to 6:30pm, Saturday 9:00am to 5:00pm

Calls are charged at the UK local rate. Please make a note of the serial number and model number

of the product before calling.

Alternatively, you can write to us at:

Vax Ltd, Plot 302, Stonebridge Cross Business Park, Hampton Lovett, Droitwitch, WR9 OLW, UK

This User Guide can be found online at: vax.co.uk/support

Contents

Let’s talk safety

Getting to know your machine

Getting started

Using your machine

Taking care of your machine

Let’s talk technical

Accessories

What to do if it goes wrong

Getting in touch

Quicklite

(Included with all models)

2-in-1 crevice tool

and dusting brush

Included with

your machine

Quicklite Pet

TurboTool holder

TurboTool

TurboTool connector

Hard oor adaptor

Initial Setup for normal operation

1. Use the base accessories.

– Shortest hose

– Extension tube set to shortest practicable length.

2. Clean lters installed.

3. Dust receptacle empty.

4. All Bleeds must be closed.

5. Floorheads/tools set to Carpet Mode for carpet cleaning.

6. Mechanical Agitation set turned ON for carpet cleaning.

7. Floorheads/tools set to Hard Floor Mode for hard oor cleaning.

8. Mechanical Agitation set turned OFF for hard oor cleaning.

Getting to know your machine

Handle

Hose

Cord wraps

Cord guide

Hose guide

Carry handle

2-in-1 crevice tool and

dusting brush

Separator

Dirt container

On/O button

HEPA lter

(hidden)

Brushbar height adjuster

Hard oor adaptor

Technical Specication

Name Quicklite

Voltage Please refer to product rating label on machine

Wattage Please refer to product rating label on machine

Capacity 2.4L

Cord length 7m

Weight 4.7kg (dependant on model)

Subject to technical change without notice.

Accessories & Consumables

Filter Kit (Type 94)*

1-1-134293-00

Belt Kit (Type 17)*

1-1-132048-00

TurboTool (Type 6)*

1-1-134419-00

*To purchase consumables and accessories, please visit vax.co.uk

Getting started

*To purchase consumables and accessories, please visit vax.co.uk

Getting started

CAUTION: Always switch o the vacuum cleaner before connecting or disconnecting the hose/attachments,

or removing and emptying the dirt container.

IMPORTANT: The vacuum cleaner is equipped with a thermal cut-out. If for any reason the vacuum cleaner

does overheat the thermostat will automatically turn the vacuum cleaner o. If this happens, switch the

vacuum cleaner o and unplug. Remove and empty the dirt container also check the vacuum cleaner for

blockages. Allow the vacuum cleaner to cool for approximately 1 hour (if you have cleaned the lters please

wait 24 hours for the lters to fully dry before putting back into the machine). If the vacuum cleaner is blocked,

switch o and unplug before removing the blockage.

Assembling your vacuum cleaner

Using a crosshead

screwdriver, remove the

screw from the back of

the vacuum cleaner.

Slide the handle down

into the main body of the

vacuum cleaner.

Return the screw and

tighten, securing the

handle into the main body

of the vacuum cleaner.

Wrap the hose over the

hose guide. Line up tabs

on the lower hose

connector with the tabs

in the lower hose entry

point. Twist connector

clockwise and lock

into place.

Line up tabs on the upper

hose connector with the

tabs in the upper hose

entry point.

Twist connector clockwise

until clicks and locks

into place.

Attaching the TurboTool holder and TurboTool (Quicklite Pet only)

Line up TurboTool

holder with handle,

push TurboTool holder

onto handle until clicks

into place.

Line up TurboTool brush

into TurboTool holder,

push until it clicks

into place.

Place the 2-in-1 crevice tool

and dusting brush into the

tool holder.

Using your machine

Turn brushbar height

adjuster dial to

desired setting.

Plug vacuum cleaner into

the mains, switch on.

Use the hard oor adaptor for best results on hard oors.

The hard oor adaptor can be used on any oor setting on the height adjuster dial.

Place foot on oorhead

and pull handle

backwards to recline.

Press the On/O button

to switch on.

Using the hard oor adaptor

Lie the vacuum cleaner

on its back exposing

the brushbar.

Line up hard oor adaptor

with base of vacuum

cleaner. Push adaptor

onto base, until it clicks

into place.

To make sure the hard oor

adaptor is correctly tted,

the wheels on the adaptor

should be at the back when

attached to vacuum cleaner.

TIP

Using your machine

Choose an accessory.Twist lower hose

connector anti-clockwise

to unlock. Pull and

remove lower hose.

To use the dusting brush, press the tab and slide the dusting brush

forwards until it clicks into place.

Hold vacuum cleaner with brushbar over tread of stairs.

Use the hard oor adaptor for best results on hard oors. The hard oor adaptor can be used on any oor setting

on the height adjuster dial.

Attach TurboTool

connector to hose before

attaching TurboTool

(some models only).

Attach accessory to hose.

Using accessories

Using on the stairs

2-in-1 crevice tool and dusting brush

IMPORTANT: Always switch o the vacuum cleaner before disconnecting or connecting the hose and

accessories. The accessories can be attached directly to the hose. This vacuum cleaner is tted with a

constantly rotating brushbar. To avoid damage to your ooring, ensure the brushbar is raised to the highest

setting when using the accessories.

CAUTION

This vacuum cleaner has a

constantly rotating brushbar.

When cleaning on stairs raise

the height adjuster dial to the

highest setting. The brushbar

must over hang the stair tread.

Always take extra care when

cleaning stairs.

Taking care of your machine

IMPORTANT: The motor is equipped with a thermal cut-out. If for any reason the machine should overheat,

the thermostat will automatically turn the machine o. Switch o and unplug the vacuum cleaner. Check the

machine for blockages and clean the lters. Wash the lters with warm water (40°C max) and leave for 24

hours or until fully dry before replacing into the machine. Filters require cleaning at least every 3-6 months

(depending on the level of use). Don’t use your vacuum cleaner without all of the lters in place.

Emptying the dirt container

Press the dirt container release

button, pull and remove

dirt container.

Hold the dirt container over a bin.

Pull the dirt release clip, allowing

dirt/debris to fall out.

TIP

Don’t over ll the dirt container

to avoid blocking the air ow

through the vacuum cleaner

and replace lters every

6-9 months.

Ce manuel convient aux modèles suivants

Autres manuels Vax Aspirateur

Vax

Vax VEC-31 Manuel utilisateur

Vax

Vax TBTSV1B1 Manuel utilisateur

Vax

Vax C86-TOe Series Instructions d'installation

Vax

Vax C85-AA-Be Manuel utilisateur

Vax

Vax AirPetVCAP1500 Manuel utilisateur

Vax

Vax Rapide Plus 5140 Fiche d'information produit

Vax

Vax W91-RS-B SERIES Manuel utilisateur

Vax

Vax U90-P4 SERIES Manuel utilisateur

Vax

Vax Essentials VEU-01 Manuel utilisateur

Vax

Vax Force 10 Cyclonic VZL-401CSP Manuel utilisateur

Vax

Vax MachAir UCA1GEV1 Manuel utilisateur

Vax

Vax VaxAIR VCAB1500 Manuel utilisateur

Vax

Vax U88-AMMe Series Air3 MAX Manuel utilisateur

Vax

Vax Mach3 U90-M3 series Manuel utilisateur

Vax

Vax tornado UC990B Manuel utilisateur

Vax

Vax WASH Vax V-020 Series Manuel utilisateur

Vax

Vax 6121 Multivax Manuel utilisateur

Vax

Vax action 802 U86-AB-Be Fiche technique

Vax

Vax Washvax V-020 Series Instructions d'installation

Vax

Vax Turbo Force Lite VS-19TLT Manuel utilisateur

Vax

Vax Impact 302 C86-ID-Pe Manuel utilisateur

Vax

Vax Essentials VEC-01 Manuel utilisateur

Vax

Vax 6121 Multivax Manuel utilisateur

Vax

Vax W86-DP-R Instructions d'installation

Manuels Aspirateur populaires d'autres marques

Bissell

Bissell LittleGreen Proheat 1425 Series Manuel utilisateur

Panasonic

Panasonic MC-YL637S147-AE Manuel utilisateur

NEFF

NEFF N17XH10 0 Series Manuel utilisateur

LG A9 Series Manuel utilisateur

Oreck

Oreck Cordless Captura BK51700 Series Manuel utilisateur

Kogan

Kogan KAVACROBVWA Manuel utilisateur

Kränzle

Kränzle VENTOS 50 ID Guide de l'utilisateur

EVVO

EVVO Ai35 Manuel utilisateur

DeWalt

DeWalt DWH200D Manuel utilisateur

Pontec

Pontec Pondomatic Vacuum Cleaner Manuel utilisateur

Cleanmaxx

Cleanmaxx PC-P007E Manuel utilisateur

Exido

Exido 240-114 Manuel utilisateur

RIDGID

RIDGID WD1685AU0 Manuel utilisateur

Ezviz

Ezviz RE4P Manuel utilisateur

STG global

STG global TANVAC HDV3000 Manuel utilisateur

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Manuel utilisateur

Factory

Factory M3340 Manuel utilisateur

Shop-Vac

Shop-Vac VN92 SERIES Manuel utilisateur
