VarTech Systems VT121CC Manuel utilisateur

VT121 ColorVue Series User Guide 150-033

VT121 ColorVue Series

12.1” Flat Panels

VT121CC · VT121PC

VT121RC · VT121WC

VT121PCQ

User’s Guide

Read these instructions completely before attempting to operate your new Color Display.

VarTech Systems Inc.

Solutions for Demanding Applications

Industrial CRT and Flat Panel Displays

VT121 ColorVue Series User Guide 150-033

Table Of Contents

Page Page

Section 1 Section 7

Warnings and Cautions 1 The Display Controls 8

7.1 Display Controls 8

Section 2 7.2 Screen Adjustment Operation Procedure 8

FCC Statement 2

Section 8

Section 3 The Screen Adjustment 9

Product Safety Precautions 3 8.1 Main Menu 9

8.2 OSD Adjusting and Controls 10-11

Section 4 8.3 How to use Autotune Adjustment 12

Hardware Installation 4

4.1 Unpacking 4 Section 9

4.2 Installation 4 Troubleshooting Tips 13

4.3 Video Input Pin Assignment 5

Section 10

Section 5 Cleaning & Maintenance 14

Touch screen 6

5.2 Touch Screen Definition 6 Mechanical Drawings 15

12.1” Panel Mount 16

5.1 Touch Screen Introduction 6 Section 11

Section 6 12.1” Rack Mount 17

The Display Timing 7 12.1” Wall Mount 18

Table 6.1 VESA Modes 7 12.1” Chassis Mount 19

Table 6.2 IBM Modes 8 12.1” Quad Panel 20

Table 6.3 Mac Modes 8

Section 12

Specifications 21

VT121 ColorVue Series User Guide 150-033

WARNING

TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS MONITOR TO

RAIN OR MOISTURE.

“HIGH VOLTAGE EXISTS ON THE BACKLIGHT POWER LEAD OF THIS MONITOR.

BEFORE SERVICING, DETERMINE THE PRESENCE OF HIGH VOLTAGE BY

CONNECTING THE H.V. METER BETWEEN THE BACKLIGHT POWER LEAD AND

CHASSIS ONLY.”

CAUTION

1. Keep monitor away from excessive dust, high temperature, moisture or

direct sunlight.

2. Use in well ventilated area and do not cover ventilation openings.

3. Unauthorized modifications of this equipment or substitution or

attachment of not shielded connecting cable may cause excessive

interference.

4. When the monitor is not in use for a long time, turn off power switch.

CAUTION: To reduce the risk of electric shock, do not remove cover

(or back). No user serviceable parts inside. Refer servicing to

qualified technician.

RISK OF ELECTRIC SHOCK!

DO NOT OPEN!!!

WARRANTY VOID IF CASING IS

REMOVED.

WARNINGS AND CAUTIONS

Section

VT121 ColorVue Series User Guide 150-033

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to

Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

Interference in a industrial installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause harmful interference to

radio communications. However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient/Relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

• Consult the dealer or an experienced radio or TV technician for help.

CAUTION: Changes or modifications not expressly approved by the manufacturer responsible for

compliance could void the user's authority to operate the equipment.

DOC Compliance Notice

This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus set

out in the Radio Interference Regulations of the Canadian Department of Communications.

Federal Communications Commission (F.C.C.) Statement

FCC STATEMENT

Section

VT121 ColorVue Series User Guide 150-033

⇒ Ensure that sufficient space is available around the display to provide the circulation

necessary for cooling.

⇒ Ensure that the ambient air temperature will not exceed the specified maximum

temperature.

⇒ Do not attempt to service this display yourself. The rear chassis has a seal so that non

qualified personal will not expose themselves to dangerous voltages or other risks.

⇒ To protect from electrical shock, unplug the display power supply from the wall before

moving.

⇒ Do not expose the display to direct sunlight or heat.

⇒ Do not use this display near water

⇒ Do not place any heavy objects on the power cords. Damage may cause electrical

shock.

⇒ Unplug the power supply from the wall or unit if one of the following conditions exists.

⇒ Power cord or plug is damaged or frayed

⇒ Liquid is spilled into the display or the display is exposed to rain or water.

⇒ The display does not operate normally when the operating instructions are

followed.

⇒ The display has been dropped or the enclosure has been damaged.

⇒ The display exhibits a distinct change in performance, indicating a need

for service.

PRODUCT SAFETY PRECAUTIONS

Section

VT121 ColorVue Series User Guide 150-033

4.1 Unpacking and setting up your display

4.2 Installation

1. Turn power off both Computer and Display before making any connection.

2. Install Display on the solid horizontal surface such as a table or desk.

3. Connect the power cable to the back of the LCD monitor.

4. Connect the signal cable on the rear of the monitor to the 15-pin connector on the rear of the

computer and tighten the screws.

IBM PC’s & Compatibles

Connect one end of the signal cable to the 15-pin connector on the rear of the computer.

Apple/Macintosh

Connect a MAC adapter to the video connector on the rear of the Apple/Macintosh computer. Then

plug the other end of the signal cable into the MAC adapter. (Contact your local Apple dealer for in-

formation on purchasing the correct conversion connector.)

5. Tighten the screw of the Display cable until the connectors are fastened securely.

6. Switch on power to the Display, then to the monitor.

This analog LCD display DOES NOT require any special drivers. Necessary drivers are supplied by

the video card manufacturer and may be found on the diskettes supplied with the video card that

came with your computer. Windows 95/98 drivers for both the display and the video card are sup-

plied on the Windows 95/98 CD or diskettes. Unfortunately, Microsoft did not provide a complete

listing of the displays on the initial retail release. You may use the standard SVGA (800 x 600 @ 60)

as the display type. The video card must also be set up correctly in Windows 95/98 and make sure

the video output of the VGA card is on list in Section 5.1 or check your Video Card manual or Win-

dows 95/98 Read me file for further information on Video Card. After the question listed above is

solved, we continue the setup procedure as below.

Your LCD monitor package will consist of the components listed below. Open shipping container and

lay all components on a flat clean surface.

⇒ VT121CC, VT121RC, VT121PC, VT121WC, or VT121PCQ LCD Monitor

⇒ 15-PIN D-sub Video cable

⇒ AC power cord

⇒ User Manual or CD ROM

HARDWARE INSTALLATION

Section

VT121 ColorVue Series User Guide 150-033

4.3 Video Input Pin Assignment

This section describes the pin assignment of the LCD’s video connector.

Pin assignments for the HD15 video connector

Pin Connection Pin Connection

1 Red Video 9 No Connection

2 Green Video 10 Ground

3 Blue Video 11 No Connection

4 No Connection 12 DDC Data

5 Ground 13 Horizontal Sync

6 Red Video Ground 14 Vertical Sync

7 Green Video Ground 15 DDC Clock

8 Blue Video Ground

HD15 Connector

VT121 ColorVue Series User Guide 150-033

TOUCH SCREEN

Section

Touch screens are a common means to interface operator inputs to a system. The universal

standard of Windows GUI (Graphical User Interface) has significantly increased the use of

touch screens.

There are four main touch technologies. The technologies are resistive, surface acoustic

wave (SAW), capacitive, and infrared (IR). Each touch technology has advantages and

disadvantages based on different user applications.

All Vartech Systems displays configured with a touch screen are supplied with a CDROM

which includes user manuals, application software, and drivers for various operating systems.

Insert the supplied CDROM into a CDROM drive and follow the installation instructions that

will appear on the screen.

Limited technical support is available by contacting Vartech Systems customer support at

800-223-8050.

5.1 Introduction

5.2 Installation

VT121 ColorVue Series User Guide 150-033

The following table lists the better display quality modes that the LCD monitor provides. If the other

video modes are input, the monitor will stop working or display unsatisfactory picture quality.

VESA MODES

Mode Resolution Total

Horizontal

Nominal

Frequency

±0.5KHz

Vertical

Nominal

Frequency

±1Hz

Nominal

Pixel Clock

(MHz)

DOS 720 x 400@70Hz 900 x 449 31.469 70.087 28.322

VGA

640 x 480@60Hz 800 x 525 31.469 59.940 25.175

640 x 480@72Hz 832 x 520 37.861 72.809 31.500

640 x 480@75Hz 840 x 500 37.500 75.000 31.500

SVGA

800 x 600@56Hz 1024 x 625 35.156 56.250 36.000

800 x 600@60Hz 1056 x 628 37.879 60.017 40.000

800 x 600@72Hz 1040 x 666 48.077 72.188 50.000

800 x 600@75Hz 1056 x 625 46.875 75.000 49.500

Table 6.1 Applicable video timing - VESA Modes

DISPLAY TIMING

Section

VT121 ColorVue Series User Guide 150-033

The Display Timing Cont.

IBM MODES

Mode Resolution Total

Horizontal

Nominal

Frequency

±0.5KHz

Vertical

Nominal

Frequency

±1Hz

Nominal Pixel

Clock (MHz)

EGA 640 x 350@70Hz 800 x 449 31.469 70.086 25.175

CGA 640 x 480@60Hz 800 x 449 31.469 70.086 25.175

DOS 800 x 600@56Hz 900 x 449 31.469 70.087 28.322

VGA 800 x 600@60Hz 800 x 525 31.469 59.940 25.275

XGA 800 x 600@72Hz 1304 x 798 57.515 72.100 75.000

Table 6.2 Applicable video timing - IBM Modes

MAC MODES

Mode Resolution Total

Horizontal

Nominal

Frequency

±0.5KHz

Vertical

Nominal

Frequency

±1Hz

Nominal

Pixel Clock

(MHz)

VGA 640 x 480@60Hz 800 x 525 31.469 59.940 25.175

640 x 480@67Hz 864 x 525 35.000 66.667 30.240

SVGA 832 x 624@75Hz 1152 x 667 49.725 74.551 57.283

XGA 1024 x 768@60Hz 1312 x 813 48.780 60.001 64.000

1024 x 768@75Hz 1328 x 804 60.241 74.927 80.000

Table 6.3 Applicable video timing - MAC Modes

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels VarTech Systems Moniteur

VarTech Systems

VarTech Systems VT320D Manuel utilisateur

VarTech Systems

VarTech Systems VT084XA4 Manuel utilisateur

VarTech Systems

VarTech Systems VT084XHB Manuel utilisateur

VarTech Systems

VarTech Systems VT121 DiamondVue Series Manuel utilisateur

VarTech Systems

VarTech Systems GDM-5001PT Manuel utilisateur

VarTech Systems

VarTech Systems VT19B-PW Manuel utilisateur

VarTech Systems

VarTech Systems VTPC2100VS Manuel utilisateur

VarTech Systems

VarTech Systems VT420D Manuel utilisateur

VarTech Systems

VarTech Systems VT14A-D Manuel utilisateur

VarTech Systems

VarTech Systems VT29B-M Manuel utilisateur

VarTech Systems

VarTech Systems VT190P2 Manuel utilisateur

VarTech Systems

VarTech Systems VT181R2 Manuel utilisateur

VarTech Systems

VarTech Systems DiamondVue VT150P Manuel utilisateur

VarTech Systems

VarTech Systems VT064P Manuel utilisateur

VarTech Systems

VarTech Systems VT14B-C1 Manuel utilisateur

VarTech Systems

VarTech Systems VTPC150XPE Manuel utilisateur

VarTech Systems

VarTech Systems VT213C Manuel utilisateur

VarTech Systems

VarTech Systems DiamondVue VT201C Manuel utilisateur

VarTech Systems

VarTech Systems VT190PVS Manuel utilisateur

VarTech Systems

VarTech Systems VT150CHB Manuel utilisateur

VarTech Systems

VarTech Systems VT420 Series Manuel utilisateur

VarTech Systems

VarTech Systems VT20A Manuel utilisateur

VarTech Systems

VarTech Systems DiamondVue VT084C Manuel utilisateur

VarTech Systems

VarTech Systems vt550 series Manuel utilisateur

Manuels Moniteur populaires d'autres marques

Linear Acoustic

Linear Acoustic LQ-1000 Manuel utilisateur

AOC

AOC I2579V Manuel utilisateur

Gateway

Gateway FPD1520 Manuel utilisateur

Furuno

Furuno Mu 120c Manuel utilisateur

Asus

Asus VB171D - 17" LCD Monitor Manuel utilisateur

Dell

Dell S2230MX Instructions d'utilisation

Philips

Philips 107C64 Manuel utilisateur

Dell

Dell S2409WFP Manuel utilisateur

EverFocus

EverFocus EN-7517E Manuel utilisateur

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manuel utilisateur

Dell

Dell Precision 7680 Mode d’emploi

LG 50PM1M - - 50" Plasma Panel Manuel utilisateur

Bosch

Bosch DDU 9 Manuel utilisateur

Acer

Acer A231HL Manuel utilisateur

Philips

Philips 86BDL4152T Manuel utilisateur

NEC

NEC AccuSync LCD5V Manuel utilisateur

Emay

Emay SleepO2 Manuel utilisateur

IBM

IBM 6360 Instructions d'installation
