Vankyo 495W Manuel utilisateur

495W

User Manual • Uživatelský manuál •

Užívateľský manuál • Használati utasítás •

Benutzerhandbuch • Manuel d'utilisation

English

3 –25

Čeština

26 –48

Slovenčina

49 –71

Magyar

72 –94

Deutsch

95 –118

Français

119 –142

Dear customer,

Thank you for purchasing our product. Please read the following instructions carefully

before first use and keep this user manual for future reference. Pay particular attention

to the safety instructions. If you have any questions or comments about the device,

please contact the customer line.

✉www.alza.co.uk/kontakt

✆+44 (0)203 514 4411

Importer Alza.cz a.s., Jankovcova 1522/53, Holešovice, 170 00 Prague 7, www.alza.cz

WHAT´S INCLUDED

NOTICE

Recommended

Projector

Remote (Batteries Not Included)

User Manual

HD Cable

Power Cable

Video, Movie

NOT Recommended

PRODUCT OVERVIEW

Focus Ring

Lens

Infrared Receiver

LED Signal

OK/Return

Left/Down/Right

Power Button

Infrared Receiver

HD Port

USB 1

USB 2

AV In

Keystone Correction Ring

Audio Out

Power Inlet

Detachable Dust Filter

Air Outlet

Speaker

QUICK START

1. Projector Installation

Horizontal Placement

Ceiling Mounting

Note: Whichever installation option you select, please make sure:

1. The projector is centered directly in front of the wall/screen, but not tilted or

placed at an angle toward the wall/screen;

2. To select the corresponding projection mode so the images can be projected

correctly.

Power Button

Left

Return

Input Source

Mute

Play/Pause

Right

Down

Volume +

Volume -

2. Power On/Off

Plug the power cord into an outlet.

Take off lens cover.

Press the Power Button to turn on the

projector.

Press the Power Button twice to turn off

the projector.

3. Images Adjustment

Rotate the Keystone Correction Ring to correct Vertical Keystone Distortion until the

image is evenly rectangular.

Rotate the Focus Ring to sharpen the Image Focus until the blurred image becomes

clear.

In Homepage interface, enter Setting > Image Scaling to enlarge or reduce the Image

Size from 75% to 100% (optional)

4. Homepage Overview

The default interface after boosting is Homepage as shown.

In Homepage interface, when the underscore cursor locates at the Main Menu Bar,

press to toggle though menu items including MultiMedia, Input Source and Setting.

Press / OK to enter the corresponding Submenu, then press to return to Main

Menu Bar.

•Multimedia page display file categories of Multimedia Input (typically for a USB

Disk), including MOVIE, PHOTO, MUSIC and TEXT.

•Input Source page display three categories of input source, including

MULTISCREEN, HDMI, and AV.

•Setting page will guide you through all settings for the projector.

•The icon will light up when the projector is successfully connected to a

Bluetooth audio device.

•The icon will turn into when the projector is successfully connected to a

Bluetooth audio device.

•The icon will turn into when a USB disk is inserted.

Main Menu Bar

USB Disk Inserted

WiFi Status

Bluetooth Status

Submenu

MULTIMEDIA CONNECTION

USB Disk Connection

Step 1: Turn on the projector and insert your USB disk into the USB 1/USB 2 port of the

projector.

Step 2: Go to Homepage > Multimedia and select the file category you would like to

display among MOVIE, PHOTO, MUSIC and TEXT, then enter the inserted USB Disk to

check all files stored.

Step 3: To play a video movie file, please follow the below steps:

•Select MOVIE in the MultiMedia interface to correspondingly read video files

stored.

•Press OK / on the projector/remote for a certain video file to enter full-screen

display.

•Press OK on the projector or press OK/Menu on the remote when playing back a

video to bring up the toolbar to control the video playing.

Note:

Operation for playing a photo file, a music file and a text file is the same with that for

playing a video file, but please make sure to select the correct file category; that is, for

playing a photo file, select Photo in MultiMedia interface, likewise, for music, select

MUSIC, for text, select TEXT.
