Valtra 95 Manuel utilisateur
Service Manual
General
Engine
Electrical
system
Valtra Inc.
SF---44200 Suolahti, Finland
Power
transmission
Brake
system
Steering sys-
tem and Front
axle
Frame and
Wheels
Tools
Cab and
Shields
Hydraulics
10
20
30
95
105
115
X100
X110
X120
40
50
60
70
80
100
90
3
To the reader
The Service Manual for the ValtraValmet tractors is intended to be a practical reference source to be
used in workshop. The repair instructions in the manual are based on methods which have been
worked out in practice during normal workshop conditions and which are based on the use of special
tools from the manufacturer when stated in the instructions. The manual also contains descriptions of
the design and function of the components.
Detailed maintenance instructions can be found in Operator's Manual.
The Service Manual will be continually updated with new revised pages which should be inserted in the
manual. lterations and additions will first appear as service bulletins.
Only genuine Valmet spare parts should be used to ensure the best possible function of the machine.
Certain operations should be carried out with the aid of special tools designed by Valmet.
Valmet Tractors Inc.
Tractor Service
IM ORTANT!
ValtraValmet 95, 105 and 115 tractors are based on ValtraValmet agricultural tractors as follows:
- 95 is based on 6400DW tractor
- 105 is based on 6600 tractor
- 115 is based on 6800 tractor
ValtraValmet X100, 110H and X120 tractors are based on ValtraValmet agricultural tractors as follows:
- X100 is based on 6550Hi tractor
- X110 is based on 6650Hi tractor
- X120 is based on 6850Hi tractor
95- X120 tractors have frame steering (in 95-X120 tractors there is a new middle frame in place of the
fuel tank which is fitted on the corresponding agricultural tractors) and 95-X120 can have special auxĆ
iliary hydraulics (e.g. special, fixed front loader and its control), which are not fitted on correcponding
agricultural tractors. However, other vehicle components are the same as in corresponding agricultural
tractors.
Find manuals at https://best-manuals.com
7
Model Code Page
11. Layout 1. 11. 2000
95, 105, 115
X100-X120 110 1
Layout of Service Manual
1. Division into groups
The manual is divided into groups (10-100) which are based on the make-up of the tractor. The groups are listed on the first index
leaf.
Example. 10. General
20. Engine, fuel and cooling systems
30. Electrical system
40. Power transmission
a.s.o.
The number designation for each group is given in the top left box of the respective pages (and the first figure in the code designaĆ
tion)
410 1
50
60
70
80
90
100
Code Page
2. Division into components or sub-groups
Each group is further divided into components or sub-groups. The number and the name of each component is given in the top
left box on each page (and comprise the two first figures in the code designation).
Example. 41. Clutch
42. Gearbox
44. Quick-shift gear
45. Final drives etc.
Find manuals at https://best-manuals.com
8
Model Code Page
11. Layout 1. 11. 2000 110 2
95, 105, 115
X100-X120
3. Code designation
Three-digit code designations are used to distinguish the different document groups for the respective components. The same
code is also used in the Time List as a reference to the text in this Manual. The code designation numbers appear both in the box at
the top of the page and also in the headings.
Example: Code 410:
- Group: Power transmission (4)
- Component: Clutch (41)
- Document group: General (410)
4. age numbers
The instructions for all components are numbered in consecutive order in the right-hand box at the top of the page. The page
numbers begin with page 1 for each component.
41. Clutch 1. 11. 2000
Model Code Page
95, 105, 115 410 1
1. 9. 2000
5. Date
t the top of each page there are two boxes for dates. In the case of a revised issue, the date of the earlier issue is printed in the
crossed-over box and the date of the current issue is printed in the "real" date box.
6. Model
t the top of each page the tractor model for which the page is valid is indicated.
7. Additions and amendments of the service manual
New and up-dated pages will be continually added to the service manual. The new pages should be inserted as indicated by the
code: the first digit (also the first digit on the index leaf) indicated the group:
- the two first digits indicate the component or sub-group
- the third digit indicates the document group for the respective components
- the page number indicates the definite position of the page within the service manual
If there are two pages with the same code and page number the page with the later date in the date box (and the old date in the
crossed-over box) is valid (or the current page).
N.B. Fitting instructions for extra equipment are inserted into the service manual at the end of group concerned (E.g. code 39 is
inserted at the end of group 30).
Find manuals at https://best-manuals.com
