Vaillant VRT 360f Operating and Fiche technique
For the owner and heating engineer
VRT 360f
Operating and Installation Manual
VRT 360f
Room temperature thermostat
GB
2
Contents
Operating and installation manual VRT 360f
Inhaltsverzeichnis
Notes on the documentation . . . . . . 4
Storage of the documents.................... 4
Symbols used........................................... 4
Safety . . . . . . . . . . . . . . . . . . . . . . . . . 5
Operating manual. . . . . . . . . . . . . . . . 6
1
Overview of the equipment . . . . . 6
2 Overview of the display . . . . . . . 7
3 Description of the appliance . . . 8
4 Operation. . . . . . . . . . . . . . . . . . . 8
4.1 Setting the operating modes ...... 9
4.2 Setting the current day and
time ................................................... 12
4.3 Setting timer programmes .......... 13
4.4 Setting the room temperature ... 16
4.5 Setting the hot water
temperature .................................... 18
4.6 Activating special functions........ 19
4.7 Info level........................................... 22
4.8 Changing the battery.................... 23
5 Manufacturer’s warranty and
liability . . . . . . . . . . . . . . . . . . . .25
6 Recycling and disposal. . . . . . . .25
3Operating and installation manual VRT 360f
Contents
GB
Installation instructions . . . . . . . . . .27
7 Notes on the installation and
operation . . . . . . . . . . . . . . . . . . .27
7.1 CE label............................................. 27
7.2 Intended use.................................... 28
8 Safety instructions and regulati-
ons . . . . . . . . . . . . . . . . . . . . . . . .29
8.1 Safety instructions ........................ 29
8.2 Regulations...................................... 30
9 Installation . . . . . . . . . . . . . . . . . 31
9.1 Place of installation....................... 31
9.2 Fitting the receiver........................ 31
9.3 Mounting the room temperature
thermostat....................................... 33
10 Electrical installation. . . . . . . . .35
10.1 Connecting the receiver............... 35
11 Start-up. . . . . . . . . . . . . . . . . . . .36
11.1 Installer level................................... 37
11.2 Service/diagnostics level.............. 41
11.3 Handing over the appliance to
the owner......................................... 43
12 Troubleshooting . . . . . . . . . . . . .44
13 Technical data. . . . . . . . . . . . . . .45
14 Vaillant Service . . . . . . . . . . . . .46
4Operating and installation manual VRT 360f
Notes on the documentation
The following information is intended to
help you throughout the entire
documentation.
Other documents apply in combination
with this installation and operation
manual.
We accept no liability for any damage
caused by failure to observe these
instructions.
Storage of the documents
Please pass on this operating and
installation manual to the owner of the
system in order for him/her to store it so
that it is available whenever it is required.
Symbols used
Please observe the safety instructions in
this manual for the installation of the
appliance.
Danger!
Immediate risk of serious injury
or death
Caution!
Potentially dangerous situation
for the product and environment.
Notes on the documentation
5GBOperating and installation manual VRT 360f
Note!
Useful information and
instructions.
• Symbol for a necessary task
Safety
The room temperature thermostat must
be installed by a suitably qualified
heating engineer, who is responsible for
adhering to the existing standards and
regulations.
We accept no liability for any damage
caused by failure to observe these
instructions.
Notes on the documentation, safety
6Operating manual VRT 360f
Operating manual
1
Overview of the equipment
1
2
Abb. 1.1 Overview of equipment
Key
1 Display
2 Dial (turn and click)
I Info button
F Special functions button
P Programming key/installer level
1 Overview of the device
7GBOperating manual VRT 360f
2 Overview of the display
1
2
3
4
5
6
7
8
9
11
10
Fig. 2.1 Overview of the display
Key
1 Installer level and
Service/Diagnosis level (Chapter 11.1)
2 Info level (see 4.7)
3 Hot water symbol
4 Circulation pump symbol
5 Heating circuit symbol
6 Time/temperature display
7 Days of the week
8 Actual temperature
9 Operating modes (see 4.1)
10 Special functions (see 4.6)
11 Setting timer programmes (see 4.3)
Overview of the display 2
8Operating manual VRT 360f
3 Description of the
appliance
The VRT 360f is a programmable room
temperature thermostat with weekly
programme for heating, hot water and
circulation pump for connection to
Vaillant heating equipment with eBus.
The connection between the room
temperature thermostat and the heating
unit is by radio link.
The VRT 360f enables you to specify the
room temperature using heating
programs. In addition, you can select
special functions such as the party
function, and control the timed
operation of a boiler and a circulation
pump.
4 Operation
The operating principle is based on the
three buttons and an dial (Vaillant "turn
and click“ operating concept).
The display normally shows the current
operating mode (e.g. ), or, if
activated, the special function and the
current room temperature, the day of
the week, the time and the symbol for
heating, hot water and/or the circulation
pump, depending on which is requested.
3 Device description, 4 Operation
9GBOperating manual VRT 360f
4.1 Setting the operating modes
Table 4.1 provides you with an overview
of the operating modes you can select.
The selected operating mode affects the
timer programmes both for heating and
for hot water and the circulation pump.
• When the room temperature
thermostat is in normal display mode.
press the dial once – the symbol for
the selected mode flashes in the
display.
• Turn the dial until the desired
operating mode appears on the
display.
The display switches back to normal
mode after five seconds.
Operation 4
10 Operating manual VRT 360f
Symbol Meaning
Heating Hot water
Automatic:
The operation of the heating circuit changes between
the operation modes Heating and Energy Saving
. The heating circuit symbol is displayed if a heating
requirement is detected.
The operation of the hot water
storage cylinder/circulation
pump changes between
heating/ON and OFF
depending upon the time
programme set on the room
temperature thermostat.
The hot water symbol and the
circulation pump symbol are
displayed if the time window
is active.
Heating:
The heating circuit is operated according to the
room temperature, regardless of the programme set
on the room temperature thermostat. The heating
circuit symbol is displayed if a heating requirement is
detected.
Energy Saving:
The heating circuit is operated according to the
energy saving temperature "ECO“, regardless of the
programme set on the room temperature thermostat.
The heating circuit symbol is displayed if a heating
requirement is detected.
Table 4.1 Operating modes
4 Operation
