Vaidnor VDF650 Series Manuel utilisateur

VDF650 Series

High-Performance AC Drive

VDF650 User Manual Preface

- 1 -

Preface

Thank you for purchasing the VDF650 series AC drive developed by Suzhou vaidnor

Electronic Technology Co., Ltd.

The VDF650 series AC drive is a general-purpose high-performance current vector control

AC drive. It is an upgrade product based on VDF730 and can implement the control of

asynchronous motor and permanent magnet synchronous motor (PMSM). It increases the

user programmable function, background monitoring software and communication bus

function, and supports multi-kind PG cards. It is used to drive various automation production

equipment involving textile, paper-making, wiredrawing, machine tool, packing, food, fan

and pump.

This manual describes the correct use of the VDF650 series AC drive, including selection,

parameter setting, commissioning, maintenance & inspection. Read and understand the

manual before use and forward the manual to the end user.

Notes

• The drawings in the manual are sometimes shown without covers or protective guards.

Remember to install the covers or protective guards as specifed frst, and then perform

operations in accordance with the instructions.

• The drawings in the manual are shown for description only and may not match the product

you purchased.

• The instructions are subject to change, without notice, due to product upgrade, specifcation

modifcation as well as efforts to increase the accuracy and convenience of the manual.

• Contact our agents or customer service center if you have problems during the use.

Introduction VDF650 User Manual

- 2 -

Introduction

Compared with VDF730, the VDF650 series AC drive incorporates the following improvements:

1) Multiple voltage classes

It provides coverage of single-phase 220 V, three-phase 220 V, three-phase 380 V,

three-phase 480 V, three-phase 690 V and three-phase 1,140 V.

2) Control of asynchronous motor and PMSM

It supports vector control of three-phase AC asynchronous motor and three-phase AC

PMSM.

3) Diversifed control modes

It supports three control modes, namely, sensorless fux vector control (SFVC), closed-

loop vector control (CLVC) and V/F control.

4) Multiple communication protocols

It supports communication via Modbus-RTU, PROFIBUS-DP, CANlink and CANopen.

5) Multiple encoder types

It supports various encoders such as differential encoder, open-collector encoder,

resolver and UVW encoder.

6) All-new SFVC algorithm

It introduces an all-new sensorless flux vector control (SFVC) algorithm that gives

better low-speed stability, enhanced low-frequency loading capacity, and supports

torque control.

7) User programmable function

The VDF65PC1 programmable card enables you to write programs in ladder diagram.

Its programming environment is compatible with that of the H1U series PLC.

8) Advanced background software

The background monitoring software helps to achieve functions of parameter upload &

download and a real-time oscilloscope.

9) Other new functions

The newly added functions of the VDF650 series AC drive are described as below:

Function Description

Virtual I/O It can implement various simple logic functions.

Motor overheat protection

The optional VDF65IO1 extension card enables AI3 to

receive the signal from the motor temperature sensor

input (PT100, PT1000) thereby providing motor overheat

protection.

Rapid current limit It helps to avoid frequent occurrence of overcurrent faults

of the AC drive.

VDF650 User Manual Introduction

- 3 -

Function Description

Multi-motor switchover Four motors can be switched over via four groups of

motor parameters.

Restoring user parameters It allows you to save or restore the parameters set by

yourself.

Higher-accuracy AI/AO The AI/AO accuracy can reach almost 20 mv via factory

correction or on-site correction.

Customized parameter

display

You can customize the parameters that need to be

displayed.

Modifed parameter display You can view the modifed parameters.

Operation selection at fault

occurrence

You can select the reaction of the AC drive to a fault

occurring, based on the actual need. The reactions are as

below:

• Coast to stop

• Decelerate to stop

• Continue to run

You can also select the frequency at which the AC drive

continues to run.

PID parameters switchover

Two groups of PID parameters can be switched over via

terminals or can be automatically switched over according

to deviation.

PID feedback loss detection The PID feedback loss value can be set to realize PID

protection.

DI/DO positive or negative

logic You can set the DI/DO positive or negative logic.

DI/DO response delay You can set DI/DO response delay time.

Power dip ride through

It ensures that the AC drive continues to run for a short

time when an instantaneous power failure or sudden

voltage reduction occurs.

Timing operation The AC drive supports timing operation for 6500 minutes

at maximum.

User programmable function The externally connected programmable card helps you

to realize secondary development.

Load allocation Load allocation can be implemented between two VDF650

series AC drives through point-to-point communication.

Introduction VDF650 User Manual

- 4 -

Product Checking

Upon unpacking, check:

• Whether the nameplate model and AC drive ratings are consistent with your order. The

box contains the AC drive, certifcate of conformity, user manual and warranty card.

• Whether the AC drive is damaged during transportation. If you fnd any omission or

damage, contact vaidnor or your supplier immediately.

First-time Use

For the users who use this product for the frst time, read the manual carefully. If in doubt

concerning some functions or performances, contact the technical support personnel of

vaidnor to ensure correct use.

CE Mark

The CE mark on the VDF650 declares that the AC drive complies with the European low

voltage directive (LVD) and EMC directive.

The VDF650 series AC drive complies with the following LVD and EMC directives and

standards:

Directive Directive Code Standard

EMC Directive 2004/18/EC

EN 61800-3

EN 55011

EN 61000-6-2

LVD Directive 2006/95/EEC EN 61800-5-1

The VDF650 series AC drive complies with the requirements of standard IEC/EN 61800-3 on

the condition of correct installation and use by following the instructions in chapter 7.

Contents

Preface ..................................................................................................................1

Introduction ............................................................................................................2

Chapter 1 Safety Information and Precautions....................................................................10

1.1 Safety Information ......................................................................................................... 10

1.2 General Precautions ......................................................................................................12

Chapter 2 Product Information ............................................................................18

2.1 Designation Rules and Nameplate of the VDF650 ......................................................... 18

2.2 Components of the VDF650....................................................................................................................18

2.3 Technical Specifcations ................................................................................................ 20

2.4 Peripheral Electrical Devices and System Confguration .............................................. 24

Chapter 3 Mechanical and Electrical Installation .................................................30

3.1 Mechanical Installation ..................................................................................................30

3.2 Electrical Installation ......................................................................................................35

Chapter 4 Operation, Display and Application Examples ....................................46

4.1 Operation Panel............................................................................................................ ............................ 46

4.2 Viewing and Modifying Function Codes ........................................................................ 48

4.3 Structure of Function Codes ..........................................................................................49

4.4 Quick View of Function Codes ...................................................................................... 50

4.5 Defnition and Operation of the Multifunction Key (MF.K) ..............................................52

4.6 Viewing Status Parameters ...........................................................................................52

4.7 Starting or Stopping the AC Drive................................................................................. ...................... 54

4.8 Setting the Running Frequency .....................................................................................60

4.9 Setting and Auto-tuning of Motor Parameters ............................................................... 69

4.10 Use of DI Terminals .....................................................................................................72

4.11 Use of DO Terminals ....................................................................................................73

4.12 Use of AI Terminals ......................................................................................................73

4.13 Use of AO Terminals ....................................................................................................74

4.14 Use of the PG Terminal ............................................................................................... 75

4.15 Use of Serial Communication ......................................................................................75

4.16 Use of Multifunctional Extension Interfaces................................................................................. 76

4.17 Password Setting.................................................................................................................................. 77

4.18 Parameter Saving and Default Setting Restoring ........................................................77

Chapter 5 Function Code Table ...........................................................................80

5.1 Standard Function Parameters........................................................................................................... 80

5.2 Monitoring Parameters ................................................................................................133

Chapter 6 Description of Function Codes...........................................................................136

Group P0: Basic Parameters .............................................................................................136

Group P1: Motor 1 Parameters.................................................................................................................148

Group P2: Vector Control Parameters ...............................................................................152

Group P3: V/F Control Parameters..........................................................................................................156

Group P4: Input Terminals .................................................................................................161

Group P5: Output Terminals ..............................................................................................172

Group P6: Start/Stop Control .............................................................................................177

Group P7: Operation Panel and Display................................................................................................183

Group P8: Auxiliary Functions ........................................................................................... 187

Group P9: Fault and Protection .........................................................................................198

Group FA: Process Control PID Function ..........................................................................207

Group FB: Swing Frequency, Fixed Length and Count .....................................................212

Group FC: Multi-Reference and Simple PLC Function....................................................................215

Group FD: User-defned Parameters ................................................................................ ..................... 219

Group FE: User-Defned Function Codes ............................................................................................ 219

Group FP: User Password.........................................................................................................................220

Group A0: Torque Control and Restricting Parameters .....................................................222

Group A1: Virtual DI (VDI)/Virtual DO (VDO) .................................................................... 224

Group A2 to A4: Motor 2 to Motor 4 Parameters ...............................................................228

Group A5: Control Optimization Parameters .....................................................................232

Group A6: AI Curve Setting ............................................................................................... 234

Group A7: User Programmable Function .......................................................................... 236

Group A8: Point-point Communication ..............................................................................236

Group AC: AI/AO Correction ..............................................................................................239

Group U0: Monitoring Parameters.................................................................................... ...................... 240

Chapter 7 EMC ..................................................................................................248

7.1 Defnition of Terms .......................................................................................................248

7.2 Introduction to EMC Standard .....................................................................................248

7.3 Selection of Peripheral EMC Devices......................................................................... ................... 249

7.4 Shielded Cable ............................................................................................................256

7.5 Solutions to Common EMC Interference Problems .....................................................258

Chapter 8 Selection and Dimensions ................................................................260

8.1 Electrical Specifcations of the VDF650 ........................................................................260

8.2 Physical Appearance and Overall Dimensions of the VDF650 .....................................263

8.3 Recommended Cable Diameter and Installation Dimensions of Power Terminals ......267

8.4 Selection of Peripheral Electrical Devices ...................................................................276

8.5 Selection and Installation of External DC Reactor...................................................... .............. 278

8.6 Physical Dimensions of External Operation Panel ......................................................280

8.7 Selection of Braking Unit and Braking Resistor ...........................................................280

Chapter 9 Maintenance and Troubleshooting................................................... ............... 286

9.1 Routine Repair and Maintenance of the VDF650 ......................................................... 286

9.2 Warranty Agreement ....................................................................................................287

9.3 Faults and Solutions ....................................................................................................287

9.4 Common Faults and Solutions .................................................................................... 292

Safety Information and Precautions

Table des matières

Autres manuels Vaidnor Entraînement CC

Vaidnor

Vaidnor VDF730 Series Manuel utilisateur

Manuels Entraînement CC populaires d'autres marques

Vincent Associates

Vincent Associates UNIBLITZ ED12DSS Manuel utilisateur

EKSMA OPTICS

EKSMA OPTICS DQ-100-4 Manuel de la liste des pièces

Chamberlain Garog

Chamberlain Garog D Series Manuel utilisateur

Parker

Parker PDS Series Manuel utilisateur

Festo

Festo DGC G Series Guide de configuration

Binks

Binks QS-5012-1-CE Manuel utilisateur

Danfoss

Danfoss VLT 2800 Series Fiche technique

ABB

ABB ACQ580-01 Series Manuel d'installation

YASKAWA

YASKAWA CANopen SI-S3 Manuel utilisateur

GE D20A6 Manuel utilisateur

Unex

Unex MC-D-250-1000-050W-TW Manuel utilisateur

Geckodrive

Geckodrive G213V Manuel utilisateur

ABB

ABB RSYC-01 Manuel utilisateur

Rockwell Automation

Rockwell Automation PowerFlex 700S Manuel du propriétaire

WEG

WEG DeviceNet CFW500 Manuel utilisateur

Siemens

Siemens SINAMICS G Fiche technique

Siemens

Siemens SINAMICS SM150 6SL3815-7NP41-0AA1 Mode d'emploi

SOMFY

SOMFY JR RU 30 Manuel utilisateur
