VDH-NK300
Hardware Manual
2015 MAY V1.1
VDH-NK300 Hardware Manual
i
Contents
A. CAUTION .............................................................................................................................................. 1
B. Introduction ......................................................................................................................................... 2
1. Product Overview ..................................................................................................................... 2
2. Main functions ........................................................................................................................... 2
C. Unpacking ............................................................................................................................................ 3
1. Accessories ................................................................................................................................. 3
2. Unpacking ................................................................................................................................... 3
D. Installation ............................................................................................................................................ 3
E. Product appearance ......................................................................................................................... 4
1. Front Panel .................................................................................................................................. 4
2. Rear Panel ................................................................................................................................... 5
3. Installation Illustration ............................................................................................................ 6
Video input ....................................................................................................................... 7
Connections for video outputs ................................................................................. 7
Audio Inputs..................................................................................................................... 7
Audio Output ................................................................................................................... 8
AlarmIn/AlarmOut connections ............................................................................... 8
F. Q & A and Maintenance ................................................................................................................. 9
1. Q & A............................................................................................................................................. 9
2. Maintenance ........................................................................................................................... 11
G. Appendix : Specifications ............................................................................................................ 12
1. 12CH NVR ................................................................................................................................ 12
VDH-NK300 Hardware Manual
1
A. CAUTION
To our dear customer!
Thank you for using our products. If you encounter any problems when using,
please do not hesitate to contact our resellers. We will provide excellent services to
you via our resellers.
The software/hardware improvements of this series are subject to change without
notice to you in advance. Before using, please read this user manual carefully to
ensure that you can use the device correctly and safely.
Caution for this NVR series
After installation, never put anything heavy over this device. Owing to the use
of the harddrive(s) insides this device, check the cooling fan periodically to see
if it is in good condition. Never use this device when the cooling function is
out of order!
Do not allow any solid object or liquid fall into or penetrate into the device.
Use cleaning tools (brushes) regularly to clean circuit boards, connectors, fans,
chassis, etc. Before cleaning, turn off the power and unplug the power.
Do not attempt to disassemble the equipment, repair, or replace parts. In case
the machine does not work properly, please contact the resellers or
manufacturers. In the shortest time, we will solve the problems you have
during using.
When not using the remote control for a long time, take out the inside battery
To prevent the control from the damage coming from battery leakage!
If this equipment connects to outdoor cameras or other external alarm
devices, ground this equipment to prevent it from electrical surges.
This NVR supports remote video monitoring via Internet. Free or non-free
domain names provided by ISPs are needed for the monitoring functions.
Free domain names may sometimes have problems and nothing to do with
NVR. Non-free domain names have less problems. Choose the domain names
carefully before using the networking function.
Operating environment
Keep and use this device at places where temperature ranges 0℃~40℃. Avoid
direct sunlight or near heat sources.
Do not install this equipment in a humid environment
Do not expose this equipment in smoky, dusty environments;
Avoid strong collision, do not drop the machine
Keep the installation level, install in a stable place, avoid the product falling;
Do not block any ventilation openings. And ensure well ventilation around the
machine
Please use this equipment within rated input and output current/voltage
range.
This device is for long-time use. For safety, do not have flammable items
placed next to the device.
VDH-NK300 Hardware Manual
2
B. Introduction
1. Product Overview
This equipment is an excellent digital surveillance product designed
specifically for the security use. Using embedded LINUX operating system, it
makes the system more stable. Using standard H.264 video compression and
G.711A audio compression technology achieves audio and video functions
such as high-quality, low bit rate and single-frame playback. Using TCP / IP
and other network technologies, it provides strong network data transmission
capacity and remote control capabilities.
This equipment can be used individually or be connected to form a powerful
security monitoring network. Using professional network video surveillance
software platform, be fully experienced the powerful networking and remote
monitoring capabilities.
This equipment can be used for security in banks, telecommunications, power
stations, justice, transport, intelligence communities, factories, warehouses,
resources, water conservancy facilities and other categories.
2. Main functions
Hisilicon SoC CPU special design for NVR with the best image process
efficiency.
Support 2 units of SATA/SATA II device up to 6TB HDD recording
capacity.
Advanced H.264 compress technology provides the best HDD space
usage.
Embedded Linux system, to eliminate the threat from virus and hacking.
Support 12CHs of IP camera (1080P) video and also support analogue
camera video with optional Video server(AXIS).
Support HD output.
Support IP CAM position layout and editable user definition.
The USB mobile storage device or remote NAS.
Support 3 users log on by Client-side software or browser.
VDH-NK300 Hardware Manual
3
C. Unpacking
1. Accessories
★ Power cable and adaptor AC100-240V/DC12V 5A x 1PCS
★ HDD screws x 8pcs
★ Operation CD x 1pcs
★ Mouse
2. Unpacking
When you receive the product, check first whether the packing of the
equipment has obvious damage. The protective material used for the package
during transport can cope with most of the accidental impact
Then, take out the device, remove the protective film of the digital video
recorder and check if there is any visible damage;
Finally, open the case, check the front panel data cable, power cord, power
supply fan and motherboard to see if they are connected firmly.
Front/Rare panels
The key functions of the front panel and the interfaces of the rear panel are
described in detail in the manual.
Please carefully check the plate or foil on the rear panel of the product to see
if it is the model you ordered.
Inside check
In addition to checking for visible signs of damage, be careful to check the
connections between the front panel data cable, power cord and
motherboard.
D. Installation
Steps and cautions:
1、Room temperature below 35℃
2、Reserve space for air circulation around 15 cm (6 inches)
3、Chassis installation starts from bottom to up
4、With multiple components in the chassis, take precautions to avoid
overloading to the power outlet.
VDH-NK300 Hardware Manual
4
E. Product appearance
1. Front Panel
MENU Going to Menu
ESC ESC Exit
■ /SEQ Stop Stop when Playback
INFO INFO Information Page
Backward
When playing back，there are 2*、4*、8*、
16*、32*、1/2*、1/4* backward speeds.
Under live page、2Ch and 9Ch can be
changed
Forward
When playback，there are 2*、4*、8*、
16*、32*、1/2*、and 1/4* forward speeds
Under live mode, 2Ch and 9Ch can be
changed
Play
Pause
Under Live mode, going to broadcast and
copy; however, under playback mode, going
to broadcast.
Pause
PLAY/LIVE Playback
LIVE
Under LIVE mode, going to playback.
Under playback, going to LIVE mode.
REC Record Under LIVE mode, going to manual force
recording.
Power One touch, turn on and press 3 second, turn
off.
Up
Down
Under UI mode, select UP or Down
Left
Right
Under UI mode, select right or left.
VDH-NK300 Hardware Manual
5
Confirm Confirm each operation
1 KEY_1 Preview the 1th Ch
2 KEY_2 Preview the 2th Ch
3 KEY_3 Preview the 3th Ch
4 KEY_4 Preview the 4th Ch
5 KEY_5 Preview the 5th Ch
6 KEY_6 Preview the 6th Ch
7 KEY_7 Preview the 7th Ch
8 KEY_8 Preview the 8th Ch
9 KEY_9 Preview the 9th Ch
0/+10 KEY_0/+10
Preview the 10th Ch or press the same key 3
second, then press 1 or 2, going to 11th or 12th
Ch.
Power Power Indicator Power on
LAN Network
Indicator Network on
REC Recording
Indicator NVR recording function on
PLAY Play Back
Indicator Playback
2. Rear Panel
1 VIDEO OUT
2 SPOT OUT
3 Audio In
4 Audio Out
VDH-NK300 Hardware Manual
6
5 HD Out
6 USB Mouse Port
7 LAN
8 VGA Out
9 Alarm In
10 Alarm Out
11 RS-485
12 DC12V Input
13 Power
14 Cable Fixed Key
Alarm In/Alarm Out/RS-485
3. Installation Illustration
VDH-NK300 Hardware Manual
7
Video input
Input interface is RJ-45 type; input signal is IP CAM
The Video signal should comply with national standards, a higher signal to
noise ratio, low distortion, low-interference; clear images, no deformation,
nature color and appropriate brightness.
Make sure stable and reliable signals from cameras
Cameras should be installed in a suitable position to avoid backlighting,
low-light environment, or adopts the better BLC, low-light cameras.
Cameras and digital video recorders should be common ground, stably and
reliably, in order to ensure the normal operation of the cameras.
Make sure the transmission cables are stable and reliable
Adopt high-quality, well-shielded coaxial cables, and choose the right model
based on the transmission distance. If the distance is too far, use shielded
twisted pair, video compensation equipment, optical transmission and other
ways to ensure signal quality based on the specific circumstances.
Video cable should avoid strong electromagnetic interference with other
devices and circuits, in particular, should avoid the current of high voltage.
Make sure the connectors well-connected:
Cables and shielded cable should be well-connected firmly to avoid false,
joint welding or oxidation.
Connections for video outputs
The video outputs include VGA and HDMI interfaces.
Pay attention to the following when you select a PC display instead of a
monitor.
1. Do not remain switched on for a long time to extend the life of the
equipment;
2. Regular degaussing will help to maintain the normal operation of the
monitor.
3. Keep away from equipment with strong electromagnetic interference.
Using TV as video output device is an unreliable alternative. It is also
required to minimize the time of use and strictly control the power, the
interference caused by neighboring devices. Leakage risks of low quality TVs
may result in damage to other equipments.
Audio Inputs
VDH-NK300 Hardware Manual
8
Voice input impedance is high, so the microphone must be a microphone
connected to the power supply.
Like video input, voice transmission cables should avoid interference, fake,
poor contact, and special attention to prevent the current of the
high-voltage.
Audio Output
The audio output parameters of NVR are generally greater than 200mv 1KΩ
(BNC), you can directly connect to the low impedance headphones, powered
speakers or other sound devices through a power amplifier.
When the external speakers and microphones can not achieve spatial
segregation, it is prone to the phenomenon of whistling.
You may adopt the following actions,
1. Using better directional microphones
2. Adjust the speaker volume to make it lower than the value of the
generated howling.
3. Using sound-absorbing materials for decoration to reduce sound
reflections and improve the acoustic environment;
4. Adjusting the layout of the microphone and speakers can reduce the
whistling.
AlarmIn/AlarmOut connections
Pay attention to the following before installation.
1. AlarmIn
(a) Alarm input is grounding alarm input
(b) The alarm input signals require voltage signals to the ground
(c) When the alarm device is shared with two NVRs or connected to a
NVR and other devices, it should be isolated by relays.
2. Alarm OUT
The alarm output of the NVR can not be connected with high-power
load (no more than 1A). In the output circuit, be careful about the
excessive current that may cause damage to the relay. When using
high-power load, extra relays are needed.
Table des matières
Autres manuels Vacron Matériel réseau
Manuels Matériel réseau populaires d'autres marques
Matrix Switch Corporation
Matrix Switch Corporation MSC-HD161DEL Manuel utilisateur
B&B Electronics
B&B Electronics ZXT9-IO-222R2 Manuel utilisateur
Yudor
Yudor YDS-16 Manuel utilisateur
D-Link
D-Link ShareCenter DNS-320L Manuel utilisateur
Samsung
Samsung ES1642dc Instructions d'utilisation
Honeywell Home
Honeywell Home LTEM-PV Instructions de montage
