Vacmaster RESPIRA UC0501 Manuel utilisateur
Use & Care Guide
Manuel D'entretien Et D'utilisation
Manual de Uso Y Cuidado
Model No / Référence de Modèle / N° de Modelo.
UC0501
Bagless Upright Vacuum Cleaner / Aspirateur Vertical
Sans Sac / Aspiradora de Pie Sin Bolsa
www.amazon.com
Distributed By / Distribué Par / Distribuido Por:
Suzhou Cleva Electric Appliance Co., Ltd.
No.8 Ting Rong Street
Suzhou Industrial Park, Suzhou
Jiangsu Province, China
Made in China
-2-
SECTION
Important Safety Instructions...................................................................................................................
Warranty..................................................................................................................................................
Technical Data.........................................................................................................................................
Getting To Know Your Vacuum................................................................................................................
General Assembly Instructions...............................................................................................................
Operating Instructions............................................................................................................................
Maintaining Your Vacuum.......................................................................................................................
Troubleshooting.....................................................................................................................................
3
4
4
5
7
10
16
27
TABLE OF CONTENTS
PAGE
Thank you for purchasing this Vacmaster®vacuum cleaner. With it you are
obtaining a high-quality product that is engineered for optimal performance.
FOR YOUR SAFETY
Read and understand this manual before use.
Keep this manual and your sales check (receipt) in a safe place for future
reference.
-3-
IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic precautions should always be followed,
including the following:
READ ALL INSTRUCTIONS BEFORE USING THIS VACUUM CLEANER
Failure to follow the warnings and instructions may result in electric shock, re
and/or serious injury.
WARNING - To reduce the risk of re, electric shock, or injury:
• Do not leave appliance when plugged in. Unplug from outlet when not in use
and before servicing.
• Do not use outdoors or on wet surfaces.
• Do not allow to be used as a toy. Close attention is necessary when used by or
near children.
• Use only as described in this manual. Use only manufacturer’s recommended
attachments.
• Do not use with damaged cord or plug. If appliance is not working as it should,
has been dropped, damaged, left outdoors, or dropped into water, contact with
customer service.
• Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull
cord around sharp edges or corners. Do not run appliance over cord. Keep cord
away from heated surfaces.
• Do not unplug by pulling on the cord. To unplug, grasp the plug, not the cord.
• Do not handle plug or appliance with wet hands.
• Do not put any objects into openings. Do not use with any opening blocked;
keep free of dust, lint, hair, and anything that may reduce air ow.
• Keep hair, loose clothing, ngers, and all parts of body away from openings and
moving parts.
• Turn off all controls before unplugging.
• Use extra care when cleaning on stairs.
• Do not use to pick up ammable or combustible liquids, such as gasoline, or
use in areas where they may be present.
• Do not pick up anything that is burning or smoking, such as cigarettes, matches,
or hot ashes.
• Do not use without the lter in place.
SAVE THESE INSTRUCTIONS
Household use only
-4-
FOR ONE YEAR from the date of sale, this product is warranted against defects
in material or workmanship when it is assembled, operated and maintained
according to all supplied instructions.
WITH PROOF OF SALE, a defective appliance will be replaced free of charge.
For warranty coverage details to obtain free replacement, visit the web page:
www.vacmaster.com or call 1-866-384-8432.
• This warranty does not cover lters or belt, which are expendable parts that
can wear out from normal use within the warranty period.
• This warranty is void if this product is ever used for other than private household
purposes.
• This warranty gives you specic legal rights, and you may also have other
rights which vary from state to state.
TECHNICAL DATA
Bagless Upright Vacuum Cleaner
Model: UC0501
Rated Voltage: 120V AC
Rated Frequency: 60Hz
Nominal Current: 7.5A
WARRANTY
TECHNICAL DATA
-5-
Hose Storage
Connection
Hose
Upper Hose
Connection
Lower Hose
Connection
Lower Cord Hook
Power
Cord
Handle
Accessory
Storage
Dust Cup
Release Button
Carrying Handle
Dust Cup
Lid Latch
Dust Cup
Floor Nozzle
Hose Release
Latch
Upper Cord
Hook
3-in-1
Combination
Tool
Wand Release
Button
Hose
Wand
GETTING TO KNOW YOUR VACUUM
Power Button
Dust Release
Button
Felt Filter &
Primary Filter
Pre-lter
-6-
Replacement Parts
Available online at www.vacmaster.com or call 1-866-384-8432.
Item Part No.
Felt Filter & Primary Filter 571029102
Foam Filter 571029103
Belt 571029105
Brushroll 571029104
Hose 571029101
3-in-1 Combination Tool 571029106
-7-
Lower Hose Connection
12
4
3
2. Install the hose onto the main body. Align the locking end of the hose with the
main body as shown, and lock the end of the hose by rotating to the left. Then
run the hose over the hose storage. Insert the other end of the hose into the
lower hose connection as shown until you hear a ‘click’.
GENERAL ASSEMBLY INSTRUCTIONS
1. Insert the wand into the main body until you hear a ‘click’.
Wand
-8-
3. Insert the combination tool onto the accessory storage as shown.
4. Make sure the upper cord hook is in the upright position as shown. Wrap the
power cord loosely around the upper and lower cord hooks.
Upper Cord Hook
Lower Cord Hook
3-in-1 Combination
Tool
-9-
5. Lock power cord plug onto the power cord.
WARNING
Wrapping the cord too tightly with excessive stress on the cord may cause cord
damage. A damaged cord is an electrical shock hazard and could cause personal
injury or damage.
Power Cord Plug
Power Cord
-10-
OPERATING INSTRUCTIONS
Using Your Upright Vacuum Cleaner
NOTE: Make sure the vacuum cleaner is completely assembled and the dust cup
is empty before using. Do not operate vacuum cleaner without lters in place.
1. Turn the upper cord hook to either side to release the power cord.
2. Detach the power cord plug from the power cord.
3. Be sure the power cord is locked into the upper locking notch as shown. This
will help manage the power cord when operating the vacuum cleaner.
4. Plug the power cord into an outlet located near the oor.
Upper Locking Notch
