User’s manual

Accessory handset for

use with VTech models

CS6419/CS6428/CS6429

www.vtechphones.com

Model: CS6409

Congratulations

on purchasing your new VTech product. Before using this

telephone, please read Important safety instructions

on pages 9-10 of this manual.

This manual has instructions on how to set up and register your

new handset. For complete instructions on using the handset, see

the user’s manual that came with your telephone base.

If you cannot nd your user’s manual, you can view or download it at

www.vtechphones.com. In Canada, go to www.vtechcanada.com.

The ENERGY STAR®program (www.energystar.gov)

recognizes and encourages the use of products that save

energy and help protect our environment. We are proud to

mark this product with the ENERGY STAR®label indicating it

meets the latest energy efciency guidelines.

Compatible with

Hearing Aid T-Coil

TIA-1083

Telephones identied with this logo have reduced noise and

interference when used with most T-coil equipped hearing

aids and cochlear implants. The TIA-1083 Compliant Logo is

a trademark of the Telecommunications Industry Association.

Used under license.

Table of contents

Getting started............................................................................1

Parts checklist ..............................................................................1

Battery installation ........................................................................2

Battery charging ...........................................................................3

Add and register a handset .........................................................4

Replace a handset........................................................................5

Handset layout .............................................................................6

Appendix .....................................................................................8

Battery ..........................................................................................8

Important safety instructions.........................................................9

Precautions for users of implanted cardiac pacemakers............11

Operating range..........................................................................11

Maintenance...............................................................................12

About cordless telephones .........................................................13

The RBRC®seal .........................................................................13

Limited warranty .........................................................................14

FCC, ACTA and IC regulations ..................................................17

Technical specications..............................................................19

Parts checklist

Your telephone package contains the following items. Save your

sales receipt and original packaging in case it is necessary to ship

your telephone for warranty service.

Handset

User’s manual

Getting started

Charger and charger adapter

Battery

Battery compartment

cover

To purchase a replacement battery or power adapters, visit our

website at www.vtechphones.com or call 1 (800) 595-9511. In

Canada, go to www.vtechcanada.com or call 1 (800) 267-7377.

Getting started

Battery installation

Install the battery as shown below.

Plug the battery connector securely into the socket inside the

handset battery compartment.

Place the battery with the label THIS SIDE UP facing up and the

wires inside the battery compartment.

Align the cover flat against the battery compartment, then slide it

towards the center of the handset until it clicks into place.

Charge the handset by placing it in the telephone base or

charger. The CHARGE light is on when the handset is charging.

CHARGE light

remains on when

charging.

3 4

If the handset will not be used for a long time, disconnect

and remove the battery to prevent possible leakage.

To purchase a replacement battery, visit our website at

www.vtechphones.com or call 1 (800) 595-9511. In Canada,

go to www.vtechcanada.com or dial 1 (800) 267-7377.

•

Battery charging

Once you have installed the battery, the screen indicates the

battery status (see the table below). If necessary, place the

handset in the telephone base or charger to charge the battery.

For best performance, keep the handset in the telephone base or

charger when not in use. The battery is fully charged after

10 hours of continuous charging. See the table on page 8 for

battery operating times.

If the screen is blank, you need to charge the handset without

interruption for at least 30 minutes to give the handset enough

charge to use the telephone for a short time. When the battery is

low, the handset plays four short beeps and shows LOW BATTERY

along with a flashing icon. When you are on a call in low battery

mode, the handset plays four short beeps every 50 seconds.

The following table summarizes the battery charge indicators and

actions to take.

Getting started

Battery indicators Battery status Action

The screen is blank,

or shows

PLACE IN CHARGER

and flashes.

Battery has no

charge or very

little charge. The

handset cannot

be used.

Charge without

interruption (at least

30 minutes).

The screen shows

LOW BATTERY and

flashes.

Battery has

enough charge to

be used for a

short time.

Charge without

interruption (at least

30 minutes).

The screen shows

HANDSET X.

Battery is charged. To keep the battery

charged, place it in the

telephone base or charger

when not in use.

If you place the handset in the telephone base or charger without

plugging in a battery, the screen displays NO BATTERY.

After you install your telephone or power

returns following a power outage, the handset

will prompt you to set the date and time. To skip

setting the date and time, press OFF/CANCEL.

SET DATE

--/--/--

Add and register a handset

Each new handset (CS6409) must be registered with the

telephone base before use. When first purchased, each

expansion handset shows 1.PRESS FIND HS ON BASE 4 SEC

and 2.THEN PRESS # ON HANDSET alternately. You may need

to charge the handset before registering it to the telephone base.

For more details on battery charging, see the table on page 3.

To register a handset:

Place the unregistered handset in the telephone base or

charger. If 1.PRESS FIND HS ON BASE 4 SEC and

2.THEN PRESS # ON HANDSET do not appear alternately

on the handset screen after a few seconds, remove the

handset and place it in the telephone base or charger again.

On the telephone base, press and hold

/FIND HANDSET for about four seconds

until the red IN USE light on the telephone base

turns on.

On the handset, press #(pound key) and the

handset shows REGISTERING.....

PLEASE WAIT. The handset shows HANDSET REGISTERED

and you hear a beep when the registration process completes.

It takes about 60 seconds to complete.

When the registration process is complete, the newly registered

handset is assigned the next available handset registration

number. For instance, if you already have HANDSET 1, the next

registered handset will be HANDSET 2.

Getting started

If the registration fails, the handset shows REGISTRATION

FAILED, then the handset shows 1.PRESS FIND HS ON BASE

4 SEC and 2.THEN PRESS # ON HANDSET alternately. To

reset the handset, remove the handset from the telephone

base and place it back in. Try the registration process again.

You cannot register a handset if any other system handset

is in use.

To reset the telephone, unplug the power and the battery for

a few seconds then plug them back in.

Only one handset can register to the telephone base at a time.

•

Replace a handset

If you want to replace a handset or reassign the designated

handset number of a registered handset, you must deregister all

the handsets and then individually register each handset.

To make deregistration easier, read all of the instructions below

before you begin.

To deregister all handsets:

Press and hold /FIND HANDSET on the telephone base for

about 10 seconds until the IN USE light on the telephone base

turns on and starts to flash.

Press and release /FIND HANDSET again. You must press

/FIND HANDSET while the IN USE light is still flashing. The

IN USE light flashes for approximately five seconds. If the light

stops flashing, start again at Step 1.

The deregistration process takes about 10 seconds to

complete. All handsets show 1.PRESS FIND HS ON BASE 4

SEC and 2.THEN PRESS # ON HANDSET alternately when

the deregistration process completes.

If deregistration fails, you may need to reset the telephone and

try again.

To reset:

Pick up the registered handset and then press /FLASH.

Press OFF/CANCEL and place the handset back in the

telephone base.

-OR-

Unplug the power from the telephone base, then plug it back in.

•

You cannot deregister handsets if any other system handset is

in use.

You cannot deregister handsets if any other system handset is

in use.

Getting started

/VOLUME

Press to enter the directory when the

telephone is not in use.

Press to scroll up while in a menu, or in

the directory, call log or redial list.

During a call, press to increase the

listening volume.

During message playback, press to increase

the listening volume (for handsets registered to

CS6428 and CS6429 base only).

When entering numbers or names in the

directory, press to move the cursor to the right.

Handset layout

Getting started

(speakerphone)

Press to make or

answer a call.

During a call, press

to switch between the

speakerphone and

the handset.

CHARGE light

On when the handset is charging in the

telephone base or charger.

MUTE/DELETE

While on a call, press to mute the microphone.

While using the dialing keys, press to delete

digits or characters.

While the handset is ringing, press to silence

the ringer temporarily.

When reviewing the redial list, directory or call

log, press to delete the displayed entry.

/FLASH

Press to make or answer a call.

During a call, press to answer an incoming call

when you receive a call waiting alert.

While reviewing a call log entry, press repeatedly

to add or remove 1 in front of the call log entry

before dialing or saving it to the directory.

TONE

Press to switch to tone dialing temporarily when

using the pulse service.

Handset layout

Getting started

MENU/SELECT

Press to show the menu.

While in a menu, press to select an item, or

save an entry or setting.

OFF/CANCEL

During a call, press to hang up.

While the handset is ringing, press to silence

the ringer temporarily.

While the telephone is not in use, press and hold

to erase the missed call indicator.

While in a menu, press to exit to the previous

menu, or press and hold to exit to idle mode.

#( pound key)

Press repeatedly to show other dialing options

when reviewing a call log entry.

INT (intercom)

Press to start an intercom conversation or transfer a call.

REDIAL/PAUSE

Press to review the redial list.

While dialing or entering numbers into the directory,

press and hold to insert a dialing pause.

CID /VOLUME

Press to review the call log when the telephone

is not in use.

Press to scroll down while in a menu, or in the

directory, call log or redial list.

During a call, press to decrease the listening

volume.

During message playback, press to decrease

the listening volume (for handsets registered to

CS6428 and CS6429 base only).

When entering numbers or names in the

directory, press to move the cursor to the left.

Dialing keys

Press to enter numbers or characters.

Autres manuels pour CS6409

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels V-tech Combiné

V-tech

V-tech Five Handset Expandable Cordless Phone System with BLUETOOTHA Wireless... Manuel utilisateur

V-tech

V-tech CS6199-4 Manuel utilisateur

V-tech

V-tech DECT 6.0 CS6219 Manuel utilisateur

V-tech

V-tech VC7100A Manuel utilisateur

V-tech

V-tech CS6719-2 Manuel utilisateur

V-tech

V-tech DS6600 Manuel utilisateur

V-tech

V-tech I5808 - Cordless Extension Handset Guide de l'utilisateur

V-tech

V-tech CS6219 Manuel utilisateur

V-tech

V-tech CTM-S2110 Manuel utilisateur

V-tech

V-tech Dect 6.0 DS6211 Manuel utilisateur

V-tech

V-tech DS6101 Manuel utilisateur

V-tech

V-tech IP 811 Manuel utilisateur

V-tech

V-tech 17450 Manuel utilisateur

V-tech

V-tech DS6601 Manuel utilisateur

V-tech

V-tech USB7050 Manuel utilisateur

V-tech

V-tech VSP601 Manuel utilisateur

V-tech

V-tech CS6400 Manuel utilisateur

V-tech

V-tech DS6421 Manuel utilisateur

V-tech

V-tech USB 711 Manuel utilisateur

V-tech

V-tech I5808 - Cordless Extension Handset Manuel utilisateur

V-tech

V-tech LS6204 - Cordless Extension Handset Manuel utilisateur

V-tech

V-tech i5803 - Cordless Extension Handset Guide de l'utilisateur

V-tech

V-tech CS6509 Manuel utilisateur

V-tech

V-tech Analog Contemporary Series Manuel utilisateur

Manuels Combiné populaires d'autres marques

Swissvoice

Swissvoice ePure HD Manuel utilisateur

Philips

Philips TD6736/BH051P Manuel utilisateur

ASCOM

ASCOM I62 - Manuel utilisateur

LG-Ericsson

LG-Ericsson LIP-9010 Manuel utilisateur

GE 1583 Manuel utilisateur

iiNet

iiNet Handset Manuel utilisateur

ASCOM

ASCOM 9p23 Manuel utilisateur

AT&T

AT&T DLP70110 Manuel utilisateur

AirCell

AirCell ST 3100 Manuel utilisateur

Eaton

Eaton HHIR-LCD-PROG Instructions de montage

Mitel

Mitel 112 Manuel utilisateur

SBC

SBC SBC-381H Manuel utilisateur

Mitel

Mitel 5602 Manuel utilisateur

ASCOM

ASCOM d81 Messenger Instructions d'installation

SpectraLink

SpectraLink 7522 Manuel utilisateur

Avaya

Avaya L100 Series Comment utiliser

ooma

ooma HD2 Handset Manuel utilisateur

Yealink

Yealink IPW56 Manuel utilisateur
