V-Tec AT27SDTD7-V1 Manuel utilisateur
ENGLISH
VIDEO DOOR PHONE SYSTEM
USER MANUAL
C5-ENG-AT27SDTD7-V1
1
2
3
409/08/2011 Tue. 09:58
Monitor
User Setup Estate
Management
Intelligent
Home Close
Manual
Intercom Direct Call
Guard Unit Alarm
Security Multimedia
●
●Slots●or●openings●in●the●back●of●the●monitor,●are●provided●for●
ventilation●and●to●ensure●reliable●operation●of●the●video●monitor●
or●equipment●and●to●protect●if●from●overheating.●These●openings●
must●not●be●blocked●or●covered.●The●monitor●●should●never●be●
placed●near●or●over●a●radiator●or●heat●register●and●should●not●be●
placed●in●a●built-in●installation●such●as●a●bookcase●unless●proper●
ventilation●is●provided.
●
●All●parts●should●be●protected●from●violence●vibration.●And●not●
allow●be●impacting,●knocking●and●dropping.
●
●For●clean●the●LCD●screen,●using●hands●or●wet●cloth●is●forbidden.
●
●Please●do●the●cleanness●with●soft●cotton●cloth,●please●do●not●use●the●
organic●or●chemical●clean●impregnate.●If●necessary,●please●use●pure●
water●or●dilute●soap●water●to●clean●the●dust.
●
●Image●distortion●may●occur●if●the●video●door●phone●is●mounted●
too●close●to●magnetic●field●e.●g.●Microwaves,●TV,●computer●etc.
●
●Please●keep●away●the●video●door●monitor●from●wet,●high●
temperature,●dust,●and●caustic●and●oxidation●gas●in●order●to●avoid●
any●unpredictable●damage.
●
●Do●NOT●open●the●device●in●any●condition,●call●the●administrator●
for●help●if●there●is●any●problem●or●mulfunction●happens.●
Precautions
Contents
The●model●you●purchase●maybe●haven't●all●functions●mentioned●here,●but●
the●functions●contained●in●your●product●can●be●found●in●this●manual.
1. Parts and Functions ....................................................................... 1
2. Basic Door Release Operation ...................................................... 2
3. About Home screen ....................................................................... 2
4. Basic Setup Instructions ................................................................ 3
5.Memory SD card ............................................................................ 7
6.Intercom function ........................................................................... 9
7. Defense Alarm Operation(optional) .............................................. 10
8. Remote Control Function(optional) .............................................. 11
9. Estate Management ....................................................................... 12
10. Intelligent Home ......................................................................... 12
11. Specications .............................................................................. 12
1. Parts and Functions
1
Key Functions
1.●LCD●screen ●
●Display●the●images●from●outdoor●station.Touch●operation.
2.●LED●indicator ●
●Normally●light●on●when●in●use
3.●Unlock●key ●
●Press●to●release●the●door●for●visitors●during●talking●or●monitoring.
4.●Mon/Talk●key ●
●Press●to●view●the●outside●condiction.
●
●Press●to●talk●with●the●visitors●while●receiving●a●call.
5.●Menu●key ●
●Press●to●open●a●list●of●actions●available●on●the●current●screen.
6.●Microphone ●
●Receives●sound●from●the●user.
7.●Speaker ●
●Output●sound●from●the●outdoor.
8.●Mounting●Hook ●
●Used●to●hang●up●the●monitor●unit
9.●Connection●Port ●
●Bus●line●terminal
10.SD●card●slot ●
●Press●to●activate●the●intercom●function●page.
1
2
3
4
5
8
9
10
6
7
2. Basic Door Release Operation
1.● Input●room●numbers●on●Door●Station●of●
the●building●or●main●entrance,●the●Monitor●
rings,●at●the●same●time,●the●screen●displays●
the●visitor's●image.
2.● Press●Mon/TALK●Button●on●monitor●or●
touch ●icon●on●screen,●you●can●talk●
with●the●visitor●for●90●seconds.●During●
communication,●press●M o n / TA L K●
Button●or●touch ●icon●again●to●end●the●
conversation.●If●nobody●answers●the●phone,●
the●screen●will●be●turned●off●automatically●
after●30●seconds.●
3.● During●calling●or●talking●state,●Press●
UNLOCK Button●●or●touch●● ●icon●to●open●
the●door●for●the●visitor.
4.● When●the●monitor●is●in●standby●mode,●press●
Mon/TALK●Button,●you●can●see●the●outside●
view.During●monitoring,pressing●UNLOCK
Button●or●touch●● ●icon●can●open●the●door.
2
3. About Home screen
The●Home●screen●is●your●starting●point●for●
using●all●the●applications●on●your●monitor.●You●
can●customize●your●Home●screen●to●display●
applications,●logos,●and●languages.
To●open●the●home●screen●page,●tap●● Menu●key●
twice●on●the●monitor●or●press●the●LCD●screen●
anywhere●twice.
4. Basic Setup Instructions
Ring Tone Settings
Total●12●pieces●ring●tones●can●be●selected.
You●can●set●different●ring●tones●to●identify●
different●calls●from●Door●Station●call,Intercom●
call●or●Door●Bell●call.
To●open●ring●tone●setting●page:
1.●On●the●home●screen,●touch●User Setup● ●
icon.
2.●Touch●Door Station call tone/Intercom call
tone/Door Bell call tone.
3.●Choose●a●ring●tone●you●want●,●then●touch●
●icon●to●save●and●exit,●the●ring●tone●will●be●
performed●immediately.●Or●touch ●icon●to●
unsave●and●exit.
3
Ring Volume Setting
You●can●set●a●ring●volume●for●day●time,6:00●
AM~18:00●PM●is●the●day●time●by●default.
To●open●ring●volume●setting●page:
1.●On●the●home●screen,●touch●User Setup● ●
icon.
2.●Touch●Ring Volume●item.
3.●Touch●Adjust+●to●increase●the●volume●or●
touch●Adjust-●to●decrease●the●volume.
4.●Touch ●icon●to●save●and●exit,●the●setting●
will●be●performed●immediately.
4
Night Ring Volume Setting
You●can●activate●a●ring●volume●for●night●
time,18:00●PM~6:00●AM●is●the●night●time●by●
default.
To●open●night●ring●volume●setting●page:
1.●On●the●home●screen,●touch●User Setup● ●
icon.
2.●Touch●Night●Ring Volume●item.
3.●Touch●Adjust+●to●increase●the●volume●or●
touch●Adjust-●to●decrease●the●volume.
4.After●you●set●a●appropriate●value,you●should●
touch●Night Ring●icon●to●activate●the●function.●
5.●Touch● ●icon●to●save●and●exit,●the●setting●will●
be●performed●immediately.
Note:●If●you●adjust●the●volume●to●0,●mute function●will●be●activated.●It's●very●useful●when●
you●don't●want●to●be●disturbed.
Monitor Time Setting
90●seconds●is●the●default●monitor●time.But●you●
can●change●the●value●at●any●time.
To●open●monitor●time●setting●page:
1.●On●the●home●screen,●touch●User Setup● ●
icon.
2.●Touch●Monitor Time●item.
3.●A●digital●keypad●will●be●shown,input●the●value●
by●touching●the●keypad.
4.●Touch● key●to●cancel●the●input,and●touch●
key●to●save●the●setting.
5.●Touch●Cancel● ●button●to●return●last●page.
Monitor time set:
min:[01] sec:[30]
5
Date and Time setting
You●can●reset●the●date●and●time●shown●on●the●
calendar●page.●Note●that●the●date/time●won't●
lose●even●if●the●power●is●off.
To●open●clock●setting●page:
1.●On●the●home●screen,●touch●User Setup● ●
icon.
2.●Touch●Clock●item.
3.●Touch●the●digital●keypad●to●input●the●correct●
time.
4.●Touch● key●to●cancel●the●input,and●touch●
key●to●save●the●setting.
5.●Touch●Cancel● ●button●to●return●last●page
Restore to default setting
The●restore●to●default●function●allows●the●user●to●
recover●the●settings●to●factory●setting.Note●that●
this●operation●is●irreversible●and●will●not●change●
the●time●setting.
To●open●restore●to●default●setting●page:
1.●On●the●home●screen,●touch●User Setup● ●
icon.
2.●Touch●Restore to default●item,a●message●of●
"Restore●to●default?"●will●be●asked.
3.●Touch●Restore to default●button●
again,restore●to●default●setting●will●be●performed.
2011-08-09 16:22
Screen Setting
To●open●screen●setting●page:
1.●When●the●Monitor●is●in●monitoring●or●talking●
state,●Press●Adjust● ●icon.
2.●Touch●Brightness/Color/Scene/Talk
volume●item.
3.●Touch● ●/● ●icon●to●decrease●or●increase●the●
value.Settings●will●be●performed●immediately.
6
1.● ●Scene●mode●selection:●Total●4●screen●modes●can●be●selected●in●sequence:●
Normal, User,
Soft
●and●
Bright.
Note●that●only●at●
User mode
that●you●can●modify●
Brightness
●or●
colour.
whenever●you●modify
Brightness
or●
colour
●item
,
the
Scene mode
item●will●be●set●to●
User
●
mode●automatically.●
2.● The●
Brightness
●and●
Colour
●item●is●for●the●image●quality●setting,●adjust●the●value●to●get●the●
best●image●you●like.
3.● The●●
Talk Volume
●item●is●talking●volume●adjustment.
4.● Note●that●all●the●modifications●will●be●done●immediately●after●the●operation.●
5.Memory SD card
7
Your●video●phone●comes●with●a●removable●microSD●memory●card●where●you●can●store●
multimedia●files,●such●as●digital●photos●,images●and●so●on.
To●install●the●memory●card:
1.●●Insert●the●memory●card●with
the●gold●contacts●facing●up.
2.●Push●the●card●in●until●it●clicks.
To●remove●the●memory●card,
press●the●card●in●and●release.
1
2
3
4
Micro SD card
Note:
1.● The●monitor●has●been●equipped●with●a●built-in●memory●(about●120●MB)●together●with●a●
microSD●card.●Maximum●16●GB●microSD●card●can●be●supported.●
2.● Photo●frame●function,●each●photo●playing●will●last●for●5●seconds,●More●pictures●in●the●
SD●card,●longer●time●for●triggering●the●function,●●800●pictures●is●supported●in●inner●
memory.●With●2G●SD●card,more●than●30000●pictures●can●be●supported.
3.● Must●use●T-views●album●software●tool●to●transform●the●JPG●format●photos●●took●by●
digital●camera●to●TVS●format●photos●that●can●be●viewed●on●Monitor.
4.● The●captured●pictures●will●be●saved●in●a●folder●named●by●date,note●that●the●pictures●
recording●every●day●will●be●saved●in●different●folders●which●automatically●generated●
every●day.
5.● The●captured●pictures●in●the●built-in●memory●can●be●copied●to●the●microSD●card,●and●●
you●should●use●T-views●●memo●software●tool●to●convert●the●pictures●to●JPG●format●that●
can●be●seen●on●the●computer.●(select●the●pictures(press●Ctrl+A●to●select●all)->>click●the●
right●key●of●the●mouse●->>choose●transfer●selected●to●JPG●item->>save●the●pictures●on●
computer)
6.● When●the●built-in●memory●is●full,the●oldest●picture●will●be●deleted●to●make●room●for●
new●record●.
7.● The●built-in●memory●can●be●formatted●by●the●Monitor,but●microSD●card●cannot,you●
should●format●the●microSD●card●on●computer.●
8.● Avoid●to●plug●in/out●the●SD●card●when●the●monitor●is●under●operation.
9.● Playing●will●be●interrupted●by●the●calling●from●outdoor●station.
