Uplus Lighting LED PROFILE FIX Manuel utilisateur

User manual

LED PROFILE FIX

Please read the instructions carefully before use

TABLE OF CONTENTS

1. Safety Instructions……………………………………………………………………………3

2.Technical Specifications………………………………………………………………………4

3.Descriptions………………………………………………………………………………………5

4.Unpacking…………………………………………………………………………………………5

5.Control Menu ……………………………………………………………………………………6-7

6.DMX Channels ……………………………………………………………………………………7

7.Dimension …………………………………………………………………………………………8

8.Trouble Shooting…………………………………………………………………………………9

9.Fixture Cleaning………………………………………………………… ………………………9

STATEMENT

The product has well capability and intact packing when leave factory. All of the user should

comply with warning item and manual, any misuse cause of the damages are not included in our

guarantee, and also can not be responsible for any malfunction & problem owing to ignore the

manual.

1.Safety Instructions

Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also

receive this instruction booklet.

•Unpack and check carefully there is no transportation damage before using the unit.

•Before operating, ensure that the voltage and frequency of power supply match the power requirements of the

unit.

•It’s important to ground the yellow/green conductor to earth in order to avoid electric shock.

•The unit is for indoor use only. Use only in a dry location.

•The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent surfaces. Be sure

that no ventilation slots are blocked.

•Disconnect main power before replacement or servicing.

•Make sure there are no flammable materials close to the unit while operating as it is fire hazard.

•Use safety cable when fixes this unit. DO NOT handle the unit by taking its head only, but always by taking its

base.

•Maximum ambient temperature is Ta: 40℃. DO NOT operate it where the temperature is higher than this Unit

surface temperature may reach up to 85℃. DO NOT touch the housing bare-hand during its operation. Turn off

the power and allow about 15 minutes for the unit to cool down before replacing or serving.

•the event of serious operating problem, stop using the unit immediately.Never try to repair the unit by yourself.

Repairs carried out by unskilled people can lead to damage or malfunction. Please contact the nearest

authorized technical assistance center. Always use the same type spare parts.

•DO NOT touch any wire during operation as high voltage might be causing electric shock.

Warning:

•To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or moisture.

•The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly damaged.

Caution:

•There are no user serviceable parts inside the unit. DO NOT open the housing or attempt any repairs yourself.

In the unlikely event your unit may require service, please contact your nearest dealer.

Installation:

•The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly fixed to

avoid vibration and slipping while operating. And make sure that the structure to which you are attaching the unit

is secure and is able to support a weight of 10 times of the unit’s weight. Also always use a safety cable that can

hold 12 times of the weight of the unit when installing the fixture.

•The equipment must be fixed by professionals. And it must be fixed at a place where is out of the touch of

people.

2.Technical Specifications

Light Source:

LED POWER: 300W

LED Color: CW 5600k or WW 3200K (300W) COB LED

Color Rendering Index(CRI): Ra≥90

LED Life Time: over 50,000 hours

Power supply:

Voltage: AC100-240V

Max.power: 300W

Optics:

Fixed Lens: 19°/26°/36°/50°(optional)

LED Life Time: over 50,000 hours

Iris: optional

Color Frame: optional

Features:

Dimming Curve: 4 kinds dimming curve

PWM: 500HZ - 25000HZ optional

Strobe :1-25times/sec

Light body feature:

Focus: Can be adjusted by hand

Technology: High-quality optical system , glass reflector

Light body: Die casting Aluminum

Touch screen: LCD with touch screen

Feature of housing: High quality fireproof ,corrosion-resistance, Oxidation resistance

Control:

Control Protocol: RDM / DMX

Control System: DMX, Auto run and Master/Slave

DMX Channels: 1/2CH

Working Environment :

Working Temperature: -30~40℃

Cooling system: No noise fan (copper tube)

IP Grade: IP20

Package :

Dimensions: 611(D)*173(W)*480(H)mm

Net Weight : 10.5kgs

Gross Weight: 12.5 kgs

Packing Size: 72*33*31.5 cm (1pc/carton)

3.Descriptions

·Warm or cool white ERS style fixture with output exceeding a tungsten 750 W source

·Ultra smooth 16-bit dimming of master dimmer and individual colors

·Flat, even field of light with superior color mixing

·RDM (Remote Device Management) for added flexibility

·Adjustable PWM (Pulse Width Modulation) to avoid flickering on camera

·Selectable dimming curve: Standard mode, Incandescent mode, quick mode and linear mode

·LCD touch screen

·Virtually silent operation for use in studio and theatre applications

4.Unpacking

Thank you for choosing our LED PROFILE FIX. For your own safety, please read this manual before installing the

device. This manual covers the important information on installation and applications. Please install and operate

the fixture with following instructions. Meanwhile, please keep this manual well for future needs.

LED PROFILE FIX is made of a new type of high temperature strength of die cast aluminum casing with nice

outlook. The fixture is designed and manufactured strictly following CE&RoHS standards, complying with

international standard DMX512 protocol. It's available independently controlled and linkable with each other for

operation. And it is applicable for large-scale live performances, theater, studio, nightclubs and discos.

LED PROFILE FIX adopts 1PCS 300W COB LED (available for WW) which features high brightness and stability.

Please carefully unpack it when you receive the fixture and check whether it is damaged during the transportation.

And please check whether the following items are included inside the box:

5.Control Menu

Operation Status

Mode

Display

Description

DMX Mode

Axxx

“A”stand for standard channel mode,，“xxx”stand for ID address

Dxxx

“D”stand for basic channel mode，“xxx”stand for ID address

Manual Mode

S-MC

“S”stand for stand alone mode，“MC”stand for“Mixed Color”

DMX Settings

Operation

Option

Description

DMX Start

Address

Press key of “OK” enter to edit mode, press “UP”

and ”down” to edit the DMX address

1~512

DMX Profile

Press key of “OK” change the DMX channel mode

2CH

Standard Channel Mode

1CH

Basic Channel Mode

Master Mode Choice

Operation

Vice Menu description

White Point

Press Key of “OK” to choose mode

Choose color temperature

Quick Color

Same as before

Choose inner setting color

Mixed Color

Same as before

Choose the color and strobe setting

Status

Description

Software

Name of software

Version

Temperature

Show the temperature of lighting fixture

DMX Status

With“OK”（Slavemode，withsignal），“NONE”（Slavemode，nosignal）、 “Alone”（alone）

Settings

Operation

Option

Description

Touch Screen Calibration

Touch screen adjust

Dimmer Frequency

Change the dimmer

frequency

500HZ

……

Each 100HZ for increase or

decrease

25000HZ

Dimmer Curve

Change dimmer curve

Standard

Incandescent

Linear

Quick

Over Temperature

Temperature setting

45~95

Each 5 for increase or decrease

Backlight

Adjust the display

brightness

10%~100%

Each 5% for increase or decrease

Backlight Timeout

Screen protect setting

No screen protect or

black screen from

0~ 60 second

Each 5 for increase or decrease

Load Factory Settings

Reset

6.DMX Channels

Model – CH2

Model – CH1

Channel

Data

Function

0~255

Color 1

Channel

Data

Function

Remark

0~255

Dimmer

0~10

No function

11~255

Strobe speed（255 is the fastest）

7.Dimension

Size of the fixture: 767.6(D)*297.3(W)*273.7(H)mm

8.Trouble Shooting

ollo

ing

few

oble

occu

uring

ope

tion

leshooting

The

does

work

ght

Check

nect

ion of p

owe

eas

ure

ins

volt

Check

pow

LED

responding

LED

on.

che

nectors,

link

ope

espons

el,

che

ess

etti

ity

nter

ittent

oble

che

ins

onn

ecto

PCB

nit

the

iou

ntroller

Check

or run

lon

volta

les

terfer

ence

inter

face

circui

One

the

cha

ing

tep

moto

dam

the

nect

PCB

oken.

oto

’

ive

PCB

ndition

9.Fixture Cleaning

The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to

optimize light output. Cleaning frequency depends on the environment in which the fixture operates:

damp, smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics.

Clean with soft cloth using normal glass cleaning fluid.

Always dry the parts carefully.

Clean the external optics at least every 20 days. Clean the internal optics at least every 30/60 days.
