ASSEMBLY INSTRUCTIONS
Revised 01/30/15 Page 1 of 2
PARTS LIST
PARTS BAG UPC 2853 5.5” up to 48” Wide 1-Tier Acrylic Card Rack
TOOLS REQUIRED: Flathead Screwdriver (Slatwall)
Drill with 3/8” Drywall Bit & Phillips Screwdriver (Drywall)
EF
G
C
C
B
A
Screw Posts 2-3 A
Slatwall Adapters 2-3 B
Nuts 2-3 C
Plastic Wall Togglers 2-3 D
Phillips Head Screws 2-3 E
Card Clips 1-8 F
D
PART Quantity Reference
Rack 1G
C
A
B
Slatwall Assembly
Insert Card Clip(s) (F) into
Rack (G).
NOTE: Assemble for EITHER Slatwall or Drywall, not both.
NOTE: Quantities of parts vary with width of
Rack chosen.
OR
5.5” up to 48”
(wide)
1
2
B
A
A
A
A
G
G
Align hole in Slatwall Adapter (B) with back side of hole in Rack (G).
Prongs extend back toward Slatwall and up. Attach using Screw Post (A)
from front and Nut (C) on back.
F
F
F
D
D
D
D
D
Page 2 of 2
E
E
Drywall Assembly
WALLWALL
WALLWALL
D
E
G
D
NOTE: Assemble for EITHER Slatwall or Drywall, not both.
OR
Insert Card Clip(s) (F) into
Rack (G).
GE
G
E
E
E
E
3
G
F
G
F
E
E
E
Determine position on wall and drill
hole with 3/8” drywall bit.
Squeeze Wall Toggler (D) flat
and insert into hole.
Tap flange flush with wall.
Place Rack (G) against Wall Toggler (D)
and insert Phillips Head Screw (E),
tightening until secure.
12
