SRM80+ PLANETARY MIXER

MAINTENANCE & PARTS MANUAL

Persons under age 18 are not permitted to operate or have accessibility to operate this

equipment per U.S. Dept. Of Labor Employment Standards Administration Fact Sheet No.

ESA913.

SRM60/80 SERVICE REV A

TABLE OF CONTENTS

DESCRIPTION PAGE

TABLE OF ONTENTS............................................................................................................I

LIST OF ILLUSTRATIONS.....................................................................................................II

1. TROUBLE SHOOTING GUIDE...........................................................................................1.1

2. ME HANI S MAINTENAN E

VT BELTS......................................................................................................................2.1

BELT REPLA EMENT...................................................................................................2.2

BELTADJUSTMENT......................................................................................................2.2

MOTOR............................................................................................................................2.4

BOWL LIFTADJUSTMENT...........................................................................................2.4

LUBRI ATION................................................................................................................2.5

REMOVAL OF TOP OVER ..........................................................................................2.6

3. TRANSMISSION

REMOVAL .......................................................................................................................3.1

TRANSMISSION PARTS LIST.......................................................................................3.3

BEATER HEAD ASSEMBLY..........................................................................................3.5

BEATER HEAD PARTS LIST.........................................................................................3.6

POWER TAKE-OFF ASSEMBLY...................................................................................3.7

POWER TAKE-OFF PARTS LIST ..................................................................................3.8

INPUTASSEMBLY.........................................................................................................3.9

INPUTASSEMBLY PARTS LIST...................................................................................3.10

VERTI AL SHAFT ASSEMBLY....................................................................................3.11

VERTI AL SHAFT ASSEMBLY PARTS LIST .............................................................3.12

REASSEMBLY ................................................................................................................3.13

4. BOWL SUPPORT ASSEMBLY

BOWL SUPPORT REMOVALAND DISASSEMBLY...................................................4.1

BOWL SUPPORT ASSEMBLY PARTS LIST.................................................................4.3

5. BOWL LIFT SLIDE & FRAMEASSEMBLY

REMOVALAND DISASSEMBLY..................................................................................5.1

BOWL LIFT SLIDE & FRAMEASSEMBLY PARTS LIST ..........................................5.3

6. POWER BOWL LIFT SLIDE & FRAMEASSEMBLY

REMOVALAND DISASSEMBLY..................................................................................6.1

ASSEMBLYAND INSTALLATION...............................................................................6.2

POWER BOWL LIFT SLIDE & FRAMEASSEMBLY PARTS LIST ...........................6.5

7. SPEED ONTROLASSEMBLY

REMOVALAND DISASSEMBLY..................................................................................7.1

ASSEMBLYAND INSTALLATION...............................................................................7.3

SPEED ONTROLASSEMBLY PARTS LIST...............................................................7.5

8. DRIVE ASSEMBLY

REMOVALAND DISASSEMBLY..................................................................................8.1

DRIVE ASSEMBLY PARTS LIST ..................................................................................8.2

9. MIXER HOUSING ASSEMBLY

MIXER HOUSING...........................................................................................................9.1

MIXER HOUSING ASSEMBLY PARTS LIST...............................................................9.1

10. APPENDIX

ELE TRI AL INSTALLATION FOR 3 PHASE MIXERS .........................................10.1

Page I

LIST OF ILLUSTRATIONS

DESCRIPTION PAGE

FIGURE 1 OVERALL VIEW OF MIXER....................................................................................III

FIGURE 2 UTAWAY VIEW OF MIXER...................................................................................IV

FIGURE 3 LUBRI ATION DIAGRAM......................................................................................2.5

FIGURE 4 TRANSMISSION ASSEMBLY.................................................................................3.4

FIGURE 5 BEATER HEAD ASSEMBLY....................................................................................3.6

FIGURE 6 POWER TAKE-OFF ASSEMBLY (PTO)..................................................................3.8

FIGURE 7 INPUTASSEMBLY.................................................................................................3.10

FIGURE 8 VERTI AL SHAFTASSEMBLY............................................................................3.12

FIGURE 9 TRANSMISSION AND SHAFTS ASSEMBLY DIAGRAM..................................3.14

FIGURE 10 BOWL SUPPORT ASSEMBLY.................................................................................4.4

FIGURE 11 BOWL LIFT SLIDE AND FRAME ASSEMBLY .....................................................5.4

FIGURE 12 POWER BOWL LIFT SLIDE AND FRAME ASSEMBLY......................................6.6

FIGURE 13 SPEED ONTROLASSEMBLY...............................................................................7.6

FIGURE 14 DRIVE ASSEMBLY...................................................................................................8.2

FIGURE 15 MIXER HOUSING ASSEMBLY...............................................................................9.2

FIGURE 16A WIRING DIAGRAM 208-230V, 60HZ, 1PH / 220-240V, 50HZ, 1PH..................10.2

FIGURE 16B WIRING DIAGRAM 208-230V, 60HZ, 3PH / 220-240V, 50HZ, 3PH..................10.3

FIGURE 16 WIRING DIAGRAM 460V, 60HZ, 3PH / 280-400V, 50HZ, 3PH .........................10.4

FIGURE 16D WIRING DIAGRAM WITH POWER BOWL LIFT

208-230V, 60HZ, 1PH / 220-240V, 50HZ, 1PH..............................................10.5

FIGURE 16E WIRING DIAGRAM WITH POWER BOWL LIFT

208-230V, 60HZ, 3PH / 220-240V, 50HZ, 3PH...............................................10.7

FIGURE 16F WIRING DIAGRAM WITH POWER BOWL LIFT

460V, 60HZ, 3PH / 380-400V, 50HZ, 3PH ...............................................10.9

Page II

OVERALLVIEW OF MIXER

FIGURE 1

1. BEATER HEAD 12. START BUTTON

2. HUTE 13. STOP BUTTON

3. SAFETY RING ASSEMBLY 14. BOWL LIFT HANDLE

4. MAGNET 15. REAR A ESS PANEL

5. No.12 HUB 16. AP

6. THUMB S REW 17. BOWL SUPPORT

7. UPPER MOUNTING BRA KET 18. BOWL LAMP

8. TIMER (OPTIONAL) 19. BOWL

9. SPEED ONTROL LEVER 20. BOWL SUPPORT PIN

10. SPEED INDI ATOR LABEL 21. BOWL MOUNTING BRA KET

11. ORD 22. LOWER MOUNTING BRA KET

Page III

CUTAWAY VIEW OF MIXER

FIGURE 2

Page IV

SRM60+ / SRM80+ TROUBLESHOOTING GUIDE

TROUBLE POSSIBLE CAUSE REMEDY

1. Mixer will not operate. 1.1 Timer not turned on.

1.2 Burned switch contacts.

1.3 Electrical service down.

1.4 Motor capacitor defective.

1.5 Burned out motor.

1.6 Magnetic starter tripped

due to overload.

1.7 Safety ring not mounted

or closed.

1.8 Bowl not raised.

1.1 Turn timer on.

1.2 Replace.

1.3 heck electrical service.

Replace fuse or reset circuit

breaker if necessary.

1.4 Replace motor.

1.5 Remove, test, repair or

replace.

1.6 Wait several minutes and

push start button.

1.7 Install safety ring.

1.8 Raise bowl completely.

2. Mixer runs but agitator

will not turn. 2.1 Drive belt off pulley

broken or slipping.

2.2 Key or pin sheared on

input shaft, input gear,

bevel pinion, bevel gear,

vertical shaft or beater

head shaft.

2.3 Shifting speed with mixer

not running.

2.1 Reinstall drive belt on motor

pulley and adjust mounting

center distance or replace.

2.2 Locate by step inspection and

replace defective part.

2.3 With mixer running, slowly

move speed control lever to

speed 4 then back to speed 1

to reengage belt.

3. Agitator stalls during

mixing. 3.1 Mixer bowl is overloaded.

3.2 Speed is set to high for

the mix.

3.3 Loose belt.

3.4 ontamination of belt

with grease.

3.1 Adjust contents of bowl.

3.2 Shift speed lower till action

rotates smoothly.

3.3 Readjust pulley center

distance to tighten belt.

3.4 lean pulleys and replace

belt.

4. Speed does not change

properly. 4.1 Loose belts.

4.2 Vari-speed pulley

inoperative.

4.1 Tighten or replace belts.

4.2 Remove, clean and lubricate

or replace.

5. Mixer runs, but

repeatedly cuts out and

stops.

5.1 Bowl overloaded.

5.2 Speed is set too high for

the mix.

5.3 Service voltage too low or

fluctuating.

5.4 Starter improperly set.

5.1 Adjust contents of bowl.

5.2 Reduce speed.

5.3 heck electrical voltage.

5.4 Adjust amp setting on starter.

6. Attachments contact

bottom of bowl. 6.1 Dented bowl.

6.2 Bowl height is set too

high.

6.1 Remove dent or replace bowl.

6.2 Readjust bowl height.

Page 1.1

SRM60+/ SRM80+ TROUBLESHOOTING GUIDE ( ONTINUED)

7. Attachments contact

side of bowl 7.1 Dented bowl.

7.2 Insufficient clearance

between bottom of bowl

and beater.

7.1 Remove dents or replace bowl.

7.2 Adjust bowl height.

8. Excessive noise 8.1 Gears need to be repacked

with grease.

8.2 Badly worn or frayed drive

belts.

8.3 Attachments hitting bowl.

8.4 Overloaded mixing bowl.

8.5 Defective bearings

8.1 Locate source by inspection

and repack with grease.

8.2 Replace belts.

8.3 Inspect for cause in items

6 & 7 above.

8.4 Adjust contents of bowl

8.5 Locate the defective bearings

and replace the assembly

Page 1.2

MECHANICS MAINTENANCE

Every six months a mechanic should perform the following inspection and maintenance.

CVT BELT

1. WARNING Start the mixer and adjust the speed control lever (Figure 1 [9]) to the lowest speed

(speed 1). Stop the mixer.

FOR SAFETY, DISCONNECT THE ELECTRICALPOWER SUPPLY CORD.

2. Remove the top cover (Figure 15 [4]) per section 2 mechanics maintenance “REMOVAL OF

TOP OVER” on page 2.6.

3. Remove the rear access panel (Figure 15 [5]).

4. Inspect the drive belt (Figure 14 [3]). If the belt is excessively frayed or has a heavily glazed

surface, replace it.However it is generally the best judgement to leave a drive belt in the machine

if it is performing well, even if it shows moderate wear. Inspect the gripping surface of the belt

for excessively glazed surfaces or contamination by grease or oil.

5. heck the belt for proper tension. The outer edge of the belt should be flush to 1/16 inch below

the outer diameter of the upper variable speed pulley when the mixer is in speed “1”. If not,

adjust the belt using the “Belt Adjustment” procedure on page 2.2.

6. Start the mixer and shift the speed control from speed “1” to speed “4” and shut the mixer off.

7. heck the position of the belt on the lower vari-speed pulley. The belt should be flush to 1/16

inch below the outer flange of the pulley. If not adjust the belt using the “Belt Adjustment”

procedures on page 2.2.

Page2.1

Check upper

vari-speed pulley

Check lower

vari-speed pulley

BELT REPLACEMENT

1. Run the mixer and shift to first speed “1” and shut the mixer off.

FOR SAFETY, DISCONNECT THE ELECTRICALPOWER SUPPLY CORD.

NOTE MIXERS WITH POWER BOWLLIFT:

Loosen the four 5/16-18 Kep nuts (Figure 12 [11]) and slide the bracket (Figure 12 [16]) all the

way toward the front of the mixer housing and remove the chain (Figure 12 [10]).

2. With the mixer OFF, shift the mixer to fourth speed “4”.

3. Unwrap the belt from the top pulley. Slide the belt between the top pulley and the speed control

cam (Figure 13 [15]).

4. Remove the belt from the lower vari-speed pulley. NOTE: the bowl slide must be in the lowered

position for the belt to clear the nose of the pulley.

WARNING The pulley flanges are spring loaded. Keep your fingers away from the pulley

while removing the belt.

5. Install the new belt in the reverse of the above procedure. Place the new belt around the lower

vari-speed pulley and pull the belt into the pulley to sperate the flanges of the pulley and allow

installation of the belt on the upper vari-speed pulley.

6. Adjust the belt as described below.

BELT ADJUSTMENT

1. Upper Vari-Speed pulley

a. With the mixer in speed 1, loosen the nuts holding the speed control bracket (Figure []), de-

tent housing [] and strap [].

b. If the belt was riding outside the pulley flanges, tap the bracket lightly towards the rear of the

mixer. If the belt was riding more than 1/16 inch below the pulley flanges, lightly tap the

bracket towards the front of the mixer. Shifting the speed control to speed 2 may help.

NOTE Move both the bracket [] and the detent housing [] the same amount. The assembly

must remain perpendicular to the mixer housing or binding of the speed control will result.

c. Retighten the nuts and run the mixer in speed 1 and check the belt position on the upper

pulley. Repeat the procedure if necessary until the belt is flush to 1/16 inch below the upper

pulley flange.

2. Lower Vari-Speed pulley

Once the upper vari-speed pulley is adjusted the lower pulley must be checked and adjusted as

necessary.

Page2.2

d. Start the mixer and shift the speed control to speed 4 and stop the mixer. heck the position

of the belt on the lower vari-speed pulley. The belt should be flush to 1/16 inch below the

outer edge of the pulley flanges.

e. If adjustment is needed, loosen the nuts (Figure []) and raise or lower the motor using the

nuts on the under side of the motor.

NOTE The base of the motor must remain parallel to the base of the mixer. If the base of the

motor is not parallel to the mixer base the belt life will be reduced and the mixer may shift

poorly.

f. Retighten the top nuts and run the mixer in speed 4 and check the belt position on the lower

vari-speed pulley. Repeat the procedure if necessary until the belt is flush to 1/16 inch below

the upper pulley flange.

Page 2.3

Motor Base

Nuts

Speed control

Bracket Mounting Nuts

Strap Detent Housing

Mounting Nuts

Table des matières

Autres manuels Univex Mixer

Manuels Mixer populaires d'autres marques

Bosch

Bosch GRW 9 Manuel utilisateur

MULTIQUIP

MULTIQUIP Whiteman WM45E Mode d’emploi

KitchenAid

KitchenAid KSM7581BZ0 Guide rapide

Jay-Lor

Jay-Lor 5050 Manuel utilisateur

Sunbeam

Sunbeam FPSBSM210X Manuel utilisateur

MULTIQUIP

MULTIQUIP Whiteman MC94S Mode d’emploi

Thinky

Thinky ARE-250 Manuel utilisateur

Midas

Midas XL4 Manuel utilisateur

bianco

bianco PURO 4 Manuel utilisateur

Paso

Paso DAG9200 Manuel utilisateur

Sima

Sima SFX-9A Manuel utilisateur

better chef

better chef IM-815WC Instructions d'installation

ALLEN & HEATH

ALLEN & HEATH GR1 Manuel utilisateur

Lacor

Lacor 69083 Fiche technique

M-Audio

M-Audio Midiman SAM Manuel utilisateur

Buffalo

Buffalo CP921 Manuel utilisateur

Pentair

Pentair HYPRO Cleanload 3376-0870 Instructions de fonctionnement

Cuisinart

Cuisinart SM50WHE Manuel utilisateur
