uDirect

guide

Thank you

Thank you for choosing the Unitron uDirect™.

At Unitron, we care deeply about people with

hearing loss. We work closely with hearing

healthcare professionals to make advanced,

purpose-driven solutions available to everyone.

Because hearing matters.

The intended use of uDirect  is to wirelessly

stream audio from dierent Bluetooth®devices

to your hearing aids. For example, mobile

phones, MP players etc.

You can also stream other audio devices

directly via a plug. For example, computers,

Roger and FM receivers.

uDirect  can also be used as a remote control

to adapt your hearing aids to dierent listening

situations.

Please note that your hearing healthcare

professional must congure your uDirect 

before it can be used as a remote control for your

hearing aids.

Your uDirect 

Hearing healthcare professional: _______________

___________________________________________

Telephone: _________________________________

Serial number of uDirect : ____________________

Warranty: __________________________________

Date of purchase:____________________________

The uControl™app can be downloaded at the

App Store and Google play. Search for Unitron and

select uControl.

Table of contentsQuick reference

Your uDirect  at a glance .......................................................... 

Setting up the power supply ...................................................... 

Charging the uDirect ................................................................ 

Turning the uDirect  on and o ................................................. 

Summary of indicator lights....................................................... 

Wearing the uDirect  correctly................................................ 

Operating distance................................................................... 

Button lock function................................................................. 

Testing sound via the uDirect ................................................ 

Access button functionality ..................................................... 

Spoken notications................................................................ 

uControl app............................................................................. 

Using uDirect  as a remote control for your hearing aid ......... 

Using uDirect  with a mobile phone .......................................

Advanced phone options ......................................................... 

Using the external microphone ................................................ 

Using uDirect with uTV  ......................................................... 

Using uDirect  with uMic.........................................................

Using uDirect  with an audio device with Bluetooth............... 

Using uDirect  with an audio device with a headphone jack.. 

Setting up the FM receiver........................................................

Managing multiple audio inputs to the uDirect ..................... 

Resetting your uDirect  ........................................................... 

Deleting the pairing of Bluetooth devices ............................... 

Troubleshooting guide ............................................................. 

Warnings .................................................................................. 

Information and explanation of symbols................................. 

Compliance information........................................................... 

O On

Charging uDirect 

Power indicator

Solid red - charging

Solid green - fully charged

Red blink - low battery

No light - battery drained

Audio indicator

Solid orange - streaming

Solid violet - demo sound

Solid blue - fully charged

Blue short blink - 1 device

connected

Blue double blink - 2 devices

connected

Blue very fast blink - pairing

Bluetooth pairing

Wearing uDirect 

On/O

2 seconds

Blue blink

Accessories

15, 16 Universal power supply with mini-USB plug

17-20 US, EU, UK, AUS adapter

Other optional accessories

External lapel microphone ‘MC1’

Short neckloop (51 cm)

Unitron uTV  (Bluetooth transmitter for TV use)

Audio cable, 1.5 m / 5 .

USB cable, 3 m / 10 .

(Included country adaptors may vary by country.)

Your uDirect  at a glance

Buttons

1 Access ( )

2 Volume ( )

3 Home ( )

4 Connect ( )

5 On/O switch ( )

Inputs

6 Microphone openings

7 Audio input (3.5mm jack)

8 FM input (Europlug)

9 Charging input (mini-USB)

Indicators

10 Audio indicator

11 Power indicator (power)

Neckloop

12 Neckloop sockets

13 Neckloop (with antenna)

14 Neckloop plugs

*Can be congured by your hearing healthcare professional.

7 8 9

16 17 18

2019

Charging the uDirect 

Your uDirect  has a non-removable

rechargeable battery.

To charge it:

. Plug the mini-USB plug into the mini-USB

port on the uDirect .

. Plug the power supply into a power outlet.

During charging, the power indicator is solid

red, this typically takes  minutes.

When the battery is fully charged, the power

indicator is solid green.

It is safe to leave the uDirect  connected to the

charger overnight.

When charging your uDirect  for the rst time,

let it charge for at least three hours, even if the

battery indicator is not lit or turns green earlier.

Setting up the power supply

. Select the adapter that corresponds to your

country.

US EU UK AUS

. Insert the round corner of

the adapter to the round

corner of the universal

power supply until it is

completely inserted.

. Click the tail of the adapter

in to lock it into place.

Make sure the adapter is securely locked.

To remove the power adapter:

. Pull back the tab on the

universal power supply and

hold.

. Gently pull the adapter

upwards to remove it from

receptacle.

. Then start over with step one (above).

1. 2.

A new battery’s full performance is achieved only

aer three complete charge and discharge cycles.

uT V™ can also be used as a charging station for

uDirect .

Turning the uDirect  on and o

Slide the power switch

() as shown to turn

the uDirect  on or o.

Switch the uDirect 

o when not in use or if in storage or during

transportation.

For operational use switch the uDirect  on.

Summary of indicator lights

The indicator lights provide helpful information

as follows:

Power indicator

Charging Solid red

Charged and full

battery

Solid green

Switching on Green 2 seconds

Switching o Blink red, then solid 2

seconds*

Battery above 10%,

normal operation

Slow blink green **

<10% battery,

charging required

(at least 2 hours)

Short blink red**

Battery dead,

charging required

(at least 2 hours)

No light aer switching on

Enable/disable

lock state

Short blink red (lock) or short

blink green (unlocked)

* When switching the uDirect  o, the

power indicator may blink red rst while

the uDirect is properly disconnecting all

Bluetooth devices.

O On

Audio indicator

The neckloop must be plugged in for any

streaming.

Plug or FM streaming Solid orange

Bluetooth phone or

music streaming

Solid blue

One Bluetooth device

connected

Short blink blue

Two Bluetooth devices

connected

Double-blink blue

Bluetooth pairing Very fast blue blinking

Demo sound playing Solid pink

The Bluetooth pairing indication will be visible

even if the neckloop is not plugged in.

During cable or FM streaming, the audio

indicator will remain orange regardless of the

Bluetooth connection state.

** If the neckloop is not connected to the

uDirect , the battery level is only shown

during startup, charging and when a button

is pressed.

Aer unplugging the neckloop the uDirect

enters power down mode aer two minutes

and the power indicator goes o. Only the

remote control functions can be used while the

neckloop is unplugged.

Battery state

The color of the power indicator informs you

about the uDirect  battery state.

The green power indicator indicates a battery

level >%.

The red power indicator indicates a battery

level <%. Less than one and a half hours

streaming remain and the battery should be

charged for at least twohours.

1110

Wearing the uDirect  correctly

Before any phone, music or TV streaming can

take place, the uDirect  must be switched on

and worn correctly as shown below:

. Put the neckloop

around your neck (easily

done by unplugging one

neckloop plug).

. Make sure both plugs

are well connected in

the neckloop sockets.

. Switch the uDirect  on.

For streaming, the neckloop must always be

plugged in. When unplugged, the uDirect  will

go into sleep mode aer two minutes. The power

and audio indicators will stop blinking and all

active Bluetooth connections are terminated

to save power. Plug the neckloop in again to

activate the streaming.

Operating distance

If uDirect  is used as a handheld

remote control (without neckloop):

• Maximum distance  cm/’’

• Hold uDirect  as shown

Button lock function

The access

( )

button on your uDirect  can

be locked to avoid inadvertent presses. To lock

the button, press and hold the connect

( )

and Home

( )

buttons simultaneously. The

power indicator light will flash red three times

to indicate that the buttons have been locked.

Press and hold the connect

( )

and Home

( )

buttons simultaneously again to unlock

the buttons.

You will still be able to answer an incoming

telephone call using the access

()

button

while it is locked.

1312

will also set the volume level of the spoken

uDirect  messages.

If you cannot hear the sound demo:

• Make sure your hearing aids are inserted

correctly.

• Make sure the uDirect  neckloop is

properly plugged in on both ends and worn

around your neck.

• Make sure the uDirect  is charged and

switched on.

• Make sure you are not on a phone call

connected through the uDirect .

The power indicator is lit as long as you press

a uDirect  button. Green conrms a good

uDirect battery state, red indicates that you

need to charge the uDirect  battery.

Two minutes aer unplugging the neckloop both

indicator lights will switch o and the uDirect 

disconnects Bluetooth to save power.

Testing sound via the uDirect 

. Wear the uDirect  correctly.

. Press and hold the access ( )

button while switching on the device.

Release the access button. The audio

indicator light with turn pink.

The hearing aids will switch to the streaming

mode and you will hear the uDirect  sound

demo.

Use the volume ( ) buttons to adjust the

volume.

The sound demo will stop aer three minutes

or when the access button is pressed.

Adjusting the volume during the sound demo

1514

Spoken notications

Spoken notications inform you about the

dierent operation modes and status of the

uDirect  using text-to-speech, for example low

battery.

Your hearing healthcare professional can

congure the language setting as well as which

notications are spoken.

Caller identication is independent of the

spoken notications level.

Spoken notications must be enabled by your

hearing healthcare professional.

Access button functionality

The access button has multiple

functions:

• Phone: Manages telephone

functions such as accepting

and ending phone calls. See the

section “Using uDirect  with a smartphone

or cell phone” for more information.

• Streaming: It pauses and resumes the

streaming from an audio device.

• Remote control: It can be used to select the

hearing aid programs.

Autres manuels pour uDirect 3

Table des matières

Autres manuels Unitron Prothèse auditive

Unitron

Unitron Moxi V-312 Manuel utilisateur

Unitron

Unitron Connect SmartFocus Manuel utilisateur

Unitron

Unitron Stride V-PR Manuel utilisateur

Unitron

Unitron Latitude Moxi 13 Manuel utilisateur

Unitron

Unitron 360 Manuel utilisateur

Unitron

Unitron Passport Fuse Manuel utilisateur

Unitron

Unitron Quantum micro BTE Manuel utilisateur

Unitron

Unitron iCube Manuel

Unitron

Unitron Moxi FIT Manuel utilisateur

Unitron

Unitron Quantum Manuel utilisateur

Unitron

Unitron Latitude Shift Manuel utilisateur

Unitron

Unitron Passport Moxi 3G Manuel utilisateur

Unitron

Unitron Moxi B-R Series Manuel utilisateur

Unitron

Unitron Max Manuel utilisateur

Unitron

Unitron Quantum BTE Manuel utilisateur

Unitron

Unitron Quantum Manuel utilisateur

Unitron

Unitron Unison Manuel utilisateur

Unitron

Unitron Moxi All Manuel utilisateur

Unitron

Unitron uDirect 2 Manuel utilisateur

Unitron

Unitron uDirect Manuel utilisateur

Unitron

Unitron Moxi 2 Manuel utilisateur

Unitron

Unitron Passport Moxi Manuel utilisateur

Unitron

Unitron Breeze Manuel utilisateur

Unitron

Unitron Next ITE series Manuel utilisateur

Manuels Prothèse auditive populaires d'autres marques

Sonic

Sonic Bliss miniBTE Manuel utilisateur

Lexie

Lexie B1 Manuel de la liste des pièces

Widex

Widex FM+DEX Manuel utilisateur

Siemens

Siemens Triano Manuel utilisateur

Camplicomms

Camplicomms HC-200 Manuel utilisateur

Widex

Widex SUPER 220 S2-VSD Manuel utilisateur

Phonak

Phonak Q90 Manuel utilisateur

Williams Sound

Williams Sound SoundPlus WIR 237 Mode d’emploi

Oticon Medical

Oticon Medical Ponto SoundConnector Manuel utilisateur

Siemens

Siemens Life micon Manuel utilisateur

Starkey

Starkey Destiny Manuel utilisateur

Audicus

Audicus The Icon Manuel utilisateur

Advanced Bionics

Advanced Bionics Slim HP Standard Manuel utilisateur

Widex

Widex DREAM440 THE DREAM SERIES Manuel utilisateur

Phonak

Phonak myPilot Manuel utilisateur

NIKEN

NIKEN NK-401 Manuel utilisateur

ON Semiconductor

ON Semiconductor Ezairo 7111 Pre Suite Manuel utilisateur

Sonetik

Sonetik GOHEAR Manuel utilisateur

Unitron uDirect 3 Manuel utilisateur

Manuels Prothèse auditive populaires d'autres marques
