Owner’s Manual
Wired Video Security DVR System
© 2017 Uniden America Corporation Issue 2, March 2017
Irving, Texas Printed in China
This Owner’s Manual applies to the following models:
BC6440D G7404D1
G6440D G7804D1
G6840D1 G7805D2
G6860D2 G7842D2
G6880D2 G7844D2
G71644D3
G71684D3
GC7440D
GC7840D1
GC7880D3
CONTENTS
INTRODUCTION..................................................................................... 7
FEATURES ............................................................................................................7
INCLUDED IN THE BOX........................................................................................7
SETTING UP YOUR SYSTEM................................................................ 8
CONNECT DVR TO POWER ................................................................................8
CONNECT MOUSE TO DVR.................................................................................8
CONNECT DVR TO MONITOR .............................................................................8
Monitor with HDMI Port ..................................................................................... 9
Monitor with VGA Port ....................................................................................... 9
TV with BNC Port (VIDEO IN) ........................................................................... 9
CONNECT ETHERNET CABLE ............................................................................9
CONNECT CAMERAS TO DVR AND POWER ...................................................10
INSTALL CAMERAS............................................................................................10
Installation Tips................................................................................................ 10
BASIC CONFIGURATION.................................................................... 12
POWER ON AND ACCESS WIZARD..................................................................12
LOGIN ..................................................................................................................12
SET PASSWORD ................................................................................................13
SET MOTION SENSITIVITY................................................................................13
BASIC OPERATIONS........................................................................... 15
SEARCH FOR FILES...........................................................................................15
PLAY BACK RECORDED FILES.........................................................................15
FIND AND VIEW SNAPSHOTS...........................................................................16
MASK MOTION SENSITIVE AREAS...................................................................16
BLOCK OFF AREAS NOT TO RECORD.............................................................16
SET UP EMAIL NOTIFICATION AND ALERT.....................................................16
CONFIGURE ALARMS........................................................................................16
CREATE A RECORDING SCHEDULE................................................................16
TRANSFER RECORDED FILES FROM THE HARD DRIVE TO A USB DEVICE16
ADD OR CHANGE A PASSWORD......................................................................16
MAIN MENU OVERVIEW ..................................................................... 17
MAIN MENU.........................................................................................................17
SETUP ICON .......................................................................................................17
Basic Icon ........................................................................................................ 18
Live Icon .......................................................................................................... 20
Record Icon ..................................................................................................... 22
Schedule Icon.................................................................................................. 24
Alarm Icon ....................................................................................................... 26
Network Icon.................................................................................................... 30
Users Icon ....................................................................................................... 34
PTZ Icon .......................................................................................................... 35
Advanced Icon................................................................................................. 39
SEARCH ICON ....................................................................................................39
Time Search Tab ............................................................................................. 40
Event Search Tab............................................................................................ 40
File Management Tab...................................................................................... 41
Image Tab ....................................................................................................... 41
BACKUP ICON.....................................................................................................42
INFORMATION ICON ..........................................................................................43
System Icon..................................................................................................... 43
Event Icon........................................................................................................ 43
Log Icon........................................................................................................... 44
Network Icon.................................................................................................... 44
Online Users Icon ............................................................................................ 44
Exit Icon........................................................................................................... 45
DISK MANAGEMENT ICON ................................................................................45
LOGOFF ICON.....................................................................................................46
SHUT DOWN ICON .............................................................................................46
REMOTE ACCESS ............................................................................... 47
SMARTPHONE....................................................................................................47
5
FIRMWARE UPDATES......................................................................... 48
TROUBLESHOOTING.......................................................................... 49
APPENDIX A: MENU STRUCTURE..................................................... 52
SPECIFICATIONS ................................................................................ 53
4 CHANNELS/4 CAMERAS.................................................................................53
8 CHANNELS/4, 6, OR 8 CAMERAS...................................................................55
FCC PART 15/IC COMPLIANCE.......................................................... 57
ONE-YEAR LIMITED WARRANTY ...................................................... 58
6
7
INTRODUCTION
Uniden's Guardian Video Security DVR provides high quality synchronous audio and video. This
state of the art surveillance system uses TCP/IP network technology so you can monitor and
operate your system remotely through Uniden's free ProHD app.
FEATURES
The DVR provides a high-performace security network using a standard H.264 video compressed
format. It can be used as a stand alone device or online as a part of a video surveillance network.
With its professional network video surveillance software, it supports:
• High denition 1080p recording.
• Real-time recording at 15 fps per channel.
• 24/7 security-grade hard drive.
• Continuous, scheduled, and motion recording.
• H.264 video compression.
• HDMI cable included for simple connection to HD TVs.
• PTZ cameras supported, remotely controlled through a mobile app.
• Accurate time stamps with NTP & daylight savings time.
• Digital zoom in live view and playback.
• 2 video outputs (HDMI & VGA) to connect multiple monitor types.
• Instant USB backup of live video from selected camera.
• Upgradeable rmware.
• Supports Internet Explorer, Safari, Chrome, and FireFox.
• Free Uniden ProHD iOS and Android compatible apps with live viewing, playback, video
recording, and snapshot capability.
• Instant email alerts with attached snapshots.
INCLUDED IN THE BOX
• Cameras (4, 6, or 8) • Receiver (1) • 12V 2A Power Adapter (2)
• 4-or 8-Way Splier Cable • 60’ Extenon Cable (4, 6, or 8) • USB Mouse
• Ethernet Cable • HDMI Cable • Camera Mounng Kit
If any items are missing or damaged, visit www.uniden.com for assistance.
8
SETTING UP YOUR SYSTEM
Images in these installation procedures show the back panel of the G6840D1. Other
models' back panels will be different, but similar.
Basic setup connects the DVR to all peripheral equipment (cameras, mouse, monitor, etc) and
power. Once connected, your system is ready for use through the DVR’s menu system.
You can set up your system in 2 stages - installing your system hardware and then setting up
basic conguration. Each stage has separate steps.
STAGE 1 - Install System Hardware
• Connect DVR to Power
• Connect Mouse to DVR
• Connect DVR to Monitor
• Connect Ethernet Cable
• Connect Cameras to DVR and Power
• Install Cameras
STAGE 2 - Basic System Conguration
• Complete Wizard and Log In
• Set Password
• Set Screen Resolution
• Set Motion Sensitivity
CONNECT DVR TO POWER
1. Connect the DVR to 12V power using the 12V 2A power adapter
(supplied).
2. Connect the power adapter to a surge protector plugged into 120V indoor power.
CONNECT MOUSE TO DVR
Connect the mouse to the DVR at the labeled USB port on the back of the
DVR.
CONNECT DVR TO MONITOR
There are three different ways to connect the DVR and monitor, depending on what type of
monitor port connection is available.
9
Monitor with HDMI Port
1. Connect DVR and monitor using HDMI Cable
(included). HDMI cable to
DVR
HDMI cable
to Monitor
(example)
2. Connect monitor to surge protector plugged into 120V indoor power.
3. The DVR beeps as it powers up. After the UNIDEN welcome screen displays, the Wizard
screen displays.
4. Select Exit for now; we will return to the Wizard later in the setup process.
Monitor with VGA Port
1. Connect DVR and monitor using VGA Cable (not
included). VGA cable to
DVR
VGA cable
to Monitor
(example)
2. Connect monitor to surge protector plugged into 120V indoor power.
3. The DVR beeps as it powers up. After the UNIDEN welcome screen displays, the Wizard
screen displays.
4. Select Exit for now; we will return to the Wizard later in the setup process.
TV with BNC Port (VIDEO IN)
1. Connect DVR and TV using BNC-RCA Cable (not
included). BNC-RCA cable
to DVR
BNC-RCA
cable to
Monitor
(example)
2. Connect TV to surge protector plugged into 120V indoor power.
3. The DVR beeps as it powers up. After the UNIDEN welcome screen displays, the Wizard
screen displays.
4. Select Exit for now; we will return to the Wizard later in the setup process.
CONNECT ETHERNET CABLE
Connect one end of the Ethernet cable to the RJ45 jack on the DVR and the other to your ethernet
connection device (router, cable box, etc).
10
CONNECT CAMERAS TO DVR AND POWER
Each camera connects to one end of the 60 foot extention cable. The other end of the cable
connects to the receiver and to power. The ends of the extention cable are marked for Camera or
DVR side
1. Connect camera cable's blue end (male) to the blue camera-side
BNC end (female) of the extension cable. Male Female
Female Male
2. Connect the camera cable’s RED power connector (female) to the
DVR extension cable’s RED power connector (male).
3. Connect the extention cable's other blue BNC end (female) to
DVR's Video In connector (male).
The Video In ports on the back of the DVR are numbered. Do not
connect cameras to ports that your system does not support. If you
have 1 - 4 cameras, use ports labeled 1 - 4, etc.
Male
Female
4. Connect the extention cable’s red (female) power connector to
one of the power splitter cable ends (male).
5. Repeat these steps to connect the other cameras to the DVR and to the splitter cable.
6. Connect the power splitter cable to the power adaptor.
Female
Male
7. Plug power adaptor into the surge protector. Live video from the cameras displays on the
screen.
Some DVR systems have more than 4 cameras. DVR systems with 6 or 8 cameras have an 8x
splitter.
INSTALL CAMERAS
Video surveillance laws vary from state to state. Check local regulations to be sure you are
operating in a legal manner.
Installation Tips
• When selecting an outside location for your cameras, keep in mind that most cameras
are designed to operate between 14°F to 122°F (-10°C to 50°C) with a relative humidity
of up to 95%. Avoid installing cameras in direct sunlight, and consider wind chill and other
environmental factors, too.
• Mount the camera in an area that is visible, but out of reach. Route the wiring so it does not
interfere with power or telephone/cable lines and it should not be where it could be easily cut.
Create a plan for camera wire routing and for camera angle.
• Adjust the camera angle so that it covers an area with high trafc as needed. In “high-
risk” locations, have more than one camera cover the same area. This provides camera
redundancy if a vandal attempts to damage a camera.
• If you position cameras indoors, avoid pointing the camera at a glass window to see outside.
This may result in a bright white ring in the night vision image because the light from the night
vision LEDs may reect off the window glass.
Take the following placement suggestions under consideration:
• Cabling Distance From DVR to Camera. The video signal sent from the camera to the DVR
Ce manuel convient aux modèles suivants
14
Table des matières
Autres manuels Uniden Système de sécurité
Uniden
Uniden UDR780HD Manuel utilisateur
Uniden
Uniden GDVR 42 Series Manuel utilisateur
Uniden
Uniden G17xx Series Manuel utilisateur
Uniden
Uniden GUARDIAN G766 Manuel utilisateur
Uniden
Uniden G1410 Manuel utilisateur
Uniden
Uniden GDVR 43 Series Manuel utilisateur
Uniden
Uniden GSHC1000 Series Manuel utilisateur
Uniden
Uniden Guardian G955 Manuel utilisateur
Uniden
Uniden UDW10055 Manuel de service
Uniden
Uniden G17xx Series Manuel utilisateur
Uniden
Uniden Guardian B6440D1 Manuel utilisateur
Uniden
Uniden G7404D1 Manuel utilisateur
Uniden
Uniden UDRC24 Manuel utilisateur
Uniden
Uniden UDW-10003 Manuel utilisateur
Uniden
Uniden UDW20055 Manuel utilisateur
Uniden
Uniden UDR744 Manuel utilisateur
Uniden
Uniden G14xx Series Manuel utilisateur
Uniden
Uniden UDVR45x4 Manuel utilisateur
Uniden
Uniden WDVR4-2 HDD Manuel utilisateur
Uniden
Uniden B6440D Manuel utilisateur
Manuels Système de sécurité populaires d'autres marques
EDM
EDM Solution 6+6 Wireless-AE Manuel utilisateur
Highway Safety Group
Highway Safety Group EA401 Manuel utilisateur
Siren
Siren LED GSM Manuel utilisateur
Detection Systems
Detection Systems 7090i Instructions de montage
Se-Kure Controls
Se-Kure Controls MicroMini SK-4841 Manuel utilisateur
Siemens
Siemens FDM273 Manuel utilisateur
