OWNER'S MANUAL
DECT1820
EXTRA HANDSET
OWNER'S
MANUAL
Welcome
Checking the Package Contents
Congratulations on your purchase of the Uniden DECT1820
optional handset and charger. This expansion handset is
compatible with models in the following series: DECT1825,
DECT1825+1, DECT1855 and DECT1855+1
(Model numbers may vary.)
Each model within this series will support up to six handsets. You
can place a fully featured cordless handset anywhere in your home
as long as AC power is available to connect the handset's charging
cradle.
The DECT1820 expansion handset will not operate unless it has
been registered to your main base. Refer to the owner's manual
supplied with your main base model for detailed instructions on
operating your new expansion handset.
Make sure you have received the following items in the package.
If any of these items are missing or damaged, contact
your retailer.
• Cordless Handset
• Charging Cradle
• AC Adapter
(INPUT:240V AC 50Hz)
(OUTPUT:6V DC 200 mA)
• 2 x AAA size Rechargeable Batteries (1.2V 650mAh)
• This Owner ’s Manual
• Other Printed Material
IMPORTANT
[1]
Installing Your Expansion Handset
Follow these three easy steps to get your new handset ready to
use:
Register your new handset to the main base.
1
2
3
Connect the charger.
Install the batteries and charge your new handset for 15-20
hours.
Connect the AC adapter to the
jack and to a standard 240V AC wall
outlet.
Set the charger on a desk or tabletop.
•
• Place the charger close to the AC outlet so that you can
unplug the AC adapter easily.
Step 1:Connect the Charger
1
2
DC IN
Use only the supplied AC
adapter. Do not use other
AC adapter.
[2]
Step 2:Install the Batteries and charge your new
handset for 15-20 hours
1
2
Remove the battery compartment cover. Press down on the
semi-circle indent and slide the cover off.
Charge the battery for 15-20 hours before using. To charge the
batteries, place the handset on the charger.
While charging, the symbol scrolls and when the battery is fully
charged, all the bars of the battery symbol will be filled when the
phone is off the cradle.
If the symbol does not appear, reposition the handset in the
charger, ensuring that the charging points contact.
•Use only the Uniden batteries supplied with your phone.
•Recharge your handset on a regular basis by returning
the handset to the charger after each phone call.
Step 3:Register the Handset
YOU NEED TO REGISTER THE DECT1820 TO THE MAIN BASE
BEFORE USE!
For Main Base Models DECT1825, DECT1825+1, DECT1855 and
DECT1855+1, When you register a new handset to your base, you
will be asked to enter the base PIN code.
The pre-set PIN code is 0000. If you wish you can change this
code, see owner's manual for detailed instruction.
Before registering, make sure that you have the base and handset
in front of you. Also, make sure all handsets and the base are in
standby mode.
[3]
On the DECT1820 handset you want to register:
On your original base:
On the DECT1820 handset:
1. Press to access the main menu.
2. Press up or down key until is displayed and
press .
Press up or down key to display and press
.Press up or down key to select your base number and press .
Press and hold for approx. 3 seconds until you hear
the registration tone. You are now in ‘registration mode’.
If the base already has the maximum number of handsets (6)
registered to it you will need to de-register one of the existing
handsets before you can register the new handset.
See section below for de-registering handsets.
Enter the base PIN code. Pre-set base PIN code is 0000. You will
hear a confirmation tone when registration is complete.
When in standby mode, the new handset number will be displayed.
The handset will automatically be allocated with the next available
handset number.
If registration is unsuccessful, the display will show
and you will need to follow the registration
procedure again.
"Add.Settings"
"Register"
Not
Registered
find handset
menu/ok
menu/ok
menu/ok
menu/ok
[4]
If you have more than one handset registered to your base you can
de-register a handset or the bases registered to use. Before de-
registering, make sure all handsets and the base are in standby
mode.
Press to access the main menu.
Press up or down key until is displayed and
press
Press up or down key to display and press .
Press up or down key to select or and press
Press up or down key to display the handset or base you want
to de-register and press .
Press up or down key to select and press .
If the handset has been registered to the base successfully, you
will hear a confirmation tone.
Press to exit and return to standby.
Your phone is GAP compatible, which means you can
register your DECT1820 handset to other DECT
(Digitally enhanced cordless telephone) GAP
compatible bases.
You can register a DECT1820 handset to up to 4 bases,
e.g. one at work and one at home, and switch between
them.
1
2
3
4
5
6
7
.
.
Add. Settings
Deregister
Handset Base
Yes
To Register your handset to another manufacturer's
base. Follow the procedure for registering shown in the
other manufacturer's user guide.
•
•
•
[5]
menu/ok
menu/ok
menu/ok
menu/ok
menu/ok
menu/ok
end
Using Your Expansion Handset
Now that your new handset is registered, it can perform all the
same functions as the handsets originally included with your phone.
With your new handset, you can
• Transfer calls between handsets
• Use two handsets as 2-way radios in DirectLink (Walkie-Talkie)
mode
• Hold conference calls
• Access the integrated answering device or voice mail using
Handset
See the owner's manual that came with your main base for
complete instructions on operating your new expanded phone.
[6]
Battery Information
Low battery alert
Cleaning the battery charging contacts
Caution:
If the symbol is displayed on the handset, "Charge Battery"
appears and you hear the low battery tone, you will need to
recharge your handset. We recommend that you place the handset
back on the charger between use to ensure that it is always fully
charged.
To maintain a good charge, clean the
charging contacts on the
handset once a month. Dampen a cloth
with plain water. Gently rub
the damp cloth over the charging contacts
until all visible dirt is
removed. Dry the contacts thoroughly
before returning the handset
to the cradle.
Do not use paint thinner,
benzene, alcohol, or other chemical
products. Doing so may discolor the
surface of the telephone and damage the
finish.
[7]
talk
talk
talk
talk
rdl
rdl rdl
rdl
menu/ok
end
Quick Guide
Function Button press
Make a call
Preparatory call
Adjust earpiece volume
End a call
Receive a call
Redial
Privacy
, enter number.
Enter number, .
During a call, or .
Phone rings, .
then or to display number,
During a call, and select ,
repeat the same step to select
" " to resume a call
Mute
Un Mute
[8]
then , select , ,enter
name, , enter number, .
Select , , then select , .
then or , .
then or to
Press or to then
Press or to select
or
.
Press or to select the melody, .
then or to select internal
handset number, or
Store phonebook
Dial phonebook number
Handset ringer melody
Make internal call
New Entry
Tone Save
Audio Settings
Ringer Type
External,
Internal, Paging, Alarm,
Appointment
number
.
talk
talk
rdl
rdl
rdl
rdl
rdl
rdl
menu/ok
menu/ok menu/ok
menu/ok
menu/ok menu/ok
menu/ok
menu/ok
menu/ok
menu/ok
menu/ok
int'com
menu/ok
[9]
