Uni-Fi Wi-Fi 6 Manuel utilisateur

Wi-Fi 6 Router

Items for installation: Optional:

unifi TV

Media Box

Modem (BTU)

Once you have received your router package containing your new Wi-Fi 6 Router,

you are advised to install the router within 7 days. During installation, please follow

the labelled instructions for Wi-Fi 6 Router. Installation after 7 days from receiving the

package will require assistance for setup. Please contact us at 1800-88-5059

(working hours 8.30am - 5.30pm, Monday-Friday) to complete it.

IMPORTANT NOTE:

POWER

LAN 1WPS LAN 2 LAN 3

POWER

LAN 1WPS LAN 2 LAN 3

LAN 3 LAN 2LAN 4TEL 2TEL 1

15-30

MIN

LAN 1 POWER

WAN

POWER

Wi-Fi 6 Router

WAN

Modem (BTU)

Wi-Fi 6 Router

PART 1: Connect the new Wi-Fi 6 Router to the

modem

Before we start, unbox your new Wi-Fi 6 Router.

Mark your old cable connection before disconnecting it from

the old router port to avoid any incorrect connections on the

new router port.

Please wait between 15 to 30 minutes for our system to run

the auto-configuration and establish the connection.

* Once you are connected, you will receive your new broadband

password via SMS for your future reference. This password has been

auto-configured in your new Wi-Fi 6 Router.

* You will also get a new default Wi-Fi network name (SSID) and

password which can be found at the bottom of the new Wi-Fi 6 router.

Connect the cable from the WAN port of your new

Wi-Fi 6 Router to the LAN 1 port of your existing

modem.

Connect the Wi-Fi 6 Router power adapter to your

power supply socket and switch it on.

LAN PORT HDMI PORT AV

unifi TV Media Box

LAN 3

Wi-Fi 6 Router

POWER

LAN 1WPS LAN 2

WAN

OPTIONAL: Connect unifi TV Media Box to the

Wi-Fi 6 Router

If you have a unifi TV Media Box (white box or unifi Plus Hybrid

Box), connect the Media Box cable from LAN port to the new

Wi-Fi 6 Router LAN 3 port. For unifi Plus Box (uPB), you can just

connect to the Wi-Fi network.
