APEX

SERIES

KEYBOARD STAND

Product Manual

for Ultimate Support

AX-48 PRO B

ITEM #17351

AX-48 PRO S

ITEM #17476

Rev. 1, 12.08.11 | Manual Item #AX-48-PRO-M

warranty registration

Visit www.ultimatesupport.com for a quick and convenient process for registering your new

Ultimate Support product. Warranty Registration and Proof of Purchase are required for warranty

fulﬁlment. Full Limited Lifetime Warranty and Ultimate Protection Plus Premium Service and

Support Plan details are available online under Music Gear & Instrument Stands / Customer Support.

AX-48 Pro B

AX-48 Pro S

SETUP FOR APEX-4 8 PRO (Continued)

HANDLE AT TACHMENT

1. Remove included

screws from handle

mount (in stand).

2. Position handle in

place by lining up holes

in handle and holes in

handle mount.

3. Secure handle in

place with screws.

Congratulations

on your purchase!

4. Position clamp on column face and install bracket and T-screw.

(Angular edge rides in column slot.)

3. Stand AX-48 Pro upright and pen top cap to remove Tribars.

5. Attach Tribars to clamps by Tribar hook. Gently push Tribar

down into slot.

6. Loosen thumbscrew and slide stabilizer to touch the ﬂoor.

Re-tighten the thumbscrew.

7. To accommodate larger, heavier keyboard and / or lower playing

styles, remove angle adapter and re-adjust stabilizer. This

changes column angle and shifts center of gravity.

8. After loading top instrument ﬁrst, secure cables in cable clips.

Rotate cable clips. NOTE: Rotate cable clips again for

re-positioning.

Updated Design – The AX-48

Pro delivers everything you

loved about the original APEX

stand, but now features a sleek

exterior design for the modern

keyboard player.

Longer Tri-bar Arms – In

addition to one set of 13-inch

Tri-bar arms, the AX-48 Pro

now includes a set of 18-inch

Tri-bar arms to support your

larger keyboards.

True Portability – Take the

AX-48 Pro anywhere. The

Tri-bar arms store in the

column top and the legs slide

into the bottom creating a

self-contained, compact unit

complete with a heavy-duty

carrying handle.

Stable & Durable – Just like

the original APEX, the AX-48

Pro features locking legs for

proven stability and a black or

silver anodized aluminum ﬁnish

that won’t rust and resists

scratches.

SETUP FOR APEX-4 8 PRO

1. Lay stand on the ﬂoor. Press

the buttons at the base of the

column and slide legs out.

2. Rotate legs until they snap

into place.
