UFO MicroLED 4000P Fiche technique
PRODUCT USER GUIDE
M croLED 4000P Slave L ght Source
PLEASE READ THIS USER GUIDE BEFORE INSTALLING, OPERATING
OR PERFORMING MAINTENANCE ON THE LIGHT SOURCE UNIT
E357731
Rev: C1
INTRODUCTION
MICROLED 4000P SLAVE USER GUIDE
2
Thank you for purchasing this UFO ight source/ uminaire.
To ensure that the ight source is set up optima y and gives a ong service ife, p ease read this
user guide before insta ing, operating or performing any maintenance on the unit.
P ease keep this User Guide for future reference. This User Guide is aid out in three sections
Installati n -detai s on how to connect your uminaire
Operati n - detai s how to programme and set up your uminaire
Maintenance - maintenance og, troub eshooting guide, technica specification
MODELS COVERED BY THIS USER GUIDE
UFO MIC4000SL
IMPORTANT
This product must be insta ed in accordance with the app icab e insta ation code, by a person
fami iar with the construction and operation of the product, and the hazards invo ved.
These ight sources are not mains dimmab e.
The LED array in this ight source is not rep aceab e. When it reaches end of ife the who e unit
must be rep aced.
Type Y Attachment: If the externa f exib e cab e or cord of this uminaire or associated
PSU/driver is damaged, it sha be exc usive y rep aced by the manufacturer or his service agent
or a simi ar qua ified person to avoid a hazard.
L cati n: Do not ocate this ight source c oser than 200mm from any f ammab e surface.
Clearance / Ventilati n: It is imperative that a gap of 200mm is e around the unit. This is to
a ow air to circu ate and prevent overheating. The ocation must have free venti ation and must
not have an ambient temperature higher than that specified for the uminaire.
M unting: This uminaire comes with an integra mounting p ate for securing the unit to a
vertica or horizonta surface. Refer to the instruction sheet supp ied with the p ate.
Warning: Never ook direct y at the uminaire through the fibre port of the ight source.
Warning: The uminaire shou d be positioned so that pro onged staring into the
uminaire at a distance c oser than 2.7 metres is not expected.
INSTALLATION
3
UFO LIGHTING
This uminaire is powered by a 12V Power Supp y Unit or 12V Constant Vo tage Driver. Remove
the PSU/driver from its box. Connect the jack p ug into the socket in the back, and the ight
source is now ready for connection.
POWER SUPPLY REQUIREMENTS
This uminaire supp ied with a separate mounting p ate. If using the mounting p ate refer to the
fitting instructions supp ied with it.
MOUNTING
There are 3 connections required - the fibre port, the mains supp y and the DMX inter ink cab e.
The fibre port shou d be connected first. Connect and secure the fibre optic connector into the
front of the unit and secure using the M5 ocking screw.
P ug the mains p ug into the e ectrica supp y socket. Switch on the power, the LED indicator
wi i uminate, and the ight source wi start up automatica y. If no ight is produced consu t
the troub eshooting section.
Fina y, if DMX operation is required, connect the DMX inter ink cab e from the master ight
source or the standa one DMX contro er to the s ave unit. The MicroLED 4000 SL unit has 2 RJ45
connectors on the rear of the unit - either can be used.
CONNECTION
Connect a DMX inter ink cab e between one of the RJ45 connectors on the master ight source
and one of the RJ45 connectors on the s ave unit.
The s ave wi now respond in exact y the same way as the master ight source when commands
are issued via the master’s remote contro unit.
Mu tip e s ave units can be daisychained to a sing e master using RJ45 terminated cab es.
SLAVE OPERATION WITH A MICROLED 4000 MASTER UNIT
INSTALLATION
OPERATION
MICROLED 4000P SLAVE USER GUIDE
4
To use the ight source in manua standa one mode remove the DMX connector from the RJ45
socket at the rear of the S ave and it wi now respond to manua commands from the 2 contro
buttons as detai ed be ow.
The ight source has 2 co our cyc es, each with 3 different speed settings, the co ours are
detai ed in the tab e be ow:
STANDALONE OPERATION USING INBUILT BUTTONS
Cycle Colour 1 Colour 2 Colour 3 Colour 4 Colour 5 Colour 6 Colour 7
1 White Red Oran e Jade Green Cyan Blue
2 Red Oran e Jade Green Cyan Blue White
The ight source is contro ed using the 2 push buttons on the rear of the unit.
The ower button stops and starts the co our cyc e.
The upper button is used to se ect the cyc e speed as fo ows:
Push the upper button repeated y unti the co our white is disp ayed. The ight source is now in
Cyc e 1 Speed A as detai ed in the tab e be ow. Each push reduces the speed. On the third push,
the co our red wi be disp ayed. The ight source is now in Cyc e 2 Speed A.
At any time the cyc e can be stopped on a co our and started again using the ower push
button.
Cycle Speed A - Fastest Speed B - Slower Speed C - Slowest
1 (White Start) Push once Push once Push once
2 (Red Start) Push once Push once Push once
OPERATION
5
UFO LIGHTING
To use the S ave in DMX operation connect a DMX Cat5 cab e between one of the RJ45 sockets
at the rear of the S ave Light Source and the Master Light Source or the DMX Contro er- see RJ45
connection detai s and drawing be ow. To connect mu tip e S ave Light Sources connect ink
Cat5 cab es between the spare RJ45 socket on the first S ave Light Source and a RJ45 socket on
the next S ave Light Source and so on.
RJ45 connection detai s are supp ied be ow:
DMX OPERATION
Pin No. 1 2 3 4 5 6 7 8
Colour White
Oran e Oran e White
Green Blue White
Blue Green White
Brown Brown
Funcon DMX+
(Hot)
DMX-
(Cold) Spare Spare Spare Spare GND GND
DMX XLR
Equivalent Pin 3 Pin 2 - - - - Pin 1 Pin 1
The ight source is assigned to address 001, which cannot be changed, Each ight source
occupies 4 DMX channe s as detai ed be ow:
Channel Funcon Value Descripon
1 Colour Red 0-255 From off at 0 to bri ht at 255
2 Colour Green 0-255 From off at 0 to bri ht at 255
3 Colour Blue 0-255 From off at 0 to bri ht at 255
4 Colour White 0-255 From off at 0 to bri ht at 255
OPERATION
MICROLED 4000P SLAVE USER GUIDE
6
MAINTENANCE LOG
Date Maintenance Undertaken
N te: A record of a maintenance MUST be kept in the tab e above, indicating what maintenance
was undertaken and when. This MUST be dated for warranty purposes.
MAINTENANCE
7
UFO LIGHTING
Problem Possible Cause(s) Remedy
Unit is dead - LED
power
indicator is not
illuminated
Mains supply off Check supply and reinstate
Loose mains plu s Check plu s
PSU failed Replace PSU
Unit is dead - no
li ht output but LED
power
indicator is sll
illuminated
LED array failure Replace LED unit
Switched off via remote control unit Recycle power to li ht source or switch on via re-
mote control
Poor li ht
output on fibre
Unit needs cleanin
Carefully clean LED Lens
with dry cloth
Clean fibre common end
Fibre port connector not
plu ed in correctly
Ensure plu ed in correctly
and secured with lockin
screw
Staonary on one
colour
Lower buon has been
pressed Press lower buon once
LED driver has failed Replace LED unit
Colour cycle cannot
be stopped LED driver has failed Replace LED unit
Slave li ht source
works on standalone
but does not
respond to DMX
DMX cable disconnected or faulty Check DMX link cable connecons -
repair or replace
Master li ht source not sendin DMX si nal Check master li ht source - refer to the relevant
user uide troubleshoon secon
DMX controller not sendin DMX si nal Check DMX controller
TROUBLESHOOTING
MICROLED 4000P SLAVE USER GUIDE
8
TECHNICAL SPECIFICATION
9
UFO LIGHTING
Port connector size 30mm diameter
Fibre type Glass / PMMA
Material/Finish ABS (black, silver or white)
Dimensions (L x W x H) 137mm (5.4”) x 114mm (4.5”) x 73mm (2.9”)
Wei ht 0.4k
Operan Environment Indoor use - IP20
Min Ambient Temp. -10°C
Max Ambient Temp. +45°C
LED Array Type RGBW
LED Array Power 2-5W
LED Array Model Cree XLamp MC-E
LED Array Life (L70, B10) > 50,000 hours @ 25°C
Wavelen th and
Luminous Flux
Red: 625nm / 45lm
Green: 530nm / 93lm
Blue: 460nm / 12lm
White: 3500K / 120lm
Control Funconality Duplicates MicroLED 4000 Master unit
DMX Funconality Input from MicroLED 4000 Master unit
DMX Channels 1
Supply Volta e 90-264Vac
Mains Runnin Current 0.06A @ 240Vac
Mains Volta e VA ran 14VA
External PSU Type Power Pax, 12V, 2A, 24W
NOTES
MICROLED 4000P SLAVE USER GUIDE
10
