YR290 B7018-D2
Service Engineer’s Manual
2
http://www.tyan.com
3
http://www.tyan.com
PREFACE
Copyright
This publication, including all photographs, illustrations, and software, is
protected under international copyright laws, with all rights reserved.
Neither this manual, nor any material contained herein, may be reproduced
without written consent of manufacturer.
Copyright 2012 MiTAC International Corporation. All rights reserved. TYAN®is
a registered trademark of MiTAC International Corporation.
Version 1.2a
Disclaimer
Information contained in this document is furnished by MiTAC International
Corporation and has been reviewed for accuracy and reliability prior to printing.
MiTAC assumes no liability whatsoever, and disclaims any express or implied
warranty, relating to sale and/or use of TYAN®products including liability or
warranties relating to fitness for a particular purpose or merchantability. MiTAC
retains the right to make changes to produce descriptions and/or specifications
at any time, without notice. In no event will MiTAC be held liable for any direct
or indirect, incidental or consequential damage, loss of use, loss of data or
other malady resulting from errors or inaccuracies of information contained in
this document.
Trademark Recognition
All registered and unregistered trademarks and company names contained in
this manual are property of their respective owners including, but not limited to
the following.
TYAN®is a trademark of MiTAC International Corporation.
Intel®is a trademark of Intel®Corporation.
AMI®, AMIBIOS® and combinations thereof are trademarks of AMI
Technologies.
Microsoft®, Windows®are trademarks of Microsoft Corporation.
IBM®, PC®, AT®and PS/2®are trademarks of IBM Corporation.
Winbond®is a trademark of Winbond Electronics Corporation.
4
http://www.tyan.com
Federal Communication Commission (FCC)
Notice for the USA
Compliance Information Statement (Declaration of
Conformity Procedure) DoC FCC Part 15: This
device complies with part 15 of the FCC Rules
Operation is subject to the following conditions:
1) This device may not cause harmful interference;
2) This device must accept any interference received including interference
that may cause undesired operation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try one or more of the
following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and the receiver.
– Plug the equipment into an outlet on a circuit different from that of the receiver.
Consult the dealer on an experienced radio/television technician for help.
Notice for Canada
This apparatus complies with the Class A limits for radio interference as
specified in the Canadian Department of Communications Radio Interference
Regulations. (Cet appareil est conforme aux norms de Classe A d’interference
radio tel que specifie par le Ministere Canadien des Communications dans les
reglements d’ineteference radio.)
Notice for Europe (CE Mark)
This product is in conformity with the Council
Directive 89/336/EEC, 92/31/EEC (EMC).
CAUTION: Lithium battery included with this board. Do not puncture, mutilate, or
dispose of battery in fire. There will be danger of explosion if battery is incorrectly
replaced. Replace only with the same or equivalent type recommended by
manufacturer. Dispose of used battery according to manufacturer instructions
and in accordance with your local regulations.
5
http://www.tyan.com
About this Manual
This manual provides you with instructions on installing your TYAN YR290
B7018-D2. This Manual is intended for experienced users and integrators
with hardware knowledge of personal computers.
This manual consists of the following parts:
Chapter1: Provides an introduction to the TYAN YR290
B7018-D2 barebones, standard parts list, describes
the external components, gives a table of key
components, and provides block diagram of the
system.
Chapter2: Covers procedures on installing the CPU, memory
modules and hard drives.
Chapter3: Covers removal and replacement procedures for
pre-installed components.
Appendix: List the cable connection and FRU part tables for
reference of system setup, and technical support in
case a problem arises with your system.
6
http://www.tyan.com
SAFETY INFORMATION
Before installing and using TYAN YR290 B7018-D2, take note of the following
precautions:
·Read all instructions carefully.
·Do not place the unit on an unstable surface, cart, or stand.
·Do not block the slots and opening on the unit, which are provided for
ventilation.
·Only use the power source indicated on the marking label. If you are not
sure, contact the power company.
·The unit uses a three-wire ground cable, which is equipped with a third
pin to ground the unit and prevent electric shock. Do not defeat the
purpose of this pin. If you outlet does not support this kind of plug,
contact your electrician to replace your obsolete outlet.
·Do not place anything on the power cord. Place the power cord where it
will not be in the way of foot traffic.
·Follow all warnings and cautions in this manual and on the unit case.
·Do not push objects in the ventilation slots as they may touch high
voltage components and result in shock and damage to the
components.
·When replacing parts, ensure that you use parts specified by the
manufacturer.
·When service or repairs have been done, perform routine safety checks
to verify that the system is operating correctly.
·Avoid using the system near water, in direct sunlight, or near a heating
device.
·Cover the unit when not in use.
7
http://www.tyan.com
Table of Contents
Chapter 1: Overview.........................................................................9
1.1 About the TYAN YR290 B7018-D2 .......................................... 9
1.2 Features.................................................................................. 10
1.3 Product Model......................................................................... 15
1.4 Standard Parts List ................................................................. 16
1.4.1 Box Contents Per Node................................................... 16
1.4.2 Accessories ..................................................................... 18
1.5 About the Product................................................................... 20
1.5.1 System Front View (Per Node)........................................ 20
1.5.2 System Rear View (Per Node) ........................................ 22
1.5.3 Internal View (Per Node) ................................................. 23
Chapter 2: Setting Up..................................................................... 25
2.0.1 Before you Begin ............................................................. 25
2.0.2 Work Area........................................................................ 25
2.0.3 Tools ................................................................................ 25
2.0.4 Precautions...................................................................... 26
2.1 Installing Motherboard Components....................................... 27
2.1.1 Installing the DVD-ROM Drive (Optional)........................ 27
2.1.2 Installing the CPU and Heatsink...................................... 31
2.1.3 Installing the Memory....................................................... 35
2.2 Rack Mounting........................................................................ 38
2.2.1 Installing the Server in a Rack......................................... 38
2.2.2 Installing the inner Rails to the Chassis........................... 39
2.2.3 Installing the Outer Rails to the Rack .............................. 40
2.2.4 Rack mounting the Server ............................................... 41
Chapter 3: Replacing Pre-Installed Components ........................ 47
3.1 Introduction ............................................................................. 47
3.2 Disassembly Flowchart........................................................... 47
3.3 Replacing Motherboard Components..................................... 49
3.3.1 Replacing Expansion Card .............................................. 49
3.3.2 Disconnecting All Motherboard Cables ........................... 52
3.3.3 Removing the Motherboard ............................................. 54
3.4 Replacing the Power Distribution Board ............................... 55
3.5 Replacing the Front Panel Board.......................................... 57
3.5.1 Front Panel Board Features ............................................ 60
3.5.2 Front Panel Board Connector Pin Definition ................... 60
3.6 Replacing the System Fan.................................................... 61
3.7 Replacing the M7018-BP2 HDD Backplane Board .............. 63
8
http://www.tyan.com
3.7.1 M7018-BP2 HDD Backplane Board Features ................. 65
3.7.2 M7018-BP2 Connector Pin Definitions............................ 66
3.8 Replacing the Power Supply................................................. 68
Appendix I: Cable Connection Tables ..........................................69
(TYAN Proprietary Design) ............................................................73
Appendix II: FRU Parts Table ........................................................ 73
Appendix III: Technical Support.................................................... 75
9
http://www.tyan.com
Chapter 1: Overview
1.1 About the TYAN YR290 B7018-D2
Congratulations on the purchase of the TYAN YR290 B7018-D2, a highly
optimized rack mount barebone system. The YR290 B7018-D2 is designed to
support up to (2) Intel® Xeon 5500/5600 Series processors and up to 96GB
RDIMM or 48GB UDIMM DDR3-800/1066/1333 memory per node. Utilizing
advanced technology from Intel®, the YR290 B7018-D2 system provides
scalable 32/64-bit computing, high bandwidth memory design, and lightning-fast
PCI-E bus capabilities. The YR290 B7018-D2 not only manages currentIT
environments, but also flexibility for future application usage.
TYAN®also offers the YR290 B7018-D2 in a version that can support up to
sixteen hot-swap hard drives (eight per node). The YR290 B7018-D2 uses latest
chassis designs which features a solid mechanical enclosure and robust
features. All of this provides the YR290 B7018-D2 with the power and flexibility
to meet the needs of today’s server applications.
10
http://www.tyan.com
1.2 Features
TYAN YR290 B7018-D2 (B7018Y290D2-045W8HR)
Form Factor 2U Rackmount Frame w/ 2x 2U Blades
Chassis Model YR290
Dimension (D x W x
H) 28.74" x 17.32" x 3.44" (730 x 440 x 87.5mm)
Blade Dimension
(D x W x H) 28.74" x 8.46" x 3.32" (730 x 214.8 x 84.5mm)
Motherboard S7018GM3NR
Board Dimension 6.3"x16.4" (160x416.6mm), per blade
Gross Weight 27 kg
System
Feature Two nodes in one chassis
Buttons (1) RST / (1) PWR / (1) ID
LEDs (1) PWR / (1) BMC / (2) LAN / (1) HDD
Front Panel (per
blade)
I/O Ports (2) USB ports
Type / Q'ty 2.5" Hot-Swap / (8)
External Drive
Bay (per blade) Supported HDD
Interface SATA-II 3.0Gb/s / SAS 3.0Gb/s
FAN (3) 6cm fans
System Cooling
Configuration
(per blade) Air Duct (1) Customized for the YR290 Chassis
Peripherals (per
blade) Type of ODD / Q'ty Ultra-slim DVD-ROM (optional)
Type ERP1U cold-swap
Input Range Full-range AC(100-240V)
Frequency 47 - 63 Hertz
Output Watts 450 Watts
Efficiency PFC / 80-plus Silver
Redundancy 1+1
Power Supply
(per blade)
Serviceability Hot-swap
Supported CPU
Series Intel Xeon Processor 5500/5600 Series
Socket Type / Q'ty LGA1366 / (2)
Thermal Design
Power (TDP)
wattage
Max up to 95W
System Bus Up to 4.8/ 5.86/ 6.4GT/s with Intel QuickPath
Interconnect (QPI) support
Processor (per
blade)
CPU list Please refer to our Web site for the latest update.
Chipset (per
blade) MCH / ICH Intel 5500 / ICH10R
Table des matières
Autres manuels TYAN Châssis
