TVS DAZZ Manuel utilisateur

Owners Manual

SKB 000001

support.ph@tvsmotor.com

Name :

Address :

Telp/ Hp No. :

Frame No. :

Engine No. :

Type :

Colour :

Purchase date :

Dealer’s Stamp / Signature Owner’s Signature

OWNER IDENTITY

CONTENTS

Preface ................................................................................

1. Specification .......................................................................

2. Know About Your Tvs Dazz .................................................

3. TVS Dazz Unique Feature ....................................................

4. Maintenance ......................................................................

5. Do It Yourself ......................................................................

CONTENTS

Dear TVS DAZZ Owner,

Congratulations!

Welcome to the family of millions of satisfied TVS Customers across the world by choosing

TVS DAZZ.

This manual explains about the features and benefits of your matic. Please thoroughly

familiarize this manual before you start.

Maintenance is extremely important to let your Dazz deliver the maximum performance to

you. Please get you Dazz maintained from any TVS Authorized Dealer / PGM / Service

Outlets.

We are delightful to welcome you into our ever expanding happy family.

Thank you for choosing TVS DAZZ.

Happy riding,

PT. TVS Motor Company Indonesia

PREFACE

OVERALL DIMENSION   

Overall length1855 mm

Overall width (Handle bar) 675 mm

Overall height 1075 mm

Seat height 750mm

Ground Clearance 150 mm

Gradeability 17

Wheel base 1240 mm

Dry Mass 92 Kg

Pay load 130 Kg  

ENGINE   

Type Single cylinder 4 stroke

air cooled engine

Bore x Stroke 53.5 x 48.8 mm

Piston displacement 109.65 cc

Compression ratio 9.5:1

Carburetor VM 17 UCAL  

SPECIFICATION

Air Filter  Paperfilter

Starting System Electric start / Kick start

Lubrication system Trochoid Oil Pump

Maximum power (in BHP) 8.1 BHP@7500 rpm

Maximum torque (in Nm) 8.5 Nm @5500 rpm

Engine idling 1600±100

Spark plug BOSCH - UR4KC

Spark plug gap 0.7 mm

TRANSMISSION   

Clutch  Centrifugal clutch - Auto

Transmission CVT (Continuously Variable Transmission)

Primary reduction 3.286

Secondary reduction 3.187

Final reduction 10.47

SPECIFICATION

Engine Oil 10W30 SL JASO MB

CHASSIS

Frame type Under Bone

Caster angle 26

Trail 87 mm

Steering angle 90

Brake front and rear

Front Disk 200 mm

Rear Drum 130 mm Dia

Tyre size

Front 80/90 - 14”

Rear 90/80 - 14”

Tyre pressure

Front 2.00 kg/cm (29 PSI)

Rear 2.25 kg/cm (32 PSI)

Suspension

Front Telescopic

Rear Toggle link, gas filled hydraulic dampers

SPECIFICATION

ELECTRICAL 

Ignition systemIDI - Ignition Dual Mode

Battery type 12V 3.5Ah

Generator AC 100W Magneto

Head lamp 12V 30 / 30 W (Halogen)

Tail / brake lamp 12V 5W/18W

Turn signal lamp front 12V 10W

Turn signal lamp rear 12V 10W

Position lamp 12V 1.7W

Speedometer lamp 12V 3.4W

Fuel gauge lamp 12V 3.4W

Fuel Indicator lamp 12V 1.7W

High beam indicator lamp 12V 1.7W

Horn 12V DC 2A

CAPACITIES

Fuel tank capacity 5.3 liter

SPECIFICATION

Engine oil capacity

Periodic 750 ml

Overhaul 800 ml

Recommendation oil 10W30 SL MB

Transmission oil capacity

Periodic 100 ml

Overhaul 120 ml

Recommendation oil 10W30 SL MB

Front fork oil capacity 55 ± 2 ml

SPECIFICATION
