Tropicair DUO Manuel
INSTALLATION
DUO
SHOW ROOM:
03 379 0438
sales@tropicair.co.nz
1/29 Acheron Drive, Riccarton
www.tropicair.co.nz
& OPERATING INSTRUCTIONS
03
10
16
CONTENTS
installation instructions
operating instructions
cleaning & maintenance
first lighting
tip sheet
problem solving
warranty
parts
17
18
19
21
24
TESTING CERTIFICATION
CM1: Canterbury Method 1
NES: National Emission Standard
MODEL AS/NZS
2918:2001
CM1.6
(ULEB)
AS/NZS
4012:2014
AS/NZS
4013:2014 AUTHORISATION
NUMBER
DUO complies 23mg/MJ 74% 0.35g/kg 164316
MODEL AS/NZS
2918:2001 NES EFFICIENCY
(%)
EMISSIONS
FACTOR
(G/KG)
AUTHORISATION
NUMBER
DUO complies 9mg/MJ 79% 0.1g/kg 163595
02
wetback complies 33mg/MJ 73% 0.48g/kg 165314
wetback complies 12mg/MJ 77% 0.2g/kg 184265
INSTALLATION
INSTRUCTIONS
THE HEATING APPLIANCE & FLUE SYSTEM SHALL BE INSTALLED IN ACCORDANCE WITH AS/NZS 2918
& THE APPROPRIATE REQUIREMENTS OF THE RELEVANT BUILDING CODES
APPLIANCES INSTALLED IN ACCORDANCE WITH THIS STANDARD SHALL COMPLY WITH THE
REQUIREMENTS OF AS/NZS 4013 WHERE REQUIRED BY THE REGULATORY AUTHORITY i.e., THE
APPLIANCE SHALL BE IDENTIFIABLE BY A COMPLIANCE PLATE WITH THE MARKING 'TESTED TO
AS/NZS 4013'
ANY MODIFICATION OF THE APPLIANCE THAT HAS NOT BEEN APPROVED IN WRITING BY THE
TESTING AUTHORITY IS CONSIDERED TO BE IN BREACH OF THE APPROVAL GRANTED FOR
COMPLIANCE WITH AS/NZS 4013.
DO NOT STORE OR USE INFLAMMABLE VAPORS OR LIQUID IN THE VICINITY OF THIS APPLIANCE.
DO NOT CONNECT TO AN UNVENTED HOT WATER SYSTEM.
INSTALL IN ACCORDANCE WITH AS 3500.4.1 or NZS 4603 & APPROPRIATE REQUIREMENTS OF THE
RELEVANT BUILDING CODES.
WARNINGS
CAUTIONS
MIXING OF APPLIANCE OR FLUE SYSTEM COMPONENTS FROM DIFFERENT SOURCES OR MODIFYING THE
DIMENSIONAL SPECIFICATIONS OF COMPONENTS MAY RESULT IN HAZARDOUS CONDITIONS.
WHERE SUCH ACTIONS IS CONSIDERED, THE MANUFACTURER SHOULD BE CONSULTED IN THE FIRST INSTANCE.
CAUTION: CRACKED or BROKEN COMPONENTS e.g. DOOR GLASS or CERAMIC TILES MAY RENDER THE
INSTALLATION UNSAFE or INEFFICIENT.
The installation must comply with local council regulations. We recommend installation by trained NZHHA
qualified installers, who work in accordance with good trade practice.
The appliance should be installed in such a manner that parts are accessible for inspection & maintenance.
A clearance of at least 1 meter must be between the front of the unit and any building structure or substantial
immovable structure.
For Low base (standard), heat sensitive floors must be protected with an approved 46mm Insulated hearth.
The appliance must be seismically restrained (including the hearth), 8mm Masonry anchors are recommended
for concrete floors or 14g High Tensile Wood Techs of appropriate length for wooden floors.
Any appliance shall not be connected to a flue common with an open fireplace.
Duo must be fitted with the following Wet or Dry Damper control advice label as appropriate for model.
1.
2.
3.
4.
5.
6.
7.
Wet Model: After 21 min. Following light up the downdraft slide should be closed
Dry Model: After 15 min. Following light up the down draft slide should be closed
KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
03
Total flue length must also be not less than 4.6m in height from floor protector
1000mm
minimum and
not lower than
point at which
flue intersects
at 3000mm
3000mm
more than 3000mm
3000mm or less
Note: Any flue systems may be fitted to the Duo provided a minimum 500mm X 500mm x 15mm ceiling plate a double
skinned 900mm long flue shield is fitted as per tested assembly.
Follow flue systems detail for specific component fitment instructions.
INSTALLATION
INSTRUCTIONS
INSTALLATION
600mm above roof ridge
Position the hearth & appliance on the floor. Drop a plumb-line from the ceiling to the center of the
Duo's flue spigot to mark the position where the flue will pass through ceiling.
Cut a 250mm x 250mm Square hole in the ceiling & roof above, & frame timber around 250mm ceiling
hole to support heat shield liners. Frame roof penetration if/as required. 40x40mm metal angles can be
used to support liners at purlin/roofline level (check manufacturers flue install instructions).
All flue joins are sealed at the time of installation using flue cement or a suitable exhaust cement and
fasten together with stainless steel pop-rivets or self-tapping screws (swagged end of the flue at
bottom). Secure the flue to the fire, drill through flue spigot on fire and secure with 2 to 3 s/s screws or
rivets. At this stage the ceiling plate should be fitted over flue & can be lifted up & screwed on.
500mm x 500mm x 15mm ceiling plate must be used.
A 900mm long double skinned shield must be fitted and can be fitted at his point.
Flash the roof to galvanised liner with an appropriate flashing method accepted by local council.
Where the chimney extends more than 1.3m (as per NZBC) above roof penetration, it will require
restraining stays. We recommend 16mm aluminium tubing for stays.
After installation of flue, ensure the unit is level & fixed through the hearth to the floor using seismic
restraints. Use 8mm masonry anchors or high tensile 14-gauge timber techs dependent on floor.
1.
2.
3.
4.
5.
6.
7.
8.
See flue installation diagram on the next page to further aid your installation but for actual flue details,
see the manufactures installation instructions.
04
INSTALLATION
INSTRUCTIONS
these are a guide only
- see instructions provided with flue
kit purchased
Liner swage points
Fit Cowl to complete
weatherproof assembly.
Fit support stays if liner
exceeds 1300mm out of roof
Flash liner to roof with
approved flashing method of
your council. We recommend
quality roof and gutter
sealant and 20mm steel
teach screws with neoprene
washers.
Cut a square hole and frame out
- see flue instructions for size
500mm x 500mm x 15mm
ceiling plate must be fitted
Flue swage points down
05
Fit a 900mm long Double
Skinned Flue shield
INSTALLATION
INSTRUCTIONS
Contact Tropicair if further clarity is required 03 379 0438 or www.tropicair.co.nz
clearances in mm to combustibles
CORNER ORIENTATION
clearances in mm to combustibles
STANDARD ORIENTATION
Standard model requires a
46mm thick insulting hearth
Tropicair advises that hearth
and clearance to combustibles
are absolute minimums.
Where practical these should
be exceeded
Side clearance is measured
from the cook top plate edge
Rear clearance is measured
from the rear of the heat
shielded casing
Corner clearance is measured
from rear corners of the heat
shielded casing
When offsetting backward
towards wall or corner, the
ceiling plate must be increased
by the same amount
(eg: Offsetting 100mm to the
rear. Standard ceiling plate of
500 x 500 x 15mm must now be
increased by 100mm at the
front. 350mm from centre to
the front edge of ceiling plate)
Minimum vertical clearance
from cooktop 1130mm
1146mm
996mm
996mm
523mm
620mm
385mm
385mm
45mm
365mm
300mm
823mm
835mm
300mm
620mm
110mm
65mm
365mm
690mm
250mm
300mm
06
Tropicair Duo Low Base (standard) clearances
INSTALLATION
INSTRUCTIONS
Contact Tropicair if further clarity is required 03 379 0438 or www.tropicair.co.nz
clearances in mm to combustibles
CORNER ORIENTATION
clearances in mm to combustibles
STANDARD ORIENTATION
Tropicair advises that hearth
and clearance to combustibles
are absolute minimums.
Where practical these should
be exceeded
Side clearance is measured
from the cook top plate edge.
Rear clearance is measured
from the rear of the heat
shielded casing.
Corner clearance is measured
from rear corners of the heat
shielded casing.
When offsetting backward
towards wall or corner, the
ceiling plate must be increased
by the same amount
(eg: Offsetting 100mm to the
front. 350mm from centre to
the front edge of ceiling plate)
minimum vertical clearance
from cooktop 1130mm
1216mm
1046mm
1045mm
523mm
620mm
385mm
385mm
45mm
365mm
300mm
823mm
905mm
380mm
620mm
110mm
65mm
365mm
690mm
250mm
300mm
07
Tropicair Duo Woodbase clearances
INSTALLATION
INSTRUCTIONS
Contact Tropicair if further clarity is required 03 379 0438 or www.tropicair.co.nz
clearances in mm to combustibles
CORNER ORIENTATION
clearances in mm to combustibles
STANDARD ORIENTATION
AS/NZS2918:2001 states:
All wetback appliances must
have 100mm working room for
maintenance.
As the Duo has clearances less
than 100 mm, the above MUST
be allowed for when installing.
1224mm
1051mm
1051mm
440mm
440mm
100mm
823mm
940mm
100mm
285mm
08
Tropicair Duo Wetback clearance changes
Contact Tropicair if further clarity is required 03 379 0438 or www.tropicair.co.nz
INSTALLATION
INSTRUCTIONS
Tropicair DUO wetback Pre-pipe information
front
Pipes centres 145mm right of centre
09
front
225mm standard base
(425mm if woodbase)
65mm
Always remember to factor hearth height in addition to these measurements
All measurements as written are from the top of the hearth
Under AS/NZS2918:2001 Minimum clearance
with a wetback is 100mm for access.
This WILL affect minimum hearth sizes
OPERATING
INSTRUCTIONS
WHAT WOOD TO USE
we recommend pine (soft wood)
- not only sustainable in NZ but one of the cheapest!
POWER OUT
not only does your Duo not need electricity to heat
your home - you can cook on the top too
ensure you use the right equipment to avoid damage
GREAT COMPANY
the atmosphere a fire puts out is both warm and cosy,
even romantic
10
