ELECTRONIC LOCK
Operation Manual
Models:
UM, CM, SM
FOR OFFICE FURNITURE, STORAGE CABINETS, LOCKERS, SAFES, VAULTS, SECURED ENCLOSURES
Micro-IQ Electronic Lock Programming Guide
Table of Contents
Definition of Terms ..............................................................1
Operating the Lock...............................................................1
Lock Components and Features ........................................................2
Programming Instructions...................................................2
Programming a New Master Code
..................................................
3
Adding a Control Key-Fob ...............................................................
Available User IDs .............................................................................
5
Operating the Lock With an Access Code .......................................
6
Unlocking the Unit ...........................................................................
6
Deleting Access Codes ......................................................................
6
Changing Access Codes ....................................................................
7
Battery Replacement ..........................................................
7
Care and Cleaning
8
General Information ..........................................................
Troubleshooting .................................................................
10
..............................................................
10
11
Table of Contents
Programming Access Codes .............................................................
4
Pre-programmed Codes ....................................................................2
Definition of Terms
1
MicroIQ Electronic Lock Programming Guide
Definition of Terms
Term Meaning
Factory Code
1-2-3-4-5
This is the preset Master Code set at
the factory.
Master Code This is the new code you will use
to permanently replace the Factory
Code.
User ID # This is the location or two digit
memory number used to store
each user’s individual Access Code.
(twenty five are available)
Access Code(s) This is the five digit code used by
each individual user to unlock the
unit.
Control Key-Fob Optional: Used to access and
program the lock.
Operating the Lock With an Access Code
1. Enter the 5-digit Access Code. The Factory Access Code is 1-1-1-1-1.
2. Rotate knob clockwise to unlock.
3. Rotate the knob counter-clockwise to lock.
(no code required to lock)
Wait for green light and an an audible beep.
Programming Instructions
2
MicroIQ Electronic Lock Programming Guide
Lock Components and Features:
Programming Instructions
Pre-programmed Codes
Your keypad lock has come preprogrammed with two (2) codes:
Access Code 1-1-1-1-1 to allow access to the unit before you program
your own codes, and Factory Code 1-2-3-4-5 to allow you to program
your own unique Master Code. This Master Code does not give you
access to the unit; it is for programming only.
It is important to write down the new 5-digit Master Code in a
safe place and do not share it with anyone. Please make note of
your new Master Code here before you begin the programming
procedure.
Note: Refer to page 1 where you recorded your Master Code.
Do not give your Master Code to anyone. If the Master Code is
compromised, then the unit’s security is compromised.
Green
Proceed
LED
Red
Error
LED
Yellow
Low battery
LED
Knob
in locked
position
Location to
point the
key-fob
Battery
holder
with cover
Keypad
Program
button
Push thin
front edge
inward
Press
Here
R
3
MicroIQ Electronic Lock Programming Guide
Programming a New Master Code
Warning: Do not set your Master Code to 1-2-3-4-5. Doing so will
erase all existing Access Codes and reset User ID 1-1 to
Access Code 1-1-1-1-1.
If a valid Master Code is entered, the green, red, and yellow
LEDs will ash.
If an invalid Master Code is entered, the red LED will flash 3
times, and the keypad will exit programming.
Once the new Master Code is programmed, the 1-2-3-4-5 Factory
Code becomes invalid.
Note: All Access Codes remain the same when a new Master Code is
programmed.
1. With the lock in either unlocked or locked position, press and
The keypad will enter programming mode, and the green LED
will light up.
2. Enter your 5-digit Master Code
If the code is entered correctly, the green LED will light up.
Proceed to step 3.
If no code is entered within 10 seconds, or if the code is entered
incorrectly, then the red LED will flash 3 times, and the keypad
will exit programming mode.
3. Press and hold the Program Button for 5 seconds.
The keypad will enter programming mode. The red LED will
flash once, and then the green and yellow LEDs will light up.
4. Enter the desired 5-digit Master Code.
MY MASTER CODE: __ - __ - __ - __ - __
Programming Instructions
hold the Program Button
(located below the #3 button) for 5
seconds.
4
MicroIQ Electronic Lock Programming Guide
Programming Instructions
Adding a Control Key-Fob
Note:
The Factory Code should be
changed to a new Master
Code before proceeding
with the programming
a Control Key-Fob.
Now you can use the Control Key-Fob to operate the lock.
1. With the lock in either unlocked or locked position, press and
hold the Program Button
(located below the #3 button) for 5
seconds.
The keypad will enter programming mode, and the green LED
will light up.
2. Enter your 5-digit Master Code
If the code is entered correctly, the green LED will light up.
Proceed to step 3.
If no code is entered within 10 seconds, or if the code is entered
incorrectly, then the red LED will flash 3 times.
To try again, return to step 1.
3. Press and hold the Program Button for 5 seconds.
The red LED will flash once, and then the green and yellow LEDs
will light up.flash once, and then the green and yellow LEDs will
light up.
4.
Point your Control Key-Fob under the Program Button and press
the center button of the fob.
A Control Key-Fob can be used insted of the
keypad to open or program the lock.
A Control Key-Fob can be paired to as many
MicroIQ locks as desired.
If no code is entered within 10 seconds, or if the Master Code is
entered incorrectly, then the red LED will flash 3 times, and the
keypad will exit programming mode.
4.
Enter the 2-digit User ID that you want to program.
If the User ID is entered correctly, the yellow LED will blink 5
times, and then both the yellow and green LED will light up.
Proceed to step 4.
If a User ID is not entered within 10 seconds, the red LED will
blink 3 times, and the keypad will exit programming.
Enter the new 5-digit Access Code.
If a valid code is entered, the green, red, and yellow LEDs will
strobe.
If an invalid code is entered, the red LED will flash 3 times, and
the keypad will exit programming mode.
Repeat Steps to program or change up to twenty-five Access Codes.
P
5
MicroIQ Electronic Lock Programming Guide
Programming Your Access Codes
You may program up to 25 unique Access Codes. Each of these
codes is used to unlock the unit.
To program a 5-digit Access Code:
1.
2.
With the lock in either the locked or unlocked position, press and
hold the Program Button (located below the #3 button) for 5
seconds.
The keypad will enter programming mode, and the green LED
will light up.
3.
Enter the 5-digit Master Code.
If the Master Code is entered correctly, the green LED will light
up. Proceed to step 3.
Programming Instructions
Available User IDs
Use this chart to record Access Codes for each User ID. User ID #11
is factory-set to Access Code 1-1-1-1-1, and should be reprogrammed
first.
11 (1-1-1-1-1) 12 13 14 15
21 22 23 24 25
31 32 33 34 35
41 42 43 44 45
51 52 53 54 55
A total of twenty-five (25) codes can be programmed.
Programming Instructions
6
MicroIQ Electronic Lock Programming Guide
Unlocking the Unit
Warning: Three invalid attempts will cause the lock to block any
other attempts for 3 minutes.
To open the unit:
1. Enter the 5-digit Access Code.
If a valid 5-digit Access Code is entered, the green LED will light
up and the lock will unlock. Proceed to step 2.
If an invalid Access Code is entered, the red LED will flash 3
times.
2. Rotate the knob clockwise to the unlocked position.
The lock will re-engage within 5 seconds if left in the locked
position.
3. To relock, rotate the knob counter-clockwise to the locked
position.
Programming Instructions
7
MicroIQ Electronic Lock Programming Guide
Deleting Access Codes
Warning: This will erase all Access Codes & reset the lock back to the
1-1-1-1-1 Access Code under User ID 1-1 when complete.
It will not change the Master Code.
To delete all Access Codes:
1.
2.
With the lock in either the locked or unlocked position, press
and hold the Program Button (located below the #3 button) for
5 seconds.
3.
Enter the valid 5-digit Master Code.
4.
Press and hold the Program Button for 5 seconds again
Enter 1-2-3-4-5.
Changing Access Codes
Each Access Code is saved under a User ID location. This procedure
will replace an existing Access Code based on the code’s User ID
location, making the original Access Code located under that User ID
permanently obsolete.
To change an Access Code:
1.
2.
With the lock in either the locked or unlocked position, press and
hold the Program Button (located below the #3 button) for 5
seconds.
3.
Enter the valid 5-digit Master Code.
4.
Enter the 2-digit User ID location* you wish to replace/change
(found in the table on page 6).
Enter the new 5-digit Access Code.
Repeat steps 1 - 4 to change additional Access Codes.
*Reference the User ID found in the table on page 6.
P
8
MicroIQ Electronic Lock Programming Guide
Battery Replacement
The keypad requires a 3v lithium CR2032 battery. When the battery
is low, the yellow LED light will flash 5 times after the lock is operated
operated to signify the low battery level. It should be replaced as
soon as possible, to avoid being locked out if the battery is depleated.
Note: Changing the battery will not delete any codes.
Caution: Be careful when removing small screw from battery
holder. If the screw is missing, a M2 x 4mm socket head
cap screw will fit for replacement. The hex tool is 1.5mm.
To replace the battery:
1. Lift the battery cover.
2. Swing the battery cover to parallel position as
lock body.
3. Remove the battery holder screw from lock body
using the hex tool.
4. Remove the battery holder by pulling it away
from the lock body.
5. Remove the battery from the holder using the
hex tool, if necessary.
Battery Replacement
