Tripp Lite SmartOnline SU16KRT Manuel utilisateur

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model #: SU16KRT

SmartOnline 16kVA On-Line Double-Conversion UPS, N+1, 12U Rack/Tower, 200-240V NEMA & C19 outlets

Highlights

16kVA / 16,000VA / 14,400W on-line double-conversion UPS; 0.9 power factor

200/208/220/230/240V 50/60Hz output, Economy mode option

Hot-swap power and battery modules, N+1 fault tolerance at loads up to 8kVA

USB, RS232 & EPO ports; support for SNMP/WEB and contact-closure card

options

Front panel LEDs with detailed LCD monitoring and control screen

Expandable runtime with optional external battery packs

Hardwire input (3 wire); L6-30R & C19 outlets

Description

Tripp Lite SU16KRT 16,000VA / 16kVA / 14,400 watt online, double-conversion UPS system offers complete power protection for critical server,

network and telecommunications equipment in a 12U rack/tower configuration. This system delivers complete N+1 redundancy when used at loads

up to 8kVA, and non-redundant operation at loads between 8 and 16kVA. Fault-tolerant auto-bypass prevents unexpected service interruptions

during UPS overload or internal fault conditions. Included parallel PDU with manual bypass switching enables hot-swappable replacement of all major

UPS system components in both N+1 and combined operating modes. Enhanced availability, fault tolerance and simple hot-swap replacement

options make this UPS ideal for advanced networking applications in data centers, computer rooms, network closets and rugged industrial locations.

Package Includes

Two SU8000RT3UPM UPS power modules

Two BP240V10RT3U battery packs

SUPDMB20K parallel PDU with Bypass switch

4 post rackmount installation rails

PowerAlert software and cabling

Features

Tripp Lite SU16KRT 16kVA, 16,000VA / 14,400 watt on-line, double-conversion UPS system in 12U total rack/tower configuration

Unique configuration offers 16kVA non-redundant operation and automatic N+1 redundancy at load levels of 8kVA and under

Included Parallel PDU with manual bypass switch enables hot-swap replacement of power modules at any supported load level

Hardwire input; 2 L6-30R and 8 C19 outlets

Maintains full-time sine wave output within 2% of selectable 200/208/220/230/240V nominal

Supports 50/60Hz operation for worldwide frequency compatibility

Expandable runtime with optional external battery packs

Some external battery configurations require the use of Tripp Lite's External Battery Configuration Software (see manual)

Battery independent restart

Highly efficient economy mode option

Optional SNMPWEBCARD, RELAYIOCARD and RELAYIOMINI interface modules available (RELAYIOMINI requires removal of USB

interface module)

HID-compliant USB interface

Includes Free PowerAlert monitoring software; PowerAlert LOCAL, PowerAlert NSA and PowerAlert NMS for monitoring up to 250

SNMP-enabled UPS, PDU and other networking devices

Optional 2POSTRMKITHD supports installation in 2 post 19 inch racks (4 required)

Optional 2-9USTAND supports upright tower placement (2 required)

Supports Emergency Power Off (EPO) via built-in interface

Front panel LEDs and LCD readout with scroll controls

LED / LCD display panel rotates for viewing in rackmount or tower configurations

External battery packs are field replaceable and hot swappable

Frequency conversion mode enables conversion of 60Hz to 50Hz or 50Hz to 60Hz (no de-rating)

Specifications

OUTPUT

Output Volt Amp

Capacity (VA)

16000

Output kVA capacity

(kVA)

Output Watt

Capacity (watts)

14400

Output kW capacity 14.4

Output power factor 0.9

Output Capacity

Details

Supports up to 105% load continuously in double conversion mode, 106 to 125% for 1 minute, 126% to 150% for 30

seconds; Loads over 150% trigger immediate bypass mode operation to support loads directly from mains power;

Double conversion mode is automatically restored as load levels are reduced to 95% or less

Nominal Output

Voltage(s) Supported

200V; 208V; 240V

Nominal Voltage

details

Voltage selection via front panel LCD interface

Frequency

compatibility

50 / 60 Hz; Supports 50 to 60 Hz and 60 to 50 Hz conversion

Frequency

compatibility details

Output frequency matches input nominal on startup; Frequency conversion mode enables conversion of 60Hz to

50Hz or 50Hz to 60Hz (no de-rating)

Output voltage

regulation (line

mode)

+/- 2%

Output voltage

regulation (Economy

line mode)

+/- 10%

Output voltage

regulation (Battery

mode)

+/- 2%

Built-in UPS output

receptacles

2 L6-30R outlet(s); 8 C19 outlet(s)

Output circuit

breaker

Two built-in 30A breakers protect one L6-30R outlet each; Eight built-in 20A breakers protect one C19 outlet each

Output AC waveform

(AC mode)

Sine wave

Output AC waveform

(battery mode)

Pure Sine wave

INPUT

Rated input current

(at maximum load)

92A (200V), 88.4A (208V), 83.6A (220V), 80A (230V), 76.6A (240V)

Nominal Input

Voltage(s) Supported

200V AC; 208V AC; 240V AC

UPS input

connection type

Hardwire

UPS input

connection

description

3 wire single phase input (L1, L2, G)

Recommended

Electrical Service

100A @ 200V-240V (L, N, PE), or 100A @ 200V, 208V, or 240V (L1, L2, G)

Phase Single-Phase

BATTERY

Full load runtime

(minutes)

5.5 minutes (14,400 watts)

Half load runtime

(minutes)

13.5 minutes (7200 watts)

Expandable battery

runtime

Runtime is expandable with external battery packs

External battery

pack compatibility

BP240V10RT3U; BP240V557C-1PH; BP240V787C-1PH; BP240V1037C-1PH; BP240V1407C-1PH

Expandable runtime

description

For best results, add external batteries in multiples of two so that both included 8kVA power modules have an equal

number and type of connected battery packs

DC system voltage

(VDC)

240

Battery recharge

rate (included

batteries)

Less than 8 hours from 10% to 90%

Battery replacement

description

Hot-swappable, user replaceable external battery packs

VOLTAGE REGULATION

Voltage regulation

description

2% output voltage regulation in standard online, double-conversion mode

Overvoltage

correction

Corrects overvoltages up to 300V

Undervoltage

correction

Corrects undervoltages as low as 100V

LEDS ALARMS & SWITCHES

LED Indicators 6 LEDs indicate line power, online mode, economy/bypass mode, on-battery, charger and AC output status; LCD

screen offers additional information and control options

Front panel LCD

display

Selectable LCD display with scroll and selection buttons enables UPS control and detailed monitoring options;

LED/LCD panel rotates for viewing in rack/tower formats; LCD Display supports ENGLISH, FRENCH, GERMAN,

ITALIAN, SPANISH and PORTUGUESE (see manual)

Alarms Unique audible alarms for all major UPS, environmental and power conditions (see manual)

Alarm cancel

operation

Alarm cancel switch

Switches 2 Switches control off/on power status and alarm-cancel/self-test operation; 2 additional switches support set and

execute scrolling LCD functions; bundled PDU includes bypass switch to enable hot-swap UPS power module

replacement

SURGE / NOISE SUPPRESSION

UPS AC

suppression

response time

Instantaneous

EMI / RFI AC noise

suppression

Yes

PHYSICAL

Installation form

factors supported

with included

accessories

4 post 19 inch rackmount

Included mounting

accessory

description

4 sets of adjustable 4 post rack rails included

Installation form

factors supported

with optional

accessories

2 post rackmount (2POSTRMKITHD); Tower (2-9USTAND)

Optional mounting

accessory notes

Qty 4 2POSTRMKITHD required; Qty 2 2-9USTAND required

Primary form factor Rackmount

UPS / Power Module

dimensions in

primary form factor

(height x width x

depth / inches)

5.14 x 17.5 x 25.82

UPS / Power Module

dimensions in

primary form factor

(height x width x

depth / cm)

13.1 x 44.5 x 65.6

Installed whole

system maximum

rack depth (inches)

32.5

Installed whole

system maximum

rack depth (cm)

82.6

Rack Height 12U

Secondary form

factor

Tower

UPS / Power Module

weight (lbs)

UPS / Power Module

weight (kg)

19.5

UPS dimensions

details

Includes 2 SU8000RT3UPM UPS/Power modules and 2 BP240V10RT3U Battery packs; Listed weights and

dimensions for UPS/Power module and Included battery pack each refer to a single unit

Included battery

pack dimensions

(height x width x

depth / inches)

5.25 x 17.5 x 25

Included battery

pack dimensions

(height x width x

depth / cm)

13.3 x 44.5 x 63.5

Included battery

pack weight (lbs)

158.7

Included battery

pack weight (kg)

UPS Shipping

dimensions (height

x width x depth /

inches)

36 x 40.25 x 51

UPS Shipping

dimensions (height

x width x depth / cm)

91.4 x 102.2 x 129.5

Shipping weight (lbs) 600

Shipping weight (kg) 272.4

Cooling method Fans

UPS housing

material

Steel

ENVIRONMENTAL

Operating

Temperature Range

+32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius

Storage

Temperature Range

+5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius

Relative Humidity 0 to 95%, non-condensing

AC mode BTU / hr.

(full load)

5464

AC economy mode

BTU / hr. (full load)

2040

AC economy mode

efficiency rating

(100% load)

96%

Operating Elevation

(ft.)

0-3000m (0 to 10,000 ft.)

Audible Noise 60 dBA at front side 1 meter

Operating Elevation

(m)

0-3000 m

COMMUNICATIONS

Communications

interface

USB (HID enabled); DB9 Serial; EPO (emergency power off); Slot for SNMP/Web interface

Network monitoring

port description

Additional contact closure support with optional RELAYIOCARD and RELAYIOMINI interface cards. RELAYIOMINI

installation requires removal of panel containing USB ports

PowerAlert software Included

Communications

cable

USB, DB9 serial and EPO cables included

WatchDog

compatibility

Supports Watchdog application, OS and hard-reboot restart options for remote applications

LINE / BATTERY TRANSFER

Transfer time No transfer time (0 ms.) in online, double-conversion mode

Transfer time

(economy mode)

8 milliseconds typical power failure response in optional economy mode

Low voltage transfer

to battery power

(setpoint)

100V

High voltage transfer

to battery power

(setpoint)

300V

SPECIAL FEATURES

Cold Start (startup in

battery mode during

a power failure)

Cold-start operation supported

Economy mode

operation

Optional economy mode enables high efficiency bypass operation with a maximum output voltage variation of

+/-10%. Double conversion mode is automatically restored as mains voltage varies beyond +/-10% with less than 1

millisecond transfer time between modes.

High availability UPS

features

Automatic inverter bypass; Manual bypass switch; Detachable hot-swap PDU; Hot swappable UPS power module;

Hot swappable batteries

Green & high

efficiency features

High efficiency economy mode operation; Support for daily startup and shutoff; Schedulable daily hours of economy

mode operation

CERTIFICATIONS

UPS Certifications Tested to UL1778 (USA); Tested to CSA (Canada); Meets FCC Part 15 Category A (EMI); ROHS (Restriction of

Hazardous Substances)

UPS Certification

details

IEC 61000-4-5 1995 B Surge Immunity

WARRANTY

Product Warranty

Period (Worldwide)

2-year limited warranty

Connected

Equipment

Insurance (U.S.,

Canada & Puerto

Rico)

$250,000 Ultimate Lifetime Insurance

Related Items

Optional Products

Related Model Description Qty.

SNMPWEBCARD For remote monitoring and control via SNMP, Web, or Telnet. 1

ENVIROSENSE Monitors temperature, humidity and contact-closure inputs. (Requires UPS with

SNMPWEBCARD, monitored PDU or switched PDU.)

SRSWITCH Magnetic Door Switch Kit for front and rear doors; requires ENVIROSENSE 1

BP240V10RT3U External Battery Pack and Cable. 3U, Expandable, Black 3-Point Connector 1

WEXT3-SU16-20K 3-Year Warranty (1-Year Extension) - For SU16K through SU20K Single-Phase UPS

Models

WEXT5-SU16-20K 5-Year Warranty (3-Year Extension) - For SU16K through SU20K Single-Phase UPS

Models

2-9USTAND Enables Tower Placement of Rackmount UPS Systems 1

2POSTRMKITHD Enables 2-Post Rackmount Installation of 3U and Larger UPS, Transformer and Battery

Pack Components

BP240V557C-1PH External battery pack for use with select Tripp Lite UPS Systems 1

BP240V787C-1PH External battery pack for use with select Tripp Lite UPS Systems 1

BP240V1037C-1PH External battery pack for use with select Tripp Lite UPS Systems 1

BP240V1407C-1PH External battery pack for use with select Tripp Lite UPS Systems 1

PDUMV20HV Metered 0U Vertical Rack PDU - Metered Power Distribution Unit for Network

Applications

PDUMV30HV Metered 0U Vertical Rack PDU - Metered Power Distribution Unit for Network

Applications

PDUMNV20HV Monitored PDU / Power Distribution Unit supports real-time remote monitoring of load

level, voltage and frequency with options for remote environmental and security

monitoring

PDUMNV30HV Monitored PDU / Power Distribution Unit supports real-time remote monitoring of load

level, voltage and frequency with options for remote environmental and security

monitoring

PDUMV20HVNET Switched, Metered PDU with Remote Monitoring - 0U Vertical Rackmount Power

Distribution Unit for Networks with Individually Switchable Outlets, Current Metering,

Remote Monitoring and Control

PDUMV30HVNET Switched, Metered PDU with Remote Monitoring - 0U Vertical Rackmount Power

Distribution Unit for Networks with Individually Switchable Outlets, Current Metering,

Remote Monitoring and Control

RELAYIOCARD Programmable Relay I/O Card 1

RELAYIOMINI 3 Relay I/O Mini-module 1

MODBUSCARD For remote monitoring and control via MODBUS protocol 1

P041-001-2 1-ft. 10AWG Heavy Duty Power Splitter Cable

(NEMA L6-30P to 2x NEMA L6-30R)

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=4675.

improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.

Table des matières

Autres manuels Tripp Lite UPS

Tripp Lite

Tripp Lite SmartOnline SU1000RTXL2U Guide de configuration

Tripp Lite

Tripp Lite OmniPro INT 300 Instructions d'installation et d'utilisation

Tripp Lite

Tripp Lite SmartPro SMART2200CRMXL Manuel utilisateur

Tripp Lite

Tripp Lite SM3000RMNAFTA Manuel utilisateur

Tripp Lite

Tripp Lite SmartPro SMART1400RM2U Manuel utilisateur

Tripp Lite

Tripp Lite OmniSmart OMNISMART1400 Manuel utilisateur

Tripp Lite

Tripp Lite INTERNET OFFICE 300 Guide de l'utilisateur

Tripp Lite

Tripp Lite AGSM5000Y3U3I Manuel utilisateur

Tripp Lite

Tripp Lite SmartPro Rackmount SMX1500XLRT2U Manuel utilisateur

Tripp Lite

Tripp Lite BC600SINE Manuel utilisateur

Tripp Lite

Tripp Lite UPS System AVRX550U Manuel utilisateur

Tripp Lite

Tripp Lite SmartOnline SU10000RT3U2TF Manuel utilisateur

Tripp Lite

Tripp Lite SmartOnline SU1500XL Manuel utilisateur

Tripp Lite

Tripp Lite SmartOnline SU3000RTXLCD3U Guide de configuration

Tripp Lite

Tripp Lite SmartOnline 220/380V Manuel utilisateur

Tripp Lite

Tripp Lite SmartOnline SU5000RT4U-IMS Manuel utilisateur

Tripp Lite

Tripp Lite SmartOnline SU3000XL Manuel utilisateur

Tripp Lite

Tripp Lite SM750XLNAFTA Manuel utilisateur

Tripp Lite

Tripp Lite SmartOnline SU40K Manuel utilisateur

Tripp Lite

Tripp Lite INTERNET550SER Manuel utilisateur

Tripp Lite

Tripp Lite BC Internet Manuel utilisateur

Tripp Lite

Tripp Lite SmartOnline SUINT1500LCD1U Manuel utilisateur

Tripp Lite

Tripp Lite SmartPro VS SMART2200VS Manuel utilisateur

Tripp Lite

Tripp Lite G1010USB Manuel utilisateur

Manuels UPS populaires d'autres marques

Pylontech

Pylontech Victron & Pylontech US5000 Manuel utilisateur

Tecnoware

Tecnoware EVO DSP PLUS MM 6.8 Manuel utilisateur

Mecer

Mecer ME-1000-WTU Manuel utilisateur

Mustek

Mustek PowerMust 530(B) Plus Manuel d'installation et d'exploitation

Emerson

Emerson Liebert NXL series Manuel utilisateur

MAKELSAN

MAKELSAN BOXER SERIES Manuel utilisateur

Block

Block PC-0524-400-0 Manuel utilisateur

CyberPower

CyberPower CP585LCD Manuel utilisateur

Eaton

Eaton 3S Instructions de montage

CyberPower

CyberPower Office Tower Series UPS 1000 Manuel utilisateur

CyberPower

CyberPower BM100 Manuel utilisateur

Best Power

Best Power 610 Manuel utilisateur

Best Power

Best Power Unity/I UT3K Manuel utilisateur

Mustek

Mustek PowerMust 400 Offline Manuel utilisateur

Xantrex

Xantrex Trace 512 UR-UPS Manuel utilisateur

Forza

Forza SL-1501UL Manuel utilisateur

LEGRAND

LEGRAND keor 310081 Manuel utilisateur

ABB

ABB Conceptpower DPA 500 Manuel utilisateur
