Tripp Lite ECO550UPSTAA Manuel utilisateur
TAA-Compliant 550VA Eco Energy-Saving UPS
System
MODEL NUMBER: ECO550UPSTAA
Description
The ECO550UPSTAA is compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases.
This standby green UPS offers complete protection from blackouts, brownouts and transient surges. Supports
green energy savings via built-in Eco outlets that automatically power off unused computer accessories like
printers or multi-media speakers when the computer is not in use. Full load efficiency rating of 99% also offers
energy-savings and cooler operation by limiting UPS power consumption to only 3 watts! Eco-friendly design
meets strict RoHS environmental standards. Provides uninterrupted transition to battery-derived AC output
during brownouts and power failures with enough runtime to save and shutdown connected equipment without
data loss. Offers complete protection in an ultra-compact desktop or wall-mountable housing. Includes 4 battery
supported outlets for computer, monitor and two vital system peripheral, plus 4 additional surge
suppression-only outlets for accessories not requiring battery support. Three of the surge-only outlets are
designated Eco outlets that can be configured to automatically power-off when the computer enters standby
mode or is shutdown. USB port enables UPS configuration options and unattended system shutdown without data loss in the case of extended power failure.
PowerAlert software is available via free download from www.tripplite.com. USB cable included. Built-in single line RJ11 phone suppression protects modem,
fax machine, cordless phone or other accessories with a dialup/DSL phone connection. Built-in audible alarm and front panel LEDs offer continuous status
information regarding line and battery power operation. 550VA / 300 watt power handling ability supports entry-level PC systems for up to 17 minutes during
power fail conditions. $100,000 connected equipment insurance (USA, Puerto Rico, & Canada Only).
Features
Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases
ECO550UPSTAA standby green UPS offers complete protection from blackouts, brownouts and transient surges
Built-in Eco outlets automatically power off unnecessary computer accessories like printers, scanners and speakers when computer is not in use
Full load efficiency rating of 99% saves energy and heat output by limiting UPS power consumption to only 3 watts with only 4 BTU/hr. of heat output
Eco-friendly design meets strict RoHS (Restriction of Hazardous Substances) environmental standards
550VA / 300 watt UPS provides battery-derived AC output during brownouts and power failures to support entry-level desktop computer with 15 inch LCD
monitor up to 17 minutes
Ultra compact UPS supports a variety of placement options for desktop or wallmount use
Highlights
Federal Trade Agreements Act /
TAA Compliant for GSA
Schedule purchases
550VA ultra-compact 120V
standby UPS, energy-saving
ECO outlets
Maintains AC output during power
failures, 99% line mode efficiency
ECO option turns off set of three
outlets when the computer is not
in use
USB port, TEL/DSL protection,
Wall mountable, Surge-only
outlets
NEMA 5-15P input plug and 8
NEMA 5-15R outlets
This product is ENERGY STAR
qualified for its ability to save
customers money while
helping to protect the
environment
Package Includes
ECO550UPSTAA TAA Compliant
UPS System
USB cable
Instruction manual with warranty
information
1 / 5
Ultra compact UPS supports a variety of placement options for desktop or wallmount use
Includes 4 UPS supported outlets for computer, monitor and 2 vital system peripherals requiring uninterrupted power
Includes 4 Surge-only outlets for accessories not requiring battery support
Three of the Surge-only outlets are designated Eco outlets that can be configured to automatically power-off when the computer is not in use
USB port enables UPS configuration options and unattended system shutdown without data loss in the case of extended power failure.
PowerAlert UPS monitoring software is available for free download from www.tripplite.com
Single line RJ11 phone suppression jacks protects modem, fax machine, cordless phone or other accessories from surges on dial-up/DSL phone
connections
USB cable included
Space-saving right angle input plug
$100,000 connected equipment insurance (USA, Puerto Rico and Canada only)
Specifications
OUTPUT
Output Volt Amp Capacity (VA) 550
Output Watt Capacity (watts) 300
Nominal Output Voltage(s)
Supported 115V; 120V
Frequency compatibility 60 Hz
Output voltage regulation (Battery
mode) 115V (+/- 5%)
Built-in UPS output receptacles 8 5-15R outlet(s)
Surge suppression only outlets 4 UPS outlets, 4 surge-only outlets
Output AC waveform (AC mode) Sine wave
Output AC waveform (battery mode) PWM sine wave
INPUT
Rated input current (at maximum
load) 10A
Nominal Input Voltage(s) Supported 120V AC
UPS input connection type 5-15P; Right-Angled
UPS Input cord length (ft.) 6
UPS Input cord length (m) 1.8
Recommended Electrical Service 15A 120V
Phase Single-Phase
BATTERY
Full load runtime (minutes) 3.5 min. (300w)
2 / 5
Half load runtime (minutes) 10 min. (150w)
DC system voltage (VDC) 12
Battery recharge rate (included
batteries) Less than 15 hours from 10% to 90%
LEDS ALARMS & SWITCHES
LED Indicators 3 LEDs indicate power status, overload/check battery and ECO-mode status
Alarms Audible alarm indicates power-failure and overload status
Switches Combination switch controls on/off power status and self-test operation; second recessed push-button switch
enables ECO outlet switching
SURGE / NOISE SUPPRESSION
UPS AC suppression joule rating 420
UPS AC suppression response time Instantaneous
UPS Dataline suppression 1 line TEL/DSL (1 in / 1 out)
EMI / RFI AC noise suppression Yes
PHYSICAL
Installation form factors supported
with included accessories Tower; Ultra-compact desktop
Primary form factor Desktop
UPS / Power Module dimensions in
primary form factor (height x width x
depth / inches)
3.1 x 10.8 x 5.7
UPS / Power Module dimensions in
primary form factor (height x width x
depth / cm)
7.8 x 27.6 x 14.6
UPS / Power Module weight (lbs) 6.6
UPS / Power Module weight (kg) 3
UPS Shipping dimensions (height x
width x depth / inches) 4.1 x 13 x 8
UPS Shipping dimensions (height x
width x depth / cm) 10.4 x 33 x 20.3
Shipping weight (lbs) 7.1
Shipping weight (kg) 3.2
UPS housing material ABS
ENVIRONMENTAL
Operating Temperature Range +32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius
Storage Temperature Range +5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius
Relative Humidity 0 to 95%, non-condensing
3 / 5
AC mode BTU / hr. (full load) 10.3
Battery mode BTU / hr. (full load) 194.3
AC mode efficiency rating (100%
load) 99%
COMMUNICATIONS
Communications interface USB (HID enabled)
PowerAlert software Free download from www.tripplite.com
Communications cable USB interface cable included
WatchDog compatibility Supports Watchdog application, OS and hard-reboot restart options for remote applications
LINE / BATTERY TRANSFER
Transfer time AC to battery mode: 4 milliseconds / Battery to AC mode: 3 milliseconds
Low voltage transfer to battery
power (setpoint) 99
High voltage transfer to battery
power (setpoint) 139
SPECIAL FEATURES
Cold Start (startup in battery mode
during a power failure) Cold-start operation supported
Green & high efficiency features Greater than 95% efficiency - GREEN UPS; Power saving auto-shutoff ECO outlets
CERTIFICATIONS
UPS Certifications Tested to UL1778 (USA); Tested to CSA (Canada); Tested to NOM (Mexico); Meets FCC Part 15 Category B
(EMI); ROHS (Restriction of Hazardous Substances); TAA Compliant; ENERGY STAR Qualified
WARRANTY
Product Warranty Period (U.S. &
Canada) 3-year limited warranty
Product Warranty Period (Latin
America) 3-year limited warranty
Product Warranty Period
(International) 2-year limited warranty
Product Warranty Period (Mexico) 3-year limited warranty
Connected Equipment Insurance
(U.S., Canada & Puerto Rico) $100,000 Ultimate Lifetime Insurance
Related Items
Optional Products
4 / 5
Model Number Description Qty.
WEXT5-INTERNET 5-Year Extended Warranty - For Internet Office, AVR and ECO Series UPS Systems 1
More information, including related products, owner's manuals, and additional technical specifications, can be found online at:
http://www.tripplite.com/sku/ECO550UPSTAA.
© 2014 Tripp Lite. All rights reserved. All trademarks are the sole property of their respective owners. Tripp Lite has a policy of continuous improvement.
Specifications are subject to change without notice. Photos may differ slightly from final products.
5 / 5
