Specifications

PowerAlert Console Launcher

1.9kW Single-Phase Switched PDU, 120V Outlets

(24 5-15/20R), L5-20P/5-20P, 10ft Cord, 0U

Vertical, TAA

MODEL NUMBER: PDUMV20NET

Description

Tripp Lite single phase Switched PDU / Power Distribution Unit offers advanced network control and

monitoring with the ability to turn on, turn off, recycle or lock-out power to each individual receptacle,

monitor site electrical conditions and remotely monitor output power consumption. PowerAlert interface

supports remote control and custom notification of user-specified conditions via email, PowerAlert

Console Launcher, SNMP, Telnet or SSH interface. Individually switched outlets can be controlled in real-

time to remotely reboot unresponsive network hardware, or be custom programmed for user-defined

power-up and power-down sequences to ensure proper startup of interdependent IT systems and prevent

inrush-related overloads as network equipment is first energized. Unused PDU outlets can be

electronically locked off to prevent the connection of unauthorized hardware. PDU output current

consumption in amps is continuously displayed locally via visual meter and remotely via network interface

to warn of potential overloads before critical IT mains or branch breakers trip.

Features

Highlights

Switched 20A 120V PDU, 0U 70

in. / 178cm Vertical Rackmount

Format

●

Reports voltage, frequency &

load level via ethernet interface

●

Visual current meter, Toolless

button mount installation

●

NEMA L5-20P input with 5-20P

adapter, attached 10 ft. / 3m

cord

●

24 switched NEMA 5-15/20R

outlets with cord retention

brackets

●

Temperature, humidity and

contact closure monitoring

options

●

Federal Trade Agreements Act /

TAA Compliant for GSA

Schedule purchases

●

Package Includes

Rackmount PDU

●

L5-20R to 5-15/20P adapter

●

Rackmount brackets

●

PDUMVROTATEBRKT

●

OVERVIEW

UPC Code 037332139719

PDU Type Switched

1 / 3

INPUT

Recommended Electrical Service 20A 120V

Maximum Input Amps 20

Maximum Input Amps Details Agency de-rated to 16A continuous

PDU Plug Type NEMA 5-20P; NEMA L5-20P

Input Phase Single-Phase

Input Cord Length (ft.) 10

Input Cord Length (m) 3.05

OUTPUT

Output Capacity Details 2.03kW (127V), 1.92kW (120V), 1.6kW (100V) / 20A total capacity (Agency de-rated to 16A); 16A max per outlet

Frequency Compatibility 50 / 60 Hz

Output Receptacles (24) 5-15/20R

Output Nominal Voltage 100; 120; 127

Customized Load Management

Receptacles Each outlet is individually controllable via remote interface

USER INTERFACE, ALERTS & CONTROLS

Front Panel LCD Display Digital meter reports PDU output current in amps

Front Panel LEDs 24 power availability LEDs confirm power off/on status for each built-in outlet

Switches Recessed reset switch for interface reboot and factory reset

SURGE / NOISE SUPPRESSION

Automatic Shut-Off No

PHYSICAL

Form Factors Supported 0U vertical rackmount; includes rackmount brackets. Supports toolless mounting in button-mount compatible racks

PDU Form Factor Vertical (0U)

Shipping Dimensions (hwd / cm) 10.16 x 15.24 x 184.15

Shipping Dimensions (hwd / in.) 4.00 x 6.00 x 72.50

Shipping Weight (kg) 7.03

Shipping Weight (lbs.) 15.50

Unit Dimensions (hwd / in.) 70 x 2.19 x 2.65

Unit Dimensions (hwd / cm) 178 x 5.6 x 6.7

Unit Weight (lbs.) 10

Unit Weight (kg) 4.54

2 / 3

not imply any affiliation with or endorsement by them. Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice.

Tripp Lite uses primary and third-party agencies to test its products for compliance with standards. See a list of Tripp Lite's testing agencies:

https://www.tripplite.com/products/product-certification-agencies

ENVIRONMENTAL

Relative Humidity 0-95% non-condensing

Operating Elevation (ft.) 0-10,000

Operating Elevation (m) 0-3000

COMMUNICATIONS

PowerAlert Software SNMPWEBCARD Interface: PowerAlert 12

Communications Cable RJ45-to-DB9 configuration/console Access cable

SNMP Compatibility Pre-installed  <a class="productLink" href="//www.tripplite.com/SNMP-Web-Management-Accessory-Card-

SmartPro-SmartOnline-UPS-Systems~SNMPWEBCARD">SNMPWEBCARD</a>  provides remote

monitoring via PowerAlert Console Launcher, Telnet, SSH, and SNMP management systems. Remote management

enables outlets to be turned on and off individually

Network Compatibility 10 Mbps; 100 Mbps (Fast Ethernet)

STANDARDS & COMPLIANCE

Certifications Tested to UL 60950-1 (USA, Canada), Class A (Emissions), NOM (Mexico), RoHS compliant, TAA Compliant

Certification Details Series Number(s) AG-0009

WARRANTY

Product Warranty Period

(Worldwide) 2-year limited warranty

3 / 3
