Tripp Lite RS-1215 Manuel utilisateur

1U Rackmount Power Strip with 12 Outlets and

15-ft. Cord

MODEL NUMBER: RS-1215

Description

Tripp Lite's RS-1215 Power Strip offers 15 amp capacity AC power distribution in a versatile multi-mount cabinet.

Detachable mounting flanges are configurable for rackmount, wallmount and under-counter installation. Uses

only 1 rack space (1U) when installed in any 19 inch rack meeting EIA standards. Unfiltered electrical

pass-through makes RS-1215 ideal for distributing alternate waveform UPS or generator power in rack

enclosures, network closets and more. Includes 12 NEMA5-15R outlets (6 front/6 rear), 15 ft AC power cord and

lighted switch with cover prevents risk of accidental turn-off.

PLUG/OUTLETS: Input: NEMA 5-15P

Output: 12 NEMA5-15R (6 front & 6 rear)

ELECTRICAL: 120V AC, 50/60Hz, 15A (Requires standard NEMA 5-15R wall receptacle)

FORMAT: Supports 19 in. rackmount (uses 1 rack space/1U), wallmount, under-counter and more

Features

Versatile all-metal cabinet with detachable mounting flanges allows rackmount, wallmount, undercounter and other creative mounting options

Uses one rack space (1U) in standard 19 inch rack ("zero U" mounting possible in many racks)

Unfiltered electrical pass-through reliably distributes alternate waveform AC power from UPS or generator to supported equipment

12 NEMA5-15R output receptacles (6 front/6 rear)

15 foot AC cord NEMA5-15P plug connection

Lighted power switch confirms power on/off status

Snap-in switch guard prevents accidental turn off

15 amp electrical capacity with circuit breaker

120V AC, 50/60Hz electrical compatibility

Specifications

Highlights

Designed for standard 19-inch

racks (1U high)

12 outlets (6 front / 6 rear)

15-amp circuit breaker

15 ft. cord

Applications

Offers multiple outlet power

distribution for multiple loads in

19 inch rackmount, wallmount

and under-counter applications,

such as internetworking, PC

systems, telecommunications,

audio/video, security, sound

reinforcement and more. Ideal

for distribution of UPS, generator

or commercially derived AC

power to protected equipment.

Package Includes

RS-1215

Mounting hardware

Instruction manual

1 / 3

OVERVIEW

Intended Application Computer Networks

OUTPUT

Frequency compatibility 50 / 60 Hz

Circuit Breaker (amps) 15

Outlet quantity / type 12 NEMA 5-15R

Outlet orientation 6 front facing / 6 rear facing

INPUT

Nominal Input Voltage(s) Supported 120V AC

Recommended Electrical Service 15A 120V

Input connection type NEMA 5-15P

Input cord length (ft.) 15

Input cord length (m) 4.572

Voltage compatibility (VAC) 120

LEDS ALARMS & SWITCHES

Switches Red illuminated 2 positon switch controls power to all outlets

Locking switch cover Transparent locking switch cover prevents accidental shutoff

PHYSICAL

Unit Dimensions (HWD/in) 1.75 (1U) x 17.5 x 4.5

Unit Dimensions (HWD/cm) 4.445 x 44.45 x 11.4

Unit weight (lbs) 4.6

Unit weight (kg) 2.09

Material of construction Sheet metal

Receptacle Color Black

AC line cord color Black

Style Rackmount

Form factors supported 1U rackmount, wall-mount and undercounter installation supported

Outlets center to center

measurement Distance between Front outlets = 83.35mm; Distance between Rear outlets = 114.3mm

SPECIAL FEATURES

TVSS grounding Back panel nut and bolt grounding lug

2 / 3

CERTIFICATIONS

UL1363 (Power Tap) UL1363 (UR status)

cUL / CSA (Canada) cUL

WARRANTY

Product Warranty Period (Worldwide) Lifetime limited warranty

Related Items

Optional Products

Model Number Description Qty.

PDUSIDEBRKT Enables Vertical Installation of Select 1U PDUs, Power Strips and Surge Suppressors in SmartRack

Configurations 1

More information, including related products, owner's manuals, and additional technical specifications, can be found online at:

http://www.tripplite.com/sku/RS-1215.

Specifications are subject to change without notice. Photos may differ slightly from final products.

3 / 3
