Tripp Lite SmartRack SR42UBEXPKD Manuel utilisateur

1

SmartRack™Assembly Instructions

Models: SR42UBKD, SR42UBEXPKD,

SR48UBKD and SR48UBEXPKD

1111 West 35th Street, Chicago, IL 60609 USA

773.869.1234 • www.tripplite.com

Copyright © 2008 Tripp Lite. All trademarks are the sole property of their respective owners.

2

Parts List

M6x12 M4x8 with

Lock Washer

M5x10

ABC

x36x24

x1 x1 x2 x2 x2

x4

x2 x2 x2 x1

x6

x16

See Owner’s

Manual

Required Tools:

• 5/32”(4 mm) Allen Wrench (Supplied)

• #1 Phillips Screwdriver (User-Supplied)

• #2 Phillips Screwdriver (User-Supplied)

WARNING: The rack enclosure is extremely heavy. Do not attempt to

unpack, move, assemble or install the enclosure without assistance.

Until it has been properly assembled and stabilized, the enclosure is

prone to tipping and could cause property damage and/or personal

injury. Use extreme caution when assembling the enclosure and be

sure to follow all handling and installation instructions. Do not attempt

to install equipment without ﬁrst stabilizing the enclosure. Refer to

Owner’s Manual.

Note:“EXP” models do not

include side panels.

#1 Phillips #2 Phillips

3

1

2

step

2

4

2

1

12

22

8

step

x2

x6

x6

x6

2-1

2-2

2-3

C

A

4

3

4

step

step

8

12

x4

x6

x6

x6

3-1

3-2

3-3

1

A

C

5

5

step

89012345678901234567890

89012345678901234567890

89012345678901234567890

x3

5-1

5-2

5-3

12

2

B

x2

The rail attachment points are numbered to help you align each pair of rails at the

same depth. Before attaching the rails using the screws (shown in Step 5-3), make

sure the same number appears in all three windows. Note: Number shown in

Step 5-2 is for illustration purposes only; attach rails at desired depth.

6

2

1

7-2

7-1

7

step

1

6

step

24 x3

6-1

6-3

x4

2

2

B

901234567890123456789012345

901234567890123456789012345

901234567890123456789012345

6-2

The rail attachment points are numbered to help you

align each pair of rails at the same depth. Before attaching

the rails using the screws (shown in Step 6-3), make sure

the same number appears in all three windows. Note:

Number shown in Step 6-2 is for illustration purposes

only; attach rails at desired depth.

7

8

step

2

1

x4

4

Note: For

“EXP” models,

skip this step.

8

1111 West 35th Street, Chicago, IL 60609 USA

773.869.1234 • www.tripplite.com

Tripp Lite follows a policy of continuous improvement. Product specications are subject to change without notice.

Made in China.

200805170 93-2818
