Owner’s Manual
USB 3.1 Type-C™
Vertical Adapters
Models: U436-000-GB (USB-C to Gigabit Ethernet),
U444-000-DP4K6B (USB-C to 4K DisplayPort),
U444-000-H4K6B (USB-C to 4K HDMI),
U444-000-VGA (USB-C to VGA)
USB Type-C and USB-C are trademarks of USB Implementers Forum
1111 W. 35th Street, Chicago, IL 60609 USA
www.tripplite.com/support
Copyright © 2019 Tripp Lite. All rights reserved.
All trademarks are the property of their owners.
Este manual esta disponible en español en la página
de Tripp Lite: www.tripplite.com.
Ce manuel est disponible en français sur le site Web
de Tripp Lite : www.tripplite.com.
Русскоязычная версия настоящего руководства
представлена на веб-сайте компании Tripp Lite по
адресу: www.tripplite.com.
WARRANTY REGISTRATION
Register your product today and be automatically entered to
win an ISOBAR surge protector in our monthly drawing!
www.tripplite.com/warranty
2
Product Features
• Add a Gigabit Ethernet, DisplayPort, HDMI,
or VGA port via the USB-C port on your
laptop, tablet or other device
• Type-C input features a vertical molding to
maximize space around your device’s ports
and prevent blockage of adjacent ports
• U444-000-DP4K6B supports DP 1.2 video
resolutions up to 3840 x 2160 (4K x 2K)
@ 60 Hz, DisplayPort Alternate Mode,
7.1 Channel Surround Sound, 4:4:4 Color
Space, HDCP 2.2 and HDR compatibility
• U444-000-H4K6B supports HDMI 2.0 video
resolutions up to 3840 x 2160 (4K x 2K) @
60 Hz, 7.1 Channel Surround, 4:4:4 Color
Space and HDCP 2.2 compatibility
• U444-000-VGA supports video resolutions
up to 1920 x 1200 (1080p) @ 60 Hz and
1.62 / 2.7 Gbps over 4 lanes
• U436-000-GB supports full Gigabit Ethernet
transmission speeds, Full-Duplex flow control
(IEEE 802.3x), is compatible with IEEE
802.3, IEEE 802.3u, IEEE 802.1P Layer 2
priority encoding, IEEE 802.1Q VLAN tagging
and IEEE 802.3az-2010 (EEE)
3
Product Features
Package Contents
System Requirements
• U436-000-GB, U444-000-DP4K6B,
U444-000-H4K6B or U444-000-VGA
• Owner’s Manual
• USB Type-C device
Note: U444-000-DP4K6B requires a device that
supports DisplayPort Alternate Mode.
•
Gigabit Ethernet connection (U436-000-GB),
DisplayPort monitor (U444-000-DP4K6B),
HDMI monitor (U444-000-H4K6B) or
VGA monitor (U444-000-VGA)
• Plug-and-play—no software or drivers
required
Note: U436-000-GB may require a driver if using a
Windows OS earlier than 10.1.
4
Optional Accessories
• P580-Series DisplayPort Cables
• N201-Series Cat6 Gigabit Snagless Patch
Cables
• P500-Series VGA Coax High-Resolution
Cables
• P569-Series HDMI High-Speed Cables
Installation
1. Connect the adapter’s USB Type-C
connector to the USB Type-C port on your
smartphone, tablet, Ultrabook or computer.
2. Using a UTP cable (such as Tripp Lite N201-
Series Cat6 cables), connect the adapter’s
RJ45 port to a network.
OR
Using a DisplayPort cable (such as Tripp Lite
P580-Series DisplayPort cables), connect
the adapter’s DisplayPort port to a monitor.
OR
5
Installation
Using an HDMI cable(such as Tripp Lite
P569-Series HDMI cables), connect the
adapter’s HDMI port to a monitor.
OR
Using a VGA cable (such as Tripp Lite P500-
Series VGA cables), connect the adapter’s
VGA port to a monitor.
3. If using the U444-000-DP4K6B,
U444-000-H4K6B or U444-000-VGA
adapter, the video image will appear on the
add-on monitor. Use your device’s display
settings to customize how video is displayed
on the add-on monitor.
6
Specifications
Connector Input USB Type-C (Male) (All
models)
Connector Output Ethernet – RJ45 (Female)
(U436-000-GB)
DisplayPort – DisplayPort
(Female) (U444-000-DP4K6B)
HDMI – HDMI (Female)
(U444-000-H4K6B)
VGA – HD15 (Female)
(U444-000-VGA)
Maximum Video
Resolutions
3840 x 2160 @ 60 Hz
(U444-000-DP4K6B,
U444-000-H4K6B)
1920 x 1200 @ 60 Hz
(U444-000-VGA)
Maximum Ethernet
Transmission
Speeds
10/100/1000 Mbps
(U436-000-GB)
7
Specifications
Operating
Temperature
32°F ~ 104°F / 0°C ~ 40°C
(All models)
Storage
Temperature
14°F ~ 122°F / -10°C ~ 50°C
(U436-000-GB)
5°F ~ 122°F / -15°C ~ 50°C
(U444-000-VGA,
U444-000-DP4K6B and
U444-000-H4K6B)
Relative Humidity 0% ~ 85% RH,
Non-Condensing (All models)
8
Warranty and
Product Registration
3-Year Limited Warranty
TRIPP LITE warrants its products to be free from defects in
materials and workmanship for a period of three (3) years
from the date of initial purchase. TRIPP LITE’s obligation
under this warranty is limited to repairing or replacing (at its
sole option) any such defective products. To obtain service
under this warranty, you must obtain a Returned Material
Authorization (RMA) number from TRIPP LITE or an authorized
TRIPP LITE service center. Products must be returned to
TRIPP LITE or an authorized TRIPP LITE service center with
transportation charges prepaid and must be accompanied by
a brief description of the problem encountered and proof of
date and place of purchase. This warranty does not apply to
equipment, which has been damaged by accident, negligence
or misapplication or has been altered or modified in any way.
EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE.
Some states do not permit limitation or exclusion of implied
warranties; therefore, the aforesaid limitation(s) or exclusion(s)
may not apply to the purchaser.
EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE
BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR
CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF
THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF
SUCH DAMAGE. Specifically, TRIPP LITE is not liable for any
costs, such as lost profits or revenue, loss of equipment, loss
of use of equipment, loss of software, loss of data, costs of
substitutes, claims by third parties, or otherwise.
9
Warranty and
Product Registration
Product Registration
Visit www.tripplite.com/warranty today to register your new
Tripp Lite product. You’ll be automatically entered into a
drawing for a chance to win a FREE Tripp Lite product!*
* No purchase necessary. Void where prohibited. Some restrictions apply.
See website for details.
FCC Notice, Class B
This device complies with part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must
accept any interference received, including interference that
may cause undesired operation.
Note: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
10
Warranty and
Product Registration
• Consult the dealer or an experienced radio/TV technician
for help.
Any changes or modifications to this equipment not expressly
approved by Tripp Lite could void the user’s authority to operate
this equipment.
WEEE Compliance Information for Tripp Lite Customers
and Recyclers (European Union)
Under the Waste Electrical and Electronic Equipment
(WEEE) Directive and implementing regulations,
when customers buy new electrical and electronic
equipment from Tripp Lite they are entitled to:
• Send old equipment for recycling on a one-for-one,
like-for-like basis (this varies depending on the
country)
• Send the new equipment back for recycling when
this ultimately becomes waste
Use of this equipment in life support applications where failure
of this equipment can reasonably be expected to cause the
failure of the life support equipment or to significantly affect its
safety or effectiveness is not recommended.
Tripp Lite has a policy of continuous improvement.
Specifications are subject to change without notice.
