Model 9325

True RMS AC/DC Clamp-On Meter

Instruction Manual

TRIPLETT

84-898

7/11

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

Safety

International Safety Symbols

This symbol, adjacent to another symbol or terminal,

indicates the user must refer to the manual for further

information.

This symbol, adjacent to a terminal, indicates that, under

normal use, hazardous voltages may be present

Double insulation

SAFETY NOTES

•Do not exceed the maximum allowable input range of any

function

•Do not apply voltage to meter when resistance function is

selected.

•Set the function switch OFF when the meter is not in use.

WARNINGS

•Set function switch to the appropriate position before

measuring.

•When measuring volts do not switch to current/resistance

modes.

•When changing ranges using the selector switch always

disconnect the test leads from the circuit under test.

•Do not exceed the maximum rated input limits.

CAUTIONS

Improper use of this meter can cause damage, shock, injury

or death. Read and understand this user manual before

operating the meter.

Always remove the test leads before replacing the battery.

Inspect the condition of the test leads and the meter itself for

any damage before operating the meter. Repair or replace any

damage before use.

Use great care when making measurements if the voltages

are greater than 25VAC rms or 35VDC. These voltages are

considered a shock hazard.

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

Remove the battery if the meter is to be stored for long periods.

Always discharge capacitors and remove power from the

device under test before performing Diode, Resistance or

Continuity tests.

•Voltage checks on electrical outlets can be difficult and

misleading because of the uncertainty of connection to the

recessed electrical contacts. Other means should be used to

ensure that the terminals are not "live".

•If the equipment is used in a manner not specified by the

manufacturer, the protection provided by the equipment may

be impaired.

Meter Description

1.Current clamp

2.Non-contact AC voltage indicator light

3.Clamp trigger

4.Data Hold and Backlight button

5.Rotary Function swith

6.Hz% Hlod button

7.RANGE select button

8.Relative button

9.MIN/MAX Hlod button

10.MODE select button

11.LCD display

12.COM input jack

13.V ΩCAP TEMPHz jack

14.Battery Cover

Function

A AC/DC

V DC, V AC

Frequency, Resistance, Diode,

Continuity , Capacitance Test

Temperature (°C/°F)

Maximum Input

1000A

1000V DC/AC

1000V DC/ AC

Input Limits

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

678

1.AC DC

3.8.8.8.8

4.AUTO

5.REL

8.HOLD

9.°C,°F, μ,m,V,A,K,M,Ω,

10.MAX MIN

11.Hz %y

AC (alternating current)

and DC (direct currrent)

Minus sign

6000 count (0 to 5999)

measurement reading with

61segments Analog Bargraph

AutoRange mode

Relative mode

Diode test mode

Audible Continuity

Data Hold mode

Units of measure list

MAX/MIN mode

Frequency/duty cycle mode

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

Specifications

Function

AC Current

(50/60Hz)

AC Current

(400Hz)

DC Current

DC Voltage

AC Voltage

(50-400Hz)

Resistance

Capacitance

Frequency

Sensitivity:

15Vrms

Temp (type-K)

(probe accuracy

not included)

Range & Resolution

600.0 AAC

1000 AAC

600.0 AAC

1000 AAC

600.0 ADC

1000 ADC

600.0 mVDC

6.000 VDC

60.00 VDC

600.0 VDC

6.000 VAC

60.00 VAC

600.0 VAC

600.0 Ω

6.000KΩ

60.00KΩ

600.0KΩ

6.000MΩ

60.00MΩ

40.00nF

400.0nF

4.000μF

40.00μF

400.0μF

4000μF

10-10kHz

-20.0°C to 760.0°C

-4.0°F to1400.0°F

Accuracy (% of reading)

± (2.8 % + 8 digits)

± (3.0 % + 8 digits)

± (5.0 % + 10 digits)

± (2.8 % + 5 digits)

± (3.0 % + 5 digits)

± (0.8% + 2 digits)

± (1.5% + 2 digits)

± (1.8% + 8 digits)

± (1.0% + 4 digits)

± (1.5% + 2 digits)

± (2.5% + 3 digits)

± (3.5% + 5 digits)

Unspecified

(3% reading + 5 digits)

(4.0% reading + 10 digits)

(5.0% reading + 10 digits)

(1.5% reading + 2 digits)

(3%rdg+5°C)

(3%rdg+9°F)

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

Clamp size

Diode Test

Continuity Check

Low Battery Indication

Overrange Indication

Measurements Rate

Input Impedance

Display

AC Current

AC Voltage bandwidth

Operating Temperature

Storage Temperature

Operating Humidity

Storage Humidity

Operating Altitude

Over voltage

Battery

Auto OFF

Dimensions/Weight

Safety

Opening 1.5" (40mm) approx

Test current of 0.3mA typical;

Open circuit voltage 1.5V DC

typical.

Threshold <40Ω;

Test current < 0.5mA

“ ” is displayed

“OL” is displayed

2 per second, nominal

10MΩ(VDC and VAC)

6000 counts LCD

50-400Hz (AAC)

50-400Hz (VAC)

41°F to 104°F (5°C to 40°C)

-4°F to 140°F (-20°C to 60°C)

Max 80% up to 87°F(31°C)

decreasing linearly to 50%

at 104°F(40°C)

<80%

7000ft. (2000meters) maximum.

Category III 600V

One 9V Battery

approx. 15 minutes

232x77x39mm/271g

For indoor use and in accordance

with Overvoltage Category II,

Pollution Degree 2. Category II

includes local level, appliance,

portable equipment, etc., with

transient overvoltages less than

Overvoltage Cat. III

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

Operation

NOTICES: Read and understand all warning and precaution

statements listed in the safety section of this operation manual

prior to using this meter. Set the function select switch to the

OFF position when the meter is not in use.

AC/DC Current Measurements

WARNING: Ensure that the test leads are disconnected from

the meter before making current clamp measurements.

1.Set the Function switch

to the 1000ADC,600ADC,

1000AAC or600AAC range.

2.If the range of the

measured is not known,

select the higher range first

then move to the lower

range if necessary.

3.Press the trigger to open

jaw. Fully enclose one

conductorto be measured.

The clamp meter LCD will display the reading.

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

DC/AC Voltage Measurements

1.Insert the black test lead into the negative COM terminal

and the

red test lead into the positive V terminal.

2.Set the function switch to the V position.

3.Select AC or DC with the MODE button.

4.Connect the test leads in parallel to the circuit under test.

5.Read the voltage measurement on the LCD display.

Resistance Measurements

1.Insert the black test lead into the negative COM terminal

and the red test lead into the positive terminal.

2.Set the function switch to the CAP position.

3.Touch the test probe tips across the circuit or component

under test. It is best to disconnect one side of the device

under test so the rest of the circuit will not interfere with the

resistance reading.

4.For Resistance tests, read the resistance on the LCD display.

Diode and Continuity Measurements

1.Insert the black test lead banana plug into the negative

COM jack and the red test lead banana plug into the positive

diode jack.

2.Turn the rotary switch to the CAP position.

3.Press the MODE button until “ “ appears in the display.

4.Touch the test probes to the diode under test. Forward

voltage will indicate 0.4V to 0.7V. Reverse voltage will indicate

“OL”. Shorted devices will indicate near 0mV and an open

device will indicate “OL” in both polarities.

Red Black Black

Forward test Reverse test

For Continuity tests, if the resistance is < 40Ω, a tone will sound.

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

Capacitance Measurements

WARNING: To avoid electric shock, disconnect power to the

unit under test and discharge all capacitors before taking any

capacitance measurements. Remove the batteries and unplug

the line cords.

1.et the rotary function switch to the CAP position.

2.Insert the black test lead banana plug into the negative

(COM) jack.

Insert the red test lead banana plug into the positive (V) jack.

3.Touch the test leads to the capacitor to be tested.

4.Read the capacitance value in the display

Frequency/duty cycle Measurements (electronic)

1.Set the rotary function switch to “V” position.

2.Select ACV with the MODE button

3.Press the Hz/% button to indicate “Hz” in the display.

4.Insert the black lead banana plug into the negative COM

jack and the red test lead banana plug into the positive Hz jack.

5.Touch the test probe tips to the circuit under test.

6.Read the frequency on the display.

7.Press the Hz/% button again to indicate “%” on the display.

Read the % of duty cycle on the display.

Temperature Measurements

WARNING: To avoid electric shock, disconnect both test

probes from any source of voltage before making a

temperature measurement.

1.Set the function switch to TEMP.

2.Insert the Temperature Probe into the negative (COM) and

the V jacks, making sure to observe the correct polarity.

3.Select °C o°F with the MODE button.

4.Touch the Temperature Probe head to the part whose

temperature you wish to measure. Keep the probe touching

the part under test until the reading stabilizes (about 30

seconds).

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

5.Read the temperature in the display. The digital reading

will indicate the proper decimal point and value.

WARNING: To avoid electric shock, be sure the thermocouple

has been removed before changing to another measurement

function

Non-Contact AC Voltage Measurements

WARNING:Risk of Electrocution. Before use, always test the

Voltage Detector on a known live circuit to verify proper

operation

1.Touch the probe tip to the hot conductor or insert into the

hot side of the electrical outlet.

2.If AC voltage is present, the detector light will illuminate.

NOTE: The conductors in electrical cord sets are often twisted.

For best results, rub the probe tip along a length of the cord

to assure placing the tip in close proximity to the live conductor.

NOTE: The detector is designed with high sensitivity. Static

electricity or other sources of energy may randomly trip the

sensor.

MODE BUTTON

To select DC/ACV,OHM/ Diode/Continuity/CAP , °C/°F

MIN & MAX Recording Button

Press MIN/MAX to enter MIN, MAX Recording mode (manual

range only ). Select the proper range before selecting MIN

MAX to ensure that the MIN/MAX reading will not exceed the

testing range. Press once to select MIN. Press again to select

MAX. and press again release MIN/MAX recording function.

REL BUTTON

For DCA Zero & Offset adjustment.

Data Hold Button

To freeze the LCD meter reading, press the data hold button.

The data hold button is located on the left side of the meter

(top button). While data hold is active, the HOLD display icon

appears on the LCD. Press the data hold button again to return

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

Autres manuels pour 9325

Autres manuels Triplett Instrument de mesure

Triplett

Triplett RHT05 Manuel utilisateur

Triplett

Triplett CD100 Manuel utilisateur

Triplett

Triplett GSM130 Manuel utilisateur

Triplett

Triplett SL600-KIT Manuel utilisateur

Triplett

Triplett CM650 Manuel utilisateur

Triplett

Triplett VCT1000 Manuel utilisateur

Triplett

Triplett LT65 Manuel utilisateur

Triplett

Triplett GSM250 Manuel utilisateur

Triplett

Triplett CFM100 Manuel utilisateur

Triplett

Triplett SLM400 Manuel utilisateur

Triplett

Triplett SL600-KIT Manuel utilisateur

Triplett

Triplett HS10 Manuel utilisateur

Triplett

Triplett UTG300 Manuel utilisateur

Triplett

Triplett CM1000 Manuel utilisateur

Triplett

Triplett RHT02 Manuel utilisateur

Triplett

Triplett WireMaster XR-2 Manuel utilisateur

Triplett

Triplett RHT02 Manuel utilisateur

Triplett

Triplett GSM120 Manuel utilisateur

Triplett

Triplett 60-A Manuel utilisateur

Triplett

Triplett 9200-A Manuel utilisateur

Triplett

Triplett EG480 Manuel utilisateur

Triplett

Triplett 360PL Manuel utilisateur

Triplett

Triplett Cam View Elite Manuel utilisateur

Triplett

Triplett RHT37 Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
