OWNER’S MANUAL
TRINITY 6-TIER NSF WIRE SHELVING RACK W/ WHEELS
MODEL # TBFZ-0945/TBTZ-0945/TBFPBA-0945/TBTPBA-0945
Important / Important / Importante
FOR 3D ASSEMBLY INSTRUCTIONS
POUR DES DIRECTIVES D’ASSEMBLAGE 3D
PARA INSTRUCCIONES DE ENSAMBLAJE EN 3D
Intelligent Instructions
Directives intelligentes
Instrucciones Inteligentes
DOWNLOADTHEFREEAPP | TÉLÉCHARGERL’APPLICATION GRATUITE| DESCARGUELAAPLICACIÓNGRATUITA
PARTS LIST
Your TRINITY 6-Tier NSF Wire Shelving Rack w/ Wheels should include the following parts. Please inspect
box contents to ensure you have received all components.
If you are missing any parts, need assistance with assembly or have questions, please contact TRINITY
via our “Contact Us” section at www.trinityii.com.
You will NOT need additional tools for assembly.
A
TOP POLE (4)
End Cap (4) and
Pole Connector (4)
are pre-installed
B
BOTTOM POLE (4)
Threaded Insert (4)
is pre-installed
C
SHELF (6)
D
SLIP SLEEVE
(48) + (2) Extra
E
LOCKING
CASTER (2)
F
NON-LOCKING
CASTER (2)
G
WRENCH (1)
H
FEET LEVELER (4)
For Stationary option
I
THREADED
INSERT (4)
J
END CAP (4)
Used when making (2) 3-Tier Racks
1© 2023 TRINITY - 800.985.5506
ASSEMBLY INSTRUCTIONS
STEP 1
Screw LOCKING CASTER (E) and NON-LOCKING CASTER (F)
into the bottom of BOTTOM POLE (B). Turn clockwise to
screw in place. Make sure LOCKING CASTERS (E) are on the
same side.
Warning: Use the included WRENCH (G) to tighten
CASTERS (E & F) to BOTTOM POLES (B) completely.
Failure to do as instructed could result in the caster
stem breaking.
STEP 2
On BOTTOM POLE (B), place 1 pair of SLIP
SLEEVES (D) at the desired level with the arrow on
SLIP SLEEVE (D) facing up and the word “TOP”
right side up. Slide the pair of SLIP SLEEVES (D)
until you hear a click to confirm the pair is locked
onto BOTTOM POLE (B). DO NOT place more
than one pair on one BOTTOM POLE (B) at a time.
Do this for each BOTTOM POLE (B) and make sure
all (8) SLIP SLEEVES (D) on BOTTOM POLES (B) are
at the same level.
Note: For stability, the lowest SLIP SLEEVES (D)
should be installed no higher than the 3rd
indentation from the caster end of BOTTOM
POLES (B).
© 2023 TRINITY - 800.985.5506 2
ASSEMBLY INSTRUCTIONS
STEP 3
Slide (4) BOTTOM POLES (B) through the corner cylinders of SHELF (C). Make
sure SHELF (C) corner cylinders are positioned over SLIP SLEEVES (D).
Repeat STEP 2 of placing SLIP SLEEVES (D) on BOTTOM
POLES (B) and assemble one more SHELF (C).
Note:
•The level side of SHELF (C) is the TOP side (the
TRINITY logo on the corner cylinders should be
right-side up.)
•Use a rubber mallet, if needed, to secure SHELF (C).
•For convenience, place BOTTOM POLES (B) with Locking Casters on the long side of the shelf if the
rack will be pushed against a wall OR if the rack is frequently rolled around like a cart, place
BOTTOM POLES (B) with Locking Casters on the side being pushed or pulled.
STEP 4
Screw TOP POLE (A) into BOTTOM POLE (B) by the pre-installed pole
connector. The tops of TOP POLE (A) are indicated by BLACK END CAP.
Repeat STEP 2 of placing SLIP SLEEVES (D) on BOTTOM POLES (B) and
STEP 3 to assemble other (4) SHELVES (C) to complete the 6-Tier Shelving
Rack.
3© 2023 TRINITY - 800.985.5506
Note: 2 people are
needed to put last
shelf on.
ASSEMBLY INSTRUCTIONS
Stationary Option
In STEP 1, instead of screwing
CASTERS into the bottoms of
BOTTOM POLES (B), screw in (4)
FEET LEVELERS (H). Turn
clockwise to screw in place.
Repeat STEPS 2 –4.
Adjust FEET LEVELERS (H) as
needed so that the Shelving
Rack is stable on the floor.
Making (2) 3-Tier Racks Option
REPEAT STEPS 1 - 3
STEP 4
Push in (4) END CAPS (J) into the tops of
BOTTOM POLES (B). Place (8) SLIP
SLEEVES (D) on the last indentation of (4)
BOTTOM POLES (B) and place SHELF (C)
corner cylinders onto SLIP SLEEVES (D) to
complete one 3-Tier Rack with Casters.
© 2023 TRINITY - 800.985.5506 4
ASSEMBLY INSTRUCTIONS
STEP 5
Unscrew (4) pre-installed pole
connectors from the bottoms of TOP
POLES (A) and screw in THREADED
INSERTS (I). Screw (4) FEET LEVELERS (H)
into THREADED INSERTS (I).
STEP 6
Following STEPS 1 –3, assemble (3) SHELVES (C)
onto TOP POLES (A) to complete another 3-Tier
Rack with Feet Levelers.
5© 2023 TRINITY - 800.985.5506
SERVICE PARTS LIST –TBFZ-0945/TBTZ-0945 (Chrome)
TRINITY Customer Service provides the following replacement parts:
Part Number Description Part Number Description
1) XBK-23-004-2517 End Cap 7) XBK-01-011-2543 Slip Sleeve
2) ZSV-04-006-3600 Top Pole 8) XXX-97-002-0001 Wrench
3) ZSV-01-013-2523 Pole Connector 9) ZSV-99-007-4010 Non-locking Caster
4) ZSV-04-042-3600 Bottom Pole 10) ZSV-01-014-2513 Threaded Insert
5) ZSV-99-008-4010 Locking Caster 11) XBK-98-003-2538 Feet Leveler
6) ZSV-03-050-4818 Shelf 12) ZSV-02-011-0001 Anti-tip Hardware Pack
© 2023 TRINITY - 800.985.5506 6
SERVICE PARTS LIST –TBFPBA-0945/TBTPBA-0945 (Black Anthracite)
TRINITY Customer Service provides the following replacement parts:
Part Number Description Part Number Description
1) XBK-23-004-2517 End Cap 7) XBK-01-011-2543 Slip Sleeve
2) ZSV-04-006-3600 Top Pole 8) XXX-97-002-0001 Wrench
3) ZSV-01-013-2523 Pole Connector 9) ZSV-99-007-4010 Non-locking Caster
4) ZSV-04-042-3600 Bottom Pole 10) ZSV-01-014-2513 Threaded Insert
5) ZSV-99-008-4010 Locking Caster 11) XBK-98-003-2538 Feet Leveler
6) ZSV-03-050-4818 Shelf 12) ZSV-02-011-0001 Anti-tip Hardware Pack
7© 2023 TRINITY - 800.985.5506
WARNINGS
1. Read and understand all instructions. Failure to follow all instructions may result in injury
and/or damage.
2. Tighten all casters completely by using the wrench. Failure to do as instructed could result
in the caster stem breaking, thereby causing the product to collapse.
3. The warnings, cautions, and instructions discussed in this manual cannot cover all
possible conditions or situations that may occur. The user must always be aware of the
environment and ensure to use the product in a safe and responsible manner.
4. Do NOT modify the product in any way. Unauthorized modification may impair the
function and/or safety of the product, and may affect the life of the product.
5. Check for damaged parts. Before using this product, carefully check that all parts are in
good condition, and that the product will operate properly and perform its intended
function. Check for damaged parts and any other conditions that may affect the operation
of this product. Replace damaged or worn parts, and never use this product with a damaged
part.
6. Do NOT overload the product.
7. Do NOT roll the product on an uneven surface. Only move the product on a smooth
surface. Rolling over rough or uneven surfaces may cause casters to break or items on the
product to fall, resulting in injury and / or damage. Wood and laminate flooring can be
scratched or dented. Ensure your flooring can bear the weight of the rack before rolling the
rack across your flooring.
Weight capacity per Shelf on Feet Levelers
(evenly distributed) 454.6 kg / 1000 lb
Weight capacity per Shelf on Casters
(evenly distributed) 60.6 kg / 133.3 lb
Total weight capacity of Shelving Rack
(evenly distributed)
2727.3 kg / 6000 lb (on Feet Levelers)
363.6 kg / 800 lb / (on Casters)
CARE AND MAINTENANCE
•Avoid harsh, abrasive cleaners, and other corrosive chemicals.
•The chrome color version (TBFZ-0945/TBTZ-0945) is not recommended for outdoor use.
© 2023 TRINITY - 800.985.5506 8
PRODUCT REGISTRATION
Thank you for purchasing a TRINITY 6-Tier NSF Wire Shelving Rack w/ Wheels. In order to register your
product and receive streamlined customer service, please fill out the following Product Registration
Form and (1) fax the form to 310.347.4134 (2) complete the Product Registration Form online at
your original receipt with your submission.
First Name: Last Name:
Address:
City: State: Zip Code:
Email Address: Phone:
Product Model #: Purchase Date: / /
Location of Purchase:
Please rate the importance of each feature (1=least important; 10=most important)
Quality Price Size/Capacity Appearance Other
How did you hear about our product?
Magazine Ad Catalog Salesperson Wordof Mouth
Internet Store Display Other
Marital Status: Single Married
Household Income: Below $50,000 $50,000-$150,000 $150,000+
Education: High School College GraduateSchool
Primary Residence: Own Rent
Comments/Suggestions:
9© 2023 TRINITY - 800.985.5506
