TRINITY Pro TLSF-4811 Manuel utilisateur
OWNER’S MANUAL
Important / Important / Importante
DOWNLOAD THE FREE APP | TÉLÉCHARGER L’APPLICATION GRATUITE| DESCARGUE LAAPLICACIÓN GRATUITA
Directives intelligentes
Instrucciones Inteligentes
TRINITY PRO 66” STAINLESS STEEL ROLLING WORKBENCH
W/CLAMPABLE RAISED TOP
Model # TLSF-4811
FOR 3D ASSEMBLY INSTRUCTIONS
POUR DES DIRECTIVES D’ASSEMBLAGE 3D
PARA INSTRUCCIONES DE ENSAMBLAJE EN 3D
Your TRINITY PRO 66in Stainless Steel Rolling Workbench w/Clampable Raised Top should include the
following parts. Please inspect box contents to ensure you have received all components.
If you are missing any parts, need assistance with assembly or have questions, please contact TRINITY
Customer Service: 800.985.5506 or customerservice@trinityii.com. Parts can also be requested online
via “Contact Us” section at www.trinityii.com.
You will need 10mm (for handles) and 14mm (for casters) socket wrenches for assembly which are NOT
included.
A
SIDE HANDLE (2)
BC
CASTER BOLT (16)
M10
D
LINER (12)
EGH
HANDLE BOLT (12)
M6 LOCKING
CASTER (2)
F
NON-LOCKING
CASTER (2) KEY (2)
© 2022 TRINITY - 800.985.5506
1
WORKBENCH (1)
I
BIN (9)
PARTS LIST
ASSEMBLY INSTRUCTIONS
Position SIDE HANDLE (B) over pre-installed nuts
on side of WORKBENCH (A). Insert HANDLE
BOLTS (C) through holes on SIDE HANDLE (B).
Use a 10mm socket wrench to fully tighten
HANDLE BOLTS (C) to WORKBENCH (A).
Repeat to install other SIDE HANDLE (B).
AB
C
© 2022 TRINITY - 800.985.5506 2
STEP 1
STEP 2
10mm
A (1) B (2) C (12)
Location of parts:
1) KEYS (H) are hooked to key leash
mounted in top middle drawer.
2) SIDE HANDLES (B), HANDLE BOLTS (C),
CASTERS (D/E), CASTER BOLTS (F),
LINERS (G) and BINS (I) are inside
accessory boxes in bottom middle
drawer.
1
2
ASSEMBLY INSTRUCTIONS
© 2022 TRINITY - 800.985.5506
3
STEP 3
D (2) E (2) F (16)
Lay WORKBENCH (A) on its backside. Two people
are needed. Do NOT attempt this alone.
Position LOCKING CASTERS (D) on side of
WORKBENCH (A) of your choice and align holes to
pre-installed nuts on the underside of
WORKBENCH (A). Use a 14mm socket wrench to
fully tighten CASTER BOLT (F) to WORKBENCH (A).
Repeat to install NON-LOCKING CASTERS (E).
Notes:
* Make sure to install both of LOCKING CASTERS
(D) on same side.
** For ease of use, place LOCKING CASTERS (D) on
side you will regularly push or pull.
*** If you plan to push workbench against a wall,
place LOCKING CASTERS (D) on front long side for
ease of access.
14mm
A
STEP 4
ED
F
G (12)
Place LINERS (G) in each pull-out tray and
each drawer.
Pull-out Tray
G
ASSEMBLY INSTRUCTIONS
STEP 5
Open Bin Drawer and hang 3 BINS (I) on each
Shelf Side Panel as shown. I (9)
I
© 2022 TRINITY - 800.985.5506 4
Shelf Side Panel
Bin Drawer
USAGE INSTRUCTIONS
DRAWER REMOVAL
DRAWER REPLACEMENT
Pull drawer out so that it is almost fully extended. On RIGHT-hand side, pull black release lever UP. On
LEFT-hand side, push black release lever DOWN. While holding the levers as instructed, pull drawer
forward until released from slides attached to Workbench (“Workbench Slides”).
Note: Slides attached to drawer (“Drawer Slides”) are an integral part of drawer and must be removed
along with drawer itself.
To replace drawer, pull slides out completely. Insert brackets on each side of Drawer Slides into
corresponding slots on Workbench Slides, making sure they are properly positioned. Once brackets are
inserted into slots, completely close drawer to set all slides in their proper positions.
© 2022 TRINITY - 800.985.5506
5
SERVICE PARTS LIST –TLSF-4811
Part Number Description Part Number Description
1) LNA-06-020-6619 Wood Top 14) XBK-22-006-1516 16” Drawer Liner
2) XBS-07-017-2603 26” Pull-out Tray 15) XBK-22-006-2516 26” Drawer Liner
3) ZSV-01-001-0612 Handle Bolt 16) XBK-22-006-3316 34” Drawer Liner
4) XSV-05-001-0900 Side Handle 17) ZSV-99-028-5020 Non-locking Caster
5) AMA-05-007-1500 16” Drawer Handle 18) XBS-07-009-3411 34” Deep Drawer
6) XBS-07-009-1605 16” Shallow Drawer 19) XBS-07-018-0920 Bin Drawer
7) ZSV-12-015-1575 Slide (workbench side) 20) AMA-05-007-0800 Bin Drawer Handle
8) ZSV-12-001-1575 Slide (drawer side) 21) XOR-21-007-0403 Bin
9) AMA-05-007-3300 34” Drawer Handle 22) CSV-11-005-0XXX Lock
10) XBS-07-009-3403 34” Shallow Drawer 23) XBS-07-017-3403 34” Pull-out Tray
11) XBS-07-009-1609 16” Deep Drawer 24) XBK-02-047-0001 Key leash
12) ZSV-01-001-1020 Caster Bolt 25) XBK-10-003-0XXX Key
13) ZSV-99-027-5020 Locking Caster
TRINITY Customer Service provides the following replacement parts:
6
7
3
10
4
14
19
20
17
12
21
18
22
NOTE: Replacement keys may be ordered using the code shown on the face of the lock.
11
24
© 2022 TRINITY - 800.985.5506 6
5
15
16
23
8
9
25 2
1
13
WARNINGS
1. Read and understand all instructions. Failure to follow all instructions may result in injury
and/or damage.
2. The warnings, cautions, and instructions discussed in this manual cannot cover all
possible conditions or situations that may occur. The user must always be aware of their
environment and ensure that they use the product in a safe and responsible manner.
3. Do NOT modify the product in any way. Unauthorized modification may impair the
function and/or safety of the product, and may affect the life of the product. Any
modifications will void warranty.
4. Check for damaged parts. Before using this product, carefully check that all parts are in
good condition, and that the product will operate properly and perform its intended
function. Check for damaged parts and any other conditions that may affect the operation
of this product. Replace damaged or worn parts, and never use this product with a
damaged part.
5. Do NOT overload the product. Capacity is based on evenly distributed weight.
6. Lock casters when leaving workbench in stationary position.
7. Lock drawers before moving the workbench.
8. Remove all items from wood top before moving the workbench. Items may fall causing
injury.
9. Always move workbench with two people. Roll slowly and constantly check
surroundings to ensure enough clearance. Heavy weight workbench can be hard to stop if
moving too fast, causing serious injury or damage.
10. Do NOT open more than one drawer at a time. Tipping can occur.
11. Do NOT step or lean on open drawers. Tipping can occur.
12. Do NOT lift workbench by wood top. Wood top may separate causing injury.
13. Do NOT hang on the wood top. Tipping can occur
14. Do NOT let children play near the workbench.
Weight capacity per bin 2 lb
Weight capacity per drawer w/ 1 pair of slides 100 lb
Weight capacity per drawer w/ 2 pairs of slides 200 lb
Total weight capacity of workbench 2200 lb
© 2022 TRINITY - 800.985.5506
7
© 2022 TRINITY - 800.985.5506 8
CARE AND MAINTENANCE
•Avoid harsh, abrasive cleaners, and other corrosive chemicals.
•Do not use scouring pad for cleaning.
•Keep dry and avoid damp environments.
•Use a quality stainless steel cleaner and follow instructions that come with the cleaner.
Wipe ALONG the grain (NOT against).
•Wood top can be cleaned with damp cloth and wiped dry immediately with dry cloth. If
needed, solvent-based wood furniture cleaner can be used.
•Clean up any spills immediately to prevent stains from forming on the wood top.
WARNINGS
15. Load workbench starting with bottom drawers to prevent workbench from tipping
16. Make sure all drawers are closed tightly before locking or unlocking.
© 2022 TRINITY - 800.985.5506
9
Thank you for purchasing a TRINITY PRO 66in Stainless Steel Rolling Workbench w/Clampable Raised Top.
In order to register your product and receive streamlined customer service, please fill out the following
Product Registration Form and (1) fax the form to 310.347.4134 (2) complete the Product Registration
Form online at www.trinityii.com or (3) scan and email the form to customerservice@trinityii.com. Include
a copy of your original receipt with your submission.
First Name: Last Name:
Address:
City: State: Zip Code:
Email Address: Phone:
Product Model #: TLSF-4811 Purchase Date: / /
Location of Purchase:
Please rate the importance of each feature (1=least important; 10=most important)
Quality Price Size/Capacity Appearance Other
How did you hear about our product?
Magazine Ad Catalog Salesperson Word of Mouth
Internet Store Display Other
Marital Status: Single Married
Household Income: Below $50,000 $50,000-$150,000 $150,000+
Education: High School College Graduate School
Primary Residence: Own Rent
Comments/Suggestions:
PRODUCT REGISTRATION
